Page 14 399G169 Rev B 27 April 2016
2.5.3 4-wire intercom (connectors G)
GPIO (connector K)
Pin
Description
Pin 1
Relay 1 COM
Pin 2
Relay 1 NC
Pin 3
Relay 1 NO
Pin 4
Relay 2 COM
