These functions can be set either in the 2-wire port settings page of the Core
Configuration Manager (CCM) or from the front panel screens on the Base
Station.
11.4 Connecting to 4-wire equipment
When connecting to 4-wire equipment the following need to be taken into
account:
• To minimise noise, use screened (shielded) cable when connecting 4-
wire ports.
• Pin-out configuration (mode) can be set on all FreeSpeak II Base 4-
wire interfaces. This is a software switch that switches the
configuration of the pins on the RJ45 etherCON connectors, according
to the device you are connecting to. Default setting: To Matrix.
11.5 Port function (to matrix or to panel)
Check this function whenever you are connecting 4-wire devices.
11.5.1 About port function
Clear-Com products are designed so matrices can connect directly to
panels/Base Station/main station using a straight-through CAT 5/6
(Ethernet) cable. The pin assignments (inputs and outputs) on these devices
are complementary. Previously, a crossover cable was necessary when
connecting Bases to other Bases. It is no longer necessary to use a crossover
cable as there is now a Port Function toggle which changes pinouts as
required. This is function is found in port options and can be set from the
CCM or the Base Station front panel menus.
11.5.2 Pin assignments
Port Function pin
assignments
To Next Page
