Page 27 399G169 Rev B 27 April 2016
4) Scroll through available systems using the right hand rotary
controller.
5) When you have found the antenna to pair to (it will be showing a '
P'
to indicate that it is open for pairing) press button
D to select the
antenna and connect the beltpack to it.
6) When the beltpack is successfully connected to the antenna, navigate
to Site Survey in the beltpack menu and monitor the range and
performance of the antenna. See
Interpret the Site Survey Screen
below.
3.4 Using an antenna with a Fiber connection
3.4.1 Install Fiber modules (parts HLI-SMFO, HLI-MMFO
You may wish to connect a FreeSpeak II Base to a splitter (FSII-SPL) using
Fiber. In this case, you need to install Fiber modules to the Base and the
splitter.
Modules are available for single mode Fiber cable (HLI-SMFO) and
multi-mode Fiber cable (HLI-MMFO)
Modules are supplied as a pair, one for the Base Station and one for
the splitter.
The Base Station switches between Fiber and RJ45 mode
automatically, depending on which connector (Fiber or RJ45) is used
Modules can be hot patched, no need to power off devices.
