Clear-Com FreeSpeak II User Manual

Page 96 399G169 Rev B 27 April 2016
Port Function pin
assignments
Pin
To Panel/Base Station
To Matrix
7
Data out +
Data in +
8
Data out -
Data in -
Note: When connecting one FreeSpeak II Base to another FreeSpeak II Base, one
device must be set ‘To Matrix’ and the other ‘To Panel’.
11.5.3 Setting port function
From the CCM:
From the Base Station:
