CleaverBrooks CFC User Manual

833-3577 CB-FALCON SYSTEM OPERATOR INTERFACE
750-241 47 65-0296—01
CH
anticondensa
tion enable
Enabled
Disabled
15 22
CH
anticondensa
tion pump
Normal (no change)
CH pump forced off
CH
anticondensa
tion setpoint
-40 °C - 130 °C (-40 °F - 266
°F)
DHW
anticondensa
tion enable
Enabled
Disabled
DHW
anticondensa
tion pump
Normal (no change)
DHW pump forced off
DHW
anticondensa
tion setpoint
-40 °C - 130 °C (-40 °F - 266
°F)
Anticondensa
tion priority
Is anticondensation more
important than (0=No, 1=Yes)?
Bit map:
15-5=Reserved (always 0)
4=Outlet high limit
3=Forced rate
2=Slow start
1=Delta-T limit
0=Stack limit
CH frost
protection
enable
Enabled
Disabled
16 22
DHW frost
protection
enable
Enabled
Disabled
Outdoor frost
protection
setpoint
-40 °C - 130 °C (-40 °F - 266
°F) (applicable for CH only)
Annunciation
enable
Enabled
Disabled
17 23
Annunciator
mode
Fixed
Programmable
Annunciator
(1–8) location
Unused
PII
LCI
ILK
Other
Annunciator
(1–8) short
name
Up to 3 characters
Annunciator
(1–8) name
Up to 20 characters
PII, LCI, ILK
short name
Up to 3 characters
PII, LCI, ILK
name
Up to 20 characters
Table 42. Configurable Parameters. (Continued)
Parameter Comment
Table
#
Page
#
PII enable Enabled
Disabled
18 23
LCI enable Enabled
Disabled
Interrupted
air switch
(IAS) enable
Enable during purge and
ignition
Disabled
IAS start
check enable
Enabled
Disabled
Interlock
(ILK) start
check enable
No ILK check
ILK check
ILK/IAS open
response
Recycle
Lockout
Purge rate
proving
Fan Speed
High Fire Switch
None
Lightoff rate
proving
Fan Speed
Low Fire Switch
None
Prepurge
rate
RPM or % 19 24
Prepurge
time
0-600 seconds
0 = Not configured
Run
stabilization
time
0-600 seconds
0 = Not configured
Pre-ignition
time
0-600 seconds
0xFFFF=Not configured
Postpurge
rate
RPM or %
Postpurge
time
0-600 seconds
0 = Not configured
Table 42. Configurable Parameters. (Continued)
Parameter Comment
Table
#
Page
#
