ProtoNode Gateway
750-426 99
B.20. FARC CB780/783
FARC CB 780/783 Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object
ID
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon SNVT Name Lon SNVT Name
BC_Initiate BI 1 DI 1 10001 FARC_AB_XXX[0].0 nvoBCInitit_XXX SNVT_switch
BC_Standby BI 2 DI 2 10002 FARC_AB_XXX[0].1 nvoBCStndby_XXX SNVT_switch
BC_Purge BI 3 DI 3 10003 FARC_AB_XXX[0].2 nvoBCPurge_XXX SNVT_switch
BC_Pilot_Ignition BI 4 DI 4 10004 FARC_AB_XXX[0].3 nvoBCPltIgn_XXX SNVT_switch
BC_Main_Ignition BI 5 DI 5 10005 FARC_AB_XXX[0].4 nvoBCMnIgn_XXX SNVT_switch
BC_Run_Mode BI 6 DI 6 10006 FARC_AB_XXX[0].5 nvoBCRunMde_XXX SNVT_switch
BC_Postpurge BI 7 DI 7 10007 FARC_AB_XXX[0].6 nvoBCPstPrg_XXX SNVT_switch
BC_Preignition BI 8 DI 8 10008 FARC_AB_XXX[0].7 nvoBCPreIgn_XXX SNVT_switch
BC_Alarm_Out BI 9 DI 9 10009 FARC_AB_XXX[0].8 nvoBCAlmOut_XXX SNVT_switch
BC_Lockout BI 10 DI 10 10010 FARC_AB_XXX[0].9 nvoBCLckout_XXX SNVT_switch
EA_Valve_POC BI 11 DI 11 10011 FARC_AB_XXX[0].10 nvoEAVlvPOC_XXX SNVT_switch
EA_Burner_Switch BI 12 DI 12 10012 FARC_AB_XXX[0].11 nvoEABrnSw_XXX SNVT_switch
EA_Oper_Control BI 13 DI 13 10013 FARC_AB_XXX[0].12 nvoEAOpCtrl_XXX SNVT_switch
EA_Aux_Limit_1 BI 14 DI 14 10014 FARC_AB_XXX[0].13 nvoEAAuxLm1_XXX SNVT_switch
EA_Aux_Limit_2 BI 15 DI 15 10015 FARC_AB_XXX[0].14 nvoEAAuxLm2_XXX SNVT_switch
EA_LWCO BI 16 DI 16 10016 FARC_AB_XXX[0].15 nvoEALWCO_XXX SNVT_switch
EA_High_Limit BI 17 DI 17 10017 FARC_AB_XXX[1].0 nvoEAHiLim_XXX SNVT_switch
EA_Aux_Limit_3 BI 18 DI 18 10018 FARC_AB_XXX[1].1 nvoEAAuxLm3_XXX SNVT_switch
EA_Oil_Select BI 19 DI 19 10019 FARC_AB_XXX[1].2 nvoEAOilSel_XXX SNVT_switch
EA_High_Oil_Press BI 20 DI 20 10020 FARC_AB_XXX[1].3 nvoEAHiOilPr_XXX SNVT_switch
EA_Low_Oil_Press BI 21 DI 21 10021 FARC_AB_XXX[1].4 nvoEALoOilPr_XXX SNVT_switch
EA_High_Oil_Temp BI 22 DI 22 10022 FARC_AB_XXX[1].5 nvoEAHiOilTp_XXX SNVT_switch
EA_Low_Oil_Temp BI 23 DI 23 10023 FARC_AB_XXX[1].6 nvoEALoOilTp_XXX SNVT_switch
EA_Gas_Select BI 24 DI 24 10024 FARC_AB_XXX[1].7 nvoEAGasSel_XXX SNVT_switch
EA_High_Gas_Press BI 25 DI 25 10025 FARC_AB_XXX[1].8 nvoEAHiGasPr_XXX SNVT_switch
EA_Low_Gas_Press BI 26 DI 26 10026 FARC_AB_XXX[1].9 nvoEALoGasPr_XXX SNVT_switch
EA_Air_Flow_Switch BI 27 DI 27 10027 FARC_AB_XXX[1].10 nvoEAAirFlSw_XXX SNVT_switch
EA_Aux_Limit_4 BI 28 DI 28 10028 FARC_AB_XXX[1].11 nvoEAAuxLim4_XXX SNVT_switch
EA_Aux_Limit_5 BI 29 DI 29 10029 FARC_AB_XXX[1].12 nvoEAAuxLim5_XXX SNVT_switch
BC_Fault_Code AI 1 AI 1 40001 FARC_AI_XXX[0] nvoBCFltCd_XXX SNVT_count_f
BC_Fault_String_Code AI 2 AI 2 40002 FARC_AI_XXX[1] nvoBCFlStrCd_XXX SNVT_count_f
BC_Sequence_State AI 3 AI 3 40003 FARC_AI_XXX[2] nvoBCSeqStat_XXX SNVT_count_f
BC_State_String_Code_L1 AI 4 AI 4 40004 FARC_AI_XXX[3] nvoBCStStCL1_XXX SNVT_count_f
BC_State_String_Code_L2 AI 5 AI 5 40005 FARC_AI_XXX[4] nvoBCStStCL2_XXX SNVT_count_f
BC_Sequence_Time AI 6 AI 6 40006 FARC_AI_XXX[5] nvoBCSeqTme_XXX SNVT_count_f
BC_Flame_Signal_Strength AI 7 AI 7 40011 FARC_AI_XXX[6] nvoBCFlSgStr_XXX SNVT_count_f
BC_State_Bits AI 8 AI 8 40012 FARC_AI_XXX[7] nvoBCStBits_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec1 AI 9 AI 9 40017 FARC_AI_XXX[8] nvoBCFlHCdR1_XXX SNVT_count_f
BC_Flt_Hist_String_Rec1 AI 10 AI 10 40018 FARC_AI_XXX[9] nvoBCFHStrR1_XXX SNVT_count_f
BC_Flt_Hist_State_Rec1 AI 11 AI 11 40019 FARC_AI_XXX[10] nvoBCFHStr1_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec1 AI 12 AI 12 40020 FARC_AI_XXX[11] nvoBCFlHL1R1_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec1 AI 13 AI 13 40021 FARC_AI_XXX[12] nvoBCFlHL2R1_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec1 AI 14 AI 14 40022 FARC_AI_XXX[13] nvoBCFlHTmR1_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec2 AI 15 AI 15 40027 FARC_AI_XXX[14] nvoBCFlHCdR2_XXX SNVT_count_f
BC_Flt_Hist_String_Rec2 AI 16 AI 16 40028 FARC_AI_XXX[15] nvoBCFHStrR2_XXX SNVT_count_f
BC_Flt_Hist_State_Rec2 AI 17 AI 17 40029 FARC_AI_XXX[16] nvoBCFHStr2_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec2 AI 18 AI 18 40030 FARC_AI_XXX[17] nvoBCFlHL1R2_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec2 AI 19 AI 19 40031 FARC_AI_XXX[18] nvoBCFlHL2R2_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec2 AI 20 AI 20 40032 FARC_AI_XXX[19] nvoBCFlHTmR2_XXX SNVT_count_f
