ProtoNode Gateway
38 750-426
APPENDIX A. TROUBLESHOOTING
A.1. Lost or Incorrect IP Address
Ensure that FieldServer Toolbox is loaded onto the local PC. Otherwise, download the FieldServer-
Toolbox.zip via the Sierra Monitor Resource Center Software Downloads.
Extract the executable file and complete the installation.
FIGURE 42 - Ethernet port location
Connect a standard CAT5 Ethernet cable between the user's PC and ProtoNode.
Double click on the FS Toolbox Utility and click Discover Now on the splash page.
Check for the IP Address of the desired gateway.
If correcting the IP Address of the gateway: click the settings icon on the same row as the gate-
way, then click Network Settings, change the IP Address and click Update IP Settings to save.
