ProtoNode Gateway

54 750-426

B.5. HSC

HSC Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks

RER LER

Point Name

BACnet

Data

Type

BACnet

Object Id

Data

Type

N2 Point

Address

Modbus

EIP Tag Name Lon Name Lon SNVT Type

C Boiler 1 State AI 1 AI 1 30021 HSC_AI_XXX[0] nvoCBl1St_XXX SNVT_count_inc_f

C Boiler 1 Alarm Word AI 2 AI 2 30022 HSC_AI_XXX[1] nvoCBl1AlWd_XXX SNVT_count_inc_f

C Boiler 1 Hours Word 1 AI 3 AI 3 30023 HSC_AI_XXX[2] nvoCBl1Hrs1_XXX SNVT_time_hour

C Boiler 1 Hours Word 2 AI 4 AI 4 30024 HSC_AI_XXX[3] nvoCBl1Hrs2_XXX SNVT_time_hour

C Boiler 1 Cycles Word 1 AI 5 AI 5 30025 HSC_AI_XXX[4] nvoCBl1Cyc1_XXX SNVT_count_inc_f

C Boiler 1 Cycles Word 2 AI 6 AI 6 30026 HSC_AI_XXX[5] nvoCBl1Cyc2_XXX SNVT_count_inc_f

C Boiler 1 Status Bits AI 7 AI 7 30027 HSC_AI_XXX[6] nvoCBl1StBt_XXX SNVT_count_inc_f

C Boiler 1 Inlet Temp AI 8 AI 8 30028 HSC_AI_XXX[7] nvoCBl1InTp_XXX SNVT_temp_p

C Boiler 1 Fire Delay AI 9 AI 9 30029 HSC_AI_XXX[8] nvoCBl1FrDl_XXX SNVT_count_inc_f

C Boiler 1 Outlet Temp AI 10 AI 10 30030 HSC_AI_XXX[9] nvoCBl1OtTp_XXX SNVT_temp_p

C Boiler 2 State AI 11 AI 11 30031 HSC_AI_XXX[10] nvoCBl2St_XXX SNVT_count_inc_f

C Boiler 2 Alarm Word AI 12 AI 12 30032 HSC_AI_XXX[11] nvoCBl2AlWd_XXX SNVT_count_inc_f

C Boiler 2 Hours Word 1 AI 13 AI 13 30033 HSC_AI_XXX[12] nvoCBl2Hrs1_XXX SNVT_time_hour

C Boiler 2 Hours Word 2 AI 14 AI 14 30034 HSC_AI_XXX[13] nvoCBl2Hrs2_XXX SNVT_time_hour

C Boiler 2 Cycles Word 1 AI 15 AI 15 30035 HSC_AI_XXX[14] nvoCBl2Cyc1_XXX SNVT_count_inc_f

C Boiler 2 Cycles Word 2 AI 16 AI 16 30036 HSC_AI_XXX[15] nvoCBl2Cyc2_XXX SNVT_count_inc_f

C Boiler 2 Status Bits AI 17 AI 17 30037 HSC_AI_XXX[16] nvoCBl2StBt_XXX SNVT_count_inc_f

C Boiler 2 Inlet Temp AI 18 AI 18 30038 HSC_AI_XXX[17] nvoCBl2InTp_XXX SNVT_temp_p

C Boiler 2 Fire Delay AI 19 AI 19 30039 HSC_AI_XXX[18] nvoCBl2FrDl_XXX SNVT_count_inc_f

C Boiler 2 Outlet Temp AI 20 AI 20 30040 HSC_AI_XXX[19] nvoCBl2OtTp_XXX SNVT_temp_p

C Boiler 3 State AI 21 AI 21 30041 HSC_AI_XXX[20] nvoCBl3St_XXX SNVT_count_inc_f

C Boiler 3 Alarm Word AI 22 AI 22 30042 HSC_AI_XXX[21] nvoCBl3AlWd_XXX SNVT_count_inc_f

C Boiler 3 Hours Word 1 AI 23 AI 23 30043 HSC_AI_XXX[22] nvoCBl3Hrs1_XXX SNVT_time_hour

C Boiler 3 Hours Word 2 AI 24 AI 24 30044 HSC_AI_XXX[23] nvoCBl3Hrs2_XXX SNVT_time_hour

C Boiler 3 Cycles Word 1 AI 25 AI 25 30045 HSC_AI_XXX[24] nvoCBl3Cyc1_XXX SNVT_count_inc_f

C Boiler 3 Cycles Word 2 AI 26 AI 26 30046 HSC_AI_XXX[25] nvoCBl3Cyc2_XXX SNVT_count_inc_f

C Boiler 3 Status Bits AI 27 AI 27 30047 HSC_AI_XXX[26] nvoCBl3StBt_XXX SNVT_count_inc_f

C Boiler 3 Inlet Temp AI 28 AI 28 30048 HSC_AI_XXX[27] nvoCBl3InTp_XXX SNVT_temp_p

C Boiler 3 Fire Delay AI 29 AI 29 30049 HSC_AI_XXX[28] nvoCBl3FrDl_XXX SNVT_count_inc_f

C Boiler 3 Outlet Temp AI 30 AI 30 30050 HSC_AI_XXX[29] nvoCBl3OtTp_XXX SNVT_temp_p

C Boiler 4 State AI 31 AI 31 30051 HSC_AI_XXX[30] nvoCBl4St_XXX SNVT_count_inc_f

C Boiler 4 Alarm Word AI 32 AI 32 30052 HSC_AI_XXX[31] nvoCBl4AlWd_XXX SNVT_count_inc_f

C Boiler 4 Hours Word 1 AI 33 AI 33 30053 HSC_AI_XXX[32] nvoCBl4Hrs1_XXX SNVT_time_hour

C Boiler 4 Hours Word 2 AI 34 AI 34 30054 HSC_AI_XXX[33] nvoCBl4Hrs2_XXX SNVT_time_hour

C Boiler 4 Cycles Word 1 AI 35 AI 35 30055 HSC_AI_XXX[34] nvoCBl4Cyc1_XXX SNVT_count_inc_f

C Boiler 4 Cycles Word 2 AI 36 AI 36 30056 HSC_AI_XXX[35] nvoCBl4Cyc2_XXX SNVT_count_inc_f

C Boiler 4 Status Bits AI 37 AI 37 30057 HSC_AI_XXX[36] nvoCBl4StBt_XXX SNVT_count_inc_f

C Boiler 4 Inlet Temp AI 38 AI 38 30058 HSC_AI_XXX[37] nvoCBl4InTp_XXX SNVT_temp_p

C Boiler 4 Fire Delay AI 39 AI 39 30059 HSC_AI_XXX[38] nvoCBl4FrDl_XXX SNVT_count_inc_f

C Boiler 4 Outlet Temp AI 40 AI 40 30060 HSC_AI_XXX[39] nvoCBl4OtTp_XXX SNVT_temp_p

C Boiler 5 State AI 41 AI 41 30061 HSC_AI_XXX[40] nvoCBl5St_XXX SNVT_count_inc_f

C Boiler 5 Alarm Word AI 42 AI 42 30062 HSC_AI_XXX[41] nvoCBl5AlWd_XXX SNVT_count_inc_f

C Boiler 5 Hours Word 1 AI 43 AI 43 30063 HSC_AI_XXX[42] nvoCBl5Hrs1_XXX SNVT_time_hour

C Boiler 5 Hours Word 2 AI 44 AI 44 30064 HSC_AI_XXX[43] nvoCBl5Hrs2_XXX SNVT_time_hour

C Boiler 5 Cycles Word 1 AI 45 AI 45 30065 HSC_AI_XXX[44] nvoCBl5Cyc1_XXX SNVT_count_inc_f

C Boiler 5 Cycles Word 2 AI 46 AI 46 30066 HSC_AI_XXX[45] nvoCBl5Cyc2_XXX SNVT_count_inc_f

C Boiler 5 Status Bits AI 47 AI 47 30067 HSC_AI_XXX[46] nvoCBl5StBt_XXX SNVT_count_inc_f

C Boiler 5 Inlet Temp AI 48 AI 48 30068 HSC_AI_XXX[47] nvoCBl5InTp_XXX SNVT_temp_p

C Boiler 5 Fire Delay AI 49 AI 49 30069 HSC_AI_XXX[48] nvoCBl5FrDl_XXX SNVT_count_inc_f
