ProtoNode Gateway
750-426 53
LOCKOUT8_MODULE AI 26 AI 26 40059 CB120_AI[22] nvoLkot8Mod_XXX SNVT_count_f
LOCKOUT9_MSG AI 27 AI 27 40064 CB120_AI[23] nvoLkot9Msg_XXX SNVT_count_f
LOCKOUT9_MODULE AI 28 AI 28 40065 CB120_AI[24] nvoLkot9Mod_XXX SNVT_count_f
LOCKOUT10_MSG AI 29 AI 29 40070 CB120_AI[25] nvoLkot10Msg_XXX SNVT_count_f
LOCKOUT10_MODULE AI 30 AI 30 40071 CB120_AI[26] nvoLkot10Mod_XXX SNVT_count_f
LOCKOUT1_BNRHRS AI 31 AI 31 40018-19 CB120_AD[3] nvoLk1BrnHrs_XXX SNVT_time_hour
LOCKOUT1_BNRCYCS AI 32 AI 32 40020-21 CB120_AD[4] nvoLk1BrnCyc_XXX SNVT_count_f
LOCKOUT2_BNRHRS AI 33 AI 33 40024-25 CB120_AD[5] nvoLk2BrnHrs_XXX SNVT_time_hour
LOCKOUT2_BNRCYCS AI 34 AI 34 40026-27 CB120_AD[6] nvoLk2BrnCyc_XXX SNVT_count_f
LOCKOUT3_BNRHRS AI 35 AI 35 40030-31 CB120_AD[7] nvoLk3BrnHrs_XXX SNVT_time_hour
LOCKOUT3_BNRCYCS AI 36 AI 36 40032-34 CB120_AD[8] nvoLk3BrnCyc_XXX SNVT_count_f
LOCKOUT4_BNRHRS AI 37 AI 37 40036-37 CB120_AD[9] nvoLk4BrnHrs_XXX SNVT_time_hour
LOCKOUT4_BNRCYCS AI 38 AI 38 40038-39 CB120_AD[10] nvoLk4BrnCyc_XXX SNVT_count_f
LOCKOUT5_BNRHRS AI 39 AI 39 40042-43 CB120_AD[11] nvoLk5BrnHrs_XXX SNVT_time_hour
LOCKOUT5_BNRCYCS AI 40 AI 40 40044-45 CB120_AD[12] nvoLk5BrnCyc_XXX SNVT_count_f
LOCKOUT6_BNRHRS AI 41 AI 41 40048-49 CB120_AD[13] nvoLk6BrnHrs_XXX SNVT_time_hour
LOCKOUT6_BNRCYCS AI 42 AI 42 40050-51 CB120_AD[14] nvoLk6BrnCyc_XXX SNVT_count_f
LOCKOUT7_BNRHRS AI 43 AI 43 40054-55 CB120_AD[15] nvoLk7BrnHrs_XXX SNVT_time_hour
LOCKOUT7_BNRCYCS AI 44 AI 44 40056-57 CB120_AD[16] nvoLk7BrnCyc_XXX SNVT_count_f
LOCKOUT8_BNRHRS AI 45 AI 45 40060-61 CB120_AD[17] nvoLk8BrnHrs_XXX SNVT_time_hour
LOCKOUT8_BNRCYCS AI 46 AI 46 40062-63 CB120_AD[18] nvoLk8BrnCyc_XXX SNVT_count_f
LOCKOUT9_BNRHRS AI 47 AI 47 40066-67 CB120_AD[19] nvoLk9BrnHrs_XXX SNVT_time_hour
LOCKOUT9_BNRCYCS AI 48 AI 48 40068-69 CB120_AD[20] nvoLk9BrnCyc_XXX SNVT_count_f
LOCKOUT10_BNRHRS AI 49 AI 49 40072-73 CB120_AD[21] nvoLk10BrnHr_XXX SNVT_time_hour
LOCKOUT10_BNRCYCS AI 50 AI 50 40074-75 CB120_AD[22] nvoLk10BrnCy_XXX SNVT_count_f
Op_Control BI 25 DI 25 40901 0 CB120_AB[2].0 nvoOpControl_XXX SNVT_switch
Aux_1 BI 26 DI 26 40901 1 CB120_AB[2].1 nvoAux1_XXX SNVT_switch
Aux_2 BI 27 DI 27 40901 2 CB120_AB[2].2 nvoAux2_XXX SNVT_switch
Aux_3 BI 28 DI 28 40901 3 CB120_AB[2].3 nvoAux3_XXX SNVT_switch
High_water BI 29 DI 29 40901 4 CB120_AB[2].4 nvoHiwater_XXX SNVT_switch
Low_Water BI 30 DI 30 40901 5 CB120_AB[2].5 nvoLoWater_XXX SNVT_switch
High_Oil_Temp BI 31 DI 31 40901 6 CB120_AB[2].6 nvoHiOilTemp_XXX SNVT_switch
Low_Oil_Temp BI 32 DI 32 40901 7 CB120_AB[2].7 nvoLoOilTemp_XXX SNVT_switch
Low_Oil_Press BI 33 DI 33 40902 0 CB120_AB[3].0 nvoLoOilPrs_XXX SNVT_switch
Low_Atom_Media BI 34 DI 34 40902 1 CB120_AB[3].1 nvoLoAtmMed_XXX SNVT_switch
Low_Gas_Press BI 35 DI 35 40902 2 CB120_AB[3].2 nvoLoGasPrs_XXX SNVT_switch
High_Gas_Press BI 36 DI 36 40902 3 CB120_AB[3].3 nvoHiGasPrs_XXX SNVT_switch
Aux_Gas BI 37 DI 37 40902 4 CB120_AWB[0].0 nvoAuxGas_XXX SNVT_switch
High_Press BI 38 DI 38 40902 5 CB120_AB[3].5 nvoHiPress_XXX SNVT_switch
High_Temp BI 39 DI 39 40902 6 CB120_AB[3].6 nvoHiTemp_XXX SNVT_switch
Aux_4 BI 40 DI 40 40902 7 CB120_AB[3].7 nvoAux4_XXX SNVT_switch
Aux_5 BI 41 DI 41 40903 0 CB120_AB[4].0 nvoAux5_XXX SNVT_switch
Aux_6 BI 42 DI 42 40903 1 CB120_AB[4].1 nvoAux6_XXX SNVT_switch
Aux_7 BI 43 DI 43 40903 2 CB120_AB[4].2 nvoAux7_XXX SNVT_switch
Air_Flow BI 44 DI 44 40903 3 CB120_AB[4].3 nvoAirFlo_XXX SNVT_switch
CB120 Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
(Bit) EIP Tag Name Lon Name Lon SNVT Type
To Next Page
