ProtoNode Gateway
131 750-426
APPENDIX E — SPECIFICATIONS / UL COMPLIANCE
E.1 Specifications
E.1.1. Compliance with UL Regulations
For UL compliance, the following instructions must be met when operating ProtoNode.
• The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating tem-
perature range.
• The interconnecting power connector and power cable shall:
Comply with local electrical code.
Be suited to the expected operating temperature range.
Meet the current and voltage rating for ProtoNode/Net
• Furthermore, the interconnecting power cable shall:
Be of length not exceeding 3.05m (118.3")
Be constructed of materials rated VW-1 or FT-1 or better
• If the unit is to be installed in an operating environment with a temperature above 65 °C, it should be
installed in a Restricted Access Area requiring a key or a special tool to gain access
• This device must not be connected to a LAN segment with outdoor wiring.
ProtoNode RER ProtoNode LER
Electrical Connections
One 6-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
Power port (+ / - / Frame-gnd)
One 3-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
One Ethernet 10/100BaseT port
One 6-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
Power port (+ / - / Frame-gnd)
One Ethernet 10/100BaseT port
One FTT-10 LonWorks port
Approvals:
CE Certified; TUV approved to UL 916, EN 60950-1, EN 50491-3 and CSA C22-2
standards;
FCC Class A Part 15; DNP3 Conformance Tested; OPC Self-tested for Compliance;
RoHS Compliant; CSA 205 Approved
BTL Marked LonMark Certified
Power Requirements
Multi-mode power adapter: 9-30VDC or 12 - 24VAC
Physical Dimensions 11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)
Weight:
0.2 kg (0.4 lbs)
Operating Temperature:
-40°C to 75°C (-40°F to167°F)
Surge Suppression EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Humidity:
5 - 90% RH (non-condensing)
(Specifications subject to change without notice)
