ProtoNode Gateway
94 750-426
B.15. SHARK 100
Shark 100 Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon Name Lon SNVT Type
Volts A-N AI 1 AI 1 41000 S100_AR_XXX[0] nvoVoltsAN_XXX SNVT_count_inc_f
Volts B-N AI 2 AI 2 41002 S100_AR_XXX[1] nvoVoltsBN_XXX SNVT_count_inc_f
Volts C-N AI 3 AI 3 41004 S100_AR_XXX[2] nvoVoltsCN_XXX SNVT_count_inc_f
Volts A-B AI 4 AI 4 41006 S100_AR_XXX[3] nvoVoltsAB_XXX SNVT_count_inc_f
Volts B-C AI 5 AI 5 41008 S100_AR_XXX[4] nvoVoltsBC_XXX SNVT_count_inc_f
Volts C-A AI 6 AI 6 41010 S100_AR_XXX[5] nvoVoltsCA_XXX SNVT_count_inc_f
Amps A AI 7 AI 7 41012 S100_AR_XXX[6] nvoAmpsA_XXX SNVT_count_inc_f
Amps B AI 8 AI 8 41014 S100_AR_XXX[7] nvoAmpsB_XXX SNVT_count_inc_f
Amps C AI 9 AI 9 41016 S100_AR_XXX[8] nvoAmpsC_XXX SNVT_count_inc_f
Watts 3-Ph total AI 10 AI 10 41018 S100_AR_XXX[9] nvoWatt3PhTo_XXX SNVT_count_inc_f
VARs 3-Ph total AI 11 AI 11 41020 S100_AR_XXX[10] nvoVAR3PhTot_XXX SNVT_count_inc_f
VAs 3-Ph total AI 12 AI 12 41022 S100_AR_XXX[11] nvoVA3PhTot_XXX SNVT_count_inc_f
Power Factor 3-Ph total AI 13 AI 13 41024 S100_AR_XXX[12] nvoPF3PhTot_XXX SNVT_count_inc_f
Frequency AI 14 AI 14 41026 S100_AR_XXX[13] nvoFreq_XXX SNVT_count_inc_f
Neutral Current AI 15 AI 15 41028 S100_AR_XXX[14] nvoNeutCurr_XXX SNVT_count_inc_f
W-hours Received AI 16 AI 16 41100 S100_AD_XXX[0] nvoWh_Rec_XXX SNVT_count_inc_f
W-hours Delivered AI 17 AI 17 41102 S100_AD_XXX[1] nvoWh_Del_XXX SNVT_count_inc_f
W-hours Net AI 18 AI 18 41104 S100_AD_XXX[2] nvoWh_Net_XXX SNVT_count_inc_f
W-hours Total AI 19 AI 19 41106 S100_AD_XXX[3] nvoWh_Tot_XXX SNVT_count_inc_f
VAR-hours Positive AI 20 AI 20 41108 S100_AD_XXX[4] nvoVARh_Pos_XXX SNVT_count_inc_f
VAR-hours Negative AI 21 AI 21 41110 S100_AD_XXX[5] nvoVARh_Neg_XXX SNVT_count_inc_f
VAR-hours Net AI 22 AI 22 41112 S100_AD_XXX[6] nvoVARh_Net_XXX SNVT_count_inc_f
VAR-hours Total AI 23 AI 23 41114 S100_AD_XXX[7] nvoVARh_Tot_XXX SNVT_count_inc_f
VA-hours Total AI 24 AI 24 41116 S100_AD_XXX[8] nvoVAh_Tot_XXX SNVT_count_inc_f
Positive Watts 3-Ph Avg AI 25 AI 25 42006 S100_AR_XXX[15] nvoPsWt3PhAv_XXX SNVT_count_inc_f
Positive VARs 3-Ph Avg AI 26 AI 26 42008 S100_AR_XXX[16] nvoPsVAR3PhA_XXX SNVT_count_inc_f
Negative Watts 3-Ph Avg AI 27 AI 27 42010 S100_AR_XXX[17] nvoNgWt3PhAv_XXX SNVT_count_inc_f
Negative VARs 3-Ph Avg AI 28 AI 28 42012 S100_AR_XXX[18] nvoNgVAR3PhA_XXX SNVT_count_inc_f
VAs 3-Ph Avg AI 29 AI 29 42014 S100_AR_XXX[19] nvoVA3Ph_Avg_XXX SNVT_count_inc_f
Positive PF 3-Ph Avg AI 30 AI 30 42016 S100_AR_XXX[20] nvoPsPF3PhAv_XXX SNVT_count_inc_f
Negative PF 3-PF Avg AI 31 AI 31 42018 S100_AR_XXX[21] nvoNgPF3PhAv_XXX SNVT_count_inc_f
Positive Watts 3-Ph Max Avg Demand AI 32 AI 32 43118 S100_AR_XXX[22] nvoPWt3PMADm_XXX SNVT_count_inc_f
Positive VARs 3-Ph Max Avg Demand AI 33 AI 33 43120 S100_AR_XXX[23] nvoPVAR3PMAD_XXX SNVT_count_inc_f
Negative Watts 3-Ph Max Avg Demand AI 34 AI 34 43122 S100_AR_XXX[24] nvoNWt3PMADm_XXX SNVT_count_inc_f
Negative VARs 3-Ph Max Avg Demand AI 35 AI 35 43124 S100_AR_XXX[25] nvoNVAR3PMAD_XXX SNVT_count_inc_f
Volts A-N %THD AI 36 AI 36 44000 S100_AI_XXX[0] nvoVltAN_THD_XXX SNVT_lev_percent
Volts B-N %THD AI 37 AI 37 44001 S100_AI_XXX[1] nvoVltBN_THD_XXX SNVT_lev_percent
Volts C-N %THD AI 38 AI 38 44002 S100_AI_XXX[2] nvoVltCN_THD_XXX SNVT_lev_percent
Amps A %THD AI 39 AI 39 44003 S100_AI_XXX[3] nvoAmpA_THD_XXX SNVT_lev_percent
Amps B %THD AI 40 AI 40 44004 S100_AI_XXX[4] nvoAmpB_THD_XXX SNVT_lev_percent
Amps C %THD AI 41 AI 41 44005 S100_AI_XXX[5] nvoAmpC_THD_XXX SNVT_lev_percent
