B.7. PCS
PCS Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon Name Lon SNVT Type
Header Pressure/Tank Level AI 1 AI 1 40050 PCS_AI_XXX[0] nvoHdPrTnkLv_XXX SNVT_count_inc_f
VSD Speed PID Loop Setpoint AI 2 AI 2 40051 PCS_AI_XXX[1] nvoVSDSpLpSP_XXX SNVT_count_inc_f
Reserved AI 3 AI 3 40052 PCS_AI_XXX[2] nvoReserved_XXX SNVT_count_inc_f
VSD Speed PID Loop Output AI 4 AI 4 40053 PCS_AI_XXX[3] nvoVSDSpLpOt_XXX SNVT_lev_percent
Digital Input Word AI 5 AI 5 40054 PCS_AI_XXX[4] nvoDI_Word_XXX SNVT_count
Digital Output Word AI 6 AI 6 40055 PCS_AI_XXX[5] nvoDO_Word_XXX SNVT_count
Alarm Word 1 AI 7 AI 7 40056 PCS_AI_XXX[6] nvoAlm_Word1_XXX SNVT_count
Alarm Word 2 AI 8 AI 8 40057 PCS_AI_XXX[7] nvoAlm_Word2_XXX SNVT_count
Lead Pump AI 9 AI 9 40058 PCS_AI_XXX[8] nvoLeadPmp_XXX SNVT_count_inc_f
Lag 1 Pump AI 10 AI 10 40059 PCS_AI_XXX[9] nvoLag1Pmp_XXX SNVT_count_inc_f
Lag 2 Pump AI 11 AI 11 40060 PCS_AI_XXX[10] nvoLag2Pmp_XXX SNVT_count_inc_f
Standby Pump AI 12 AI 12 40061 PCS_AI_XXX[11] nvoStndbyPmp_XXX SNVT_count_inc_f
Pump 1 Hours (10 000s) AI 13 AI 13 40062 PCS_AI_XXX[12] nvoPmp1Hrs10_XXX SNVT_time_hour
Pump 1 Hours (1s) AI 14 AI 14 40063 PCS_AI_XXX[13] nvoPmp1Hrs1_XXX SNVT_time_hour
Pump 2 Hours (10 000s) AI 15 AI 15 40064 PCS_AI_XXX[14] nvoPmp2Hrs10_XXX SNVT_time_hour
Pump 2 Hours (1s) AI 16 AI 16 40065 PCS_AI_XXX[15] nvoPmp2Hrs1_XXX SNVT_time_hour
Pump 3 Hours (10 000s) AI 17 AI 17 40066 PCS_AI_XXX[16] nvoPmp3Hrs10_XXX SNVT_time_hour
Pump 3 Hours (1s) AI 18 AI 18 40067 PCS_AI_XXX[17] nvoPmp3Hrs1_XXX SNVT_time_hour
Pump 4 Hours (10 000s) AI 19 AI 19 40068 PCS_AI_XXX[18] nvoPmp4Hrs10_XXX SNVT_time_hour
Pump 4 Hours (1s) AI 20 AI 20 40069 PCS_AI_XXX[19] nvoPmp4Hrs1_XXX SNVT_time_hour
VSD Speed Output Signal AI 21 AI 21 40070 PCS_AI_XXX[20] nvoVSDSpOtSg_XXX SNVT_switch
Pump 1 Fault BI 1 DI 1 10001 PCS_AB_XXX[0].0 nvoPmp1Fault_XXX SNVT_switch
Pump 2 Fault BI 2 DI 2 10002 PCS_AB_XXX[0].1 nvoPmp2Fault_XXX SNVT_switch
Pump 3 Fault BI 3 DI 3 10003 PCS_AB_XXX[0].2 nvoPmp3Fault_XXX SNVT_switch
Pump 4 Fault BI 4 DI 4 10004 PCS_AB_XXX[0].3 nvoPmp4Fault_XXX SNVT_switch
Header Pressure Low Alm BI 5 DI 5 10005 PCS_AB_XXX[0].4 nvoHdrPrLoAl_XXX SNVT_switch
Header Pressure High Alm BI 6 DI 6 10006 PCS_AB_XXX[0].5 nvoHdrPrHiAl_XXX SNVT_switch
Analog Signal Failure BI 7 DI 7 10007 PCS_AB_XXX[0].6 nvoAnaSigFl_XXX SNVT_switch
Datalog SD Card Full BI 8 DI 8 10008 PCS_AB_XXX[0].7 nvoSDCardFul_XXX SNVT_switch
Pump 1 in Manual Mode BI 9 DI 9 10009 PCS_AB_XXX[0].8 nvoPmp1ManMd_XXX SNVT_switch
Pump 2 in Manual Mode BI 10 DI 10 10010 PCS_AB_XXX[0].9 nvoPmp2ManMd_XXX SNVT_switch
Pump 3 in Manual Mode BI 11 DI 11 10011 PCS_AB_XXX[0].10 nvoPmp3ManMd_XXX SNVT_switch
Pump 4 in Manual Mode BI 12 DI 12 10012 PCS_AB_XXX[0].11 nvoPmp4ManMd_XXX SNVT_switch
Source Tank LWCO BI 13 DI 13 10013 PCS_AB_XXX[0].12 nvoSrcTkLWCO_XXX SNVT_switch
Low Battery BI 14 DI 14 10014 PCS_AB_XXX[0].13 nvoLowBatt_XXX SNVT_switch
External Alm BI 15 DI 15 10015 PCS_AB_XXX[0].14 nvoExtAlm_XXX SNVT_switch
Level Low Alm BI 16 DI 16 10016 PCS_AB_XXX[0].15 nvoLvlLoAlm_XXX SNVT_switch
Level High Alm BI 17 DI 17 10017 PCS_AB_XXX[1].0 nvoLvlHiAlm_XXX SNVT_switch
Alarm Word Bit 1 BI 18 DI 18 10018 PCS_AB_XXX[1].1 nvoAlmWdBit1_XXX SNVT_switch
Alarm Word Bit 2 BI 19 DI 19 10019 PCS_AB_XXX[1].2 nvoAlmWdBit2_XXX SNVT_switch
Alarm Word Bit 3 BI 20 DI 20 10020 PCS_AB_XXX[1].3 nvoAlmWdBit3_XXX SNVT_switch
Alarm Word Bit 4 BI 21 DI 21 10021 PCS_AB_XXX[1].4 nvoAlmWdBit4_XXX SNVT_switch
Alarm Word Bit 5 BI 22 DI 22 10022 PCS_AB_XXX[1].5 nvoAlmWdBit5_XXX SNVT_switch
Alarm Word Bit 6 BI 23 DI 23 10023 PCS_AB_XXX[1].6 nvoAlmWdBit6_XXX SNVT_switch
Alarm Word Bit 7 BI 24 DI 24 10024 PCS_AB_XXX[1].7 nvoAlmWdBit7_XXX SNVT_switch
Alarm Word Bit 8 BI 25 DI 25 10025 PCS_AB_XXX[1].8 nvoAlmWdBit8_XXX SNVT_switch
Alarm Word Bit 9 BI 26 DI 26 10026 PCS_AB_XXX[1].9 nvoAlmWdBit9_XXX SNVT_switch
Alarm Word Bit 10 BI 27 DI 27 10027 PCS_AB_XXX[1].10 nvoAlWdBit10_XXX SNVT_switch
Alarm Word Bit 11 BI 28 DI 28 10028 PCS_AB_XXX[1].11 nvoAlWdBit11_XXX SNVT_switch
Alarm Word Bit 12 BI 29 DI 29 10029 PCS_AB_XXX[1].12 nvoAlWdBit12_XXX SNVT_switch
Alarm Word Bit 13 BI 30 DI 30 10030 PCS_AB_XXX[1].13 nvoAlWdBit13_XXX SNVT_switch
Alarm Word Bit 14 BI 31 DI 31 10031 PCS_AB_XXX[1].14 nvoAlWdBit14_XXX SNVT_switch
Alarm Word Bit 15 BI 32 DI 32 10032 PCS_AB_XXX[1].15 nvoAlWdBit15_XXX SNVT_switch
Pump 1 Run BI 33 DI 33 10033 PCS_AB_XXX[2].0 nvoPmp1Run_XXX SNVT_switch
Pump 2 Run BI 34 DI 34 10034 PCS_AB_XXX[2].1 nvoPmp2Run_XXX SNVT_switch
Pump 3 Run BI 35 DI 35 10035 PCS_AB_XXX[2].2 nvoPmp3Run_XXX SNVT_switch
Pump 4 Run BI 36 DI 36 10036 PCS_AB_XXX[2].3 nvoPmp4Run_XXX SNVT_switch
