B.18. PUMP INTERFACE MODULE
Pump Interface Module Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object
ID
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon SNVT Name Lon SNVT Name
Input Word AI 1 AI 1 30021 LCS_AI_XXX[0] nvoInputWrd_XXX SNVT_count_f
Output Word AI 2 AI 2 30022 LCS_AI_XXX[1] nvoOutputWrd_XXX SNVT_count_f
Number of Pumps AI 3 AI 3 30023 LCS_AI_XXX[2] nvoNumPmps_XXX SNVT_count_f
Analog In 1 Scaled Value AI 4 AI 4 30024-25 LCS_AR_XXX[0] nvoAI1SclVal_XXX SNVT_count_f
Analog In 2 Scaled Value AI 5 AI 5 30026-27 LCS_AR_XXX[1] nvoAI2SclVal_XXX SNVT_count_f
PID Output Scaled Value AI 6 AI 6 30028-29 LCS_AR_XXX[2] nvoPIDOtScVl_XXX SNVT_count_f
PID PV Scaled Value AI 7 AI 7 30030-31 LCS_AR_XXX[3] nvoPIDPVScVl_XXX SNVT_count_f
PID SP Scaled Value AI 8 AI 8 30032-33 LCS_AR_XXX[4] nvoPIDSPScVl_XXX SNVT_count_f
Lead Pump Number AI 9 AI 9 30034 LCS_AI_XXX[3] nvoLdPmpNum_XXX SNVT_count_f
Lag1 Pump Number AI 10 AI 10 30035 LCS_AI_XXX[4] nvoLag1PmpNm_XXX SNVT_count_f
Lag2 Pump Number AI 11 AI 11 30036 LCS_AI_XXX[5] nvoLag2PmpNm_XXX SNVT_count_f
Lag3 Pump Number AI 12 AI 12 30037 LCS_AI_XXX[6] nvoLag3PmpNm_XXX SNVT_count_f
Pump 1 Run Input BI 1 DI 1 10001 LCS_AB_XXX[0].0 nvoP1RunInpt_XXX SNVT_switch
Pump 2 Run Input BI 2 DI 2 10002 LCS_AB_XXX[0].1 nvoP2RunInpt_XXX SNVT_switch
Pump 3 Run Input BI 3 DI 3 10003 LCS_AB_XXX[0].2 nvoP3RunInpt_XXX SNVT_switch
Pump 4 Run Input BI 4 DI 4 10004 LCS_AB_XXX[0].3 nvoP4RunInpt_XXX SNVT_switch
Pump 1 Auto Input BI 5 DI 5 10005 LCS_AB_XXX[0].4 nvoP1AutInpt_XXX SNVT_switch
Pump 2 Auto Input BI 6 DI 6 10006 LCS_AB_XXX[0].5 nvoP2AutInpt_XXX SNVT_switch
Pump 3 Auto Input BI 7 DI 7 10007 LCS_AB_XXX[0].6 nvoP3AutInpt_XXX SNVT_switch
Pump 4 Auto Input BI 8 DI 8 10008 LCS_AB_XXX[0].7 nvoP4AutInpt_XXX SNVT_switch
Pump Run Request BI 9 DI 9 10009 LCS_AB_XXX[0].8 nvoPmpRunReq_XXX SNVT_switch
30021_9 BI 10 DI 10 10010 LCS_AB_XXX[0].9 nvo30021_9_XXX SNVT_switch
30021_10 BI 11 DI 11 10011 LCS_AB_XXX[0].10 nvo30021_10_XXX SNVT_switch
30021_11 BI 12 DI 12 10012 LCS_AB_XXX[0].11 nvo30021_11_XXX SNVT_switch
30021_12 BI 13 DI 13 10013 LCS_AB_XXX[0].12 nvo30021_12_XXX SNVT_switch
30021_13 BI 14 DI 14 10014 LCS_AB_XXX[0].13 nvo30021_13_XXX SNVT_switch
30021_14 BI 15 DI 15 10015 LCS_AB_XXX[0].14 nvo30021_14_XXX SNVT_switch
30021_15 BI 16 DI 16 10016 LCS_AB_XXX[0].15 nvo30021_15_XXX SNVT_switch
Pump 1 Run Output BI 17 DI 17 10017 LCS_AB_XXX[1].0 nvoP1RunOut_XXX SNVT_switch
Pump 2 Run Output BI 18 DI 18 10018 LCS_AB_XXX[1].1 nvoP2RunOut_XXX SNVT_switch
Pump 3 Run Output BI 19 DI 19 10019 LCS_AB_XXX[1].2 nvoP3RunOut_XXX SNVT_switch
Pump 4 Run Output BI 20 DI 20 10020 LCS_AB_XXX[1].3 nvoP4RunOut_XXX SNVT_switch
Alarm Output BI 21 DI 21 10021 LCS_AB_XXX[1].4 nvoAlarmOut_XXX SNVT_switch
Alarm Blinker BI 22 DI 22 10022 LCS_AB_XXX[1].5 nvoAlmBlnkr_XXX SNVT_switch
Pumps Off BI 23 DI 23 10023 LCS_AB_XXX[1].6 nvoPmpsOff_XXX SNVT_switch
30022_7 BI 24 DI 24 10024 LCS_AB_XXX[1].7 nvo30022_7_XXX SNVT_switch
30022_8 BI 25 DI 25 10025 LCS_AB_XXX[1].8 nvo30022_8_XXX SNVT_switch
30022_9 BI 26 DI 26 10026 LCS_AB_XXX[1].9 nvo30022_9_XXX SNVT_switch
30022_10 BI 27 DI 27 10027 LCS_AB_XXX[1].10 nvo30022_10_XXX SNVT_switch
30022_11 BI 28 DI 28 10028 LCS_AB_XXX[1].11 nvo30022_11_XXX SNVT_switch
30022_12 BI 29 DI 29 10029 LCS_AB_XXX[1].12 nvo30022_12_XXX SNVT_switch
30022_13 BI 30 DI 30 10030 LCS_AB_XXX[1].13 nvo30022_13_XXX SNVT_switch
30022_14 BI 31 DI 31 10031 LCS_AB_XXX[1].14 nvo30022_14_XXX SNVT_switch
OAT Pumps Off BI 32 DI 32 10032 LCS_AB_XXX[1].15 nviOATPmpOff_XXX SNVT_switch
Remote Setpoint Write AV 1 AO 1 40021-22 LCS_AWR_XXX[0] nviRemSPWr_XXX SNVT_count_f
Modulation Output Override AV 2 AO 2 40029-30 LCS_AWR_XXX[1] nviModOtOvrd_XXX SNVT_count_f
Heartbeat Write Tag AV 3 AO 3 40025 LCS_AWI_XXX[1] nviHrtBtWrt_XXX SNVT_count_f
