ProtoNode Gateway
48 750-426
B.2. FALCON STEAM
FALCON STEAM Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object
Id
N2
Data
Type
N2
Point
Address
Modbus
Register
(Bit) EIP Tag Name Lon Name Lon SNVT Type
PumpA BI 1 DI 1 30003 0 CFS_AB[0].0 nvoPumpA_XXX SNVT_switch
PumpA BI 1 DI 1 30003 0 CFS_AB_XXX[0].0 nvoPumpA_XXX SNVT_switch
PumpB BI 2 DI 2 30003 1 CFS_AB_XXX[0].1 nvoPumpB_XXX SNVT_switch
PumpC BI 3 DI 3 30003 2 CFS_AB_XXX[0].2 nvoPumpC_XXX SNVT_switch
Blower_Mtr BI 4 DI 4 30003 3 CFS_AB_XXX[0].3 nvoBlwr_Mtr_XXX SNVT_switch
Ext_Ignition BI 5 DI 5 30003 4 CFS_AB_XXX[0].4 nvoExt_Ign_XXX SNVT_switch
Pilot_Valve BI 6 DI 6 30003 5 CFS_AB_XXX[0].5 nvoPilotVlv_XXX SNVT_switch
Main_Valve BI 7 DI 7 30003 6 CFS_AB_XXX[0].6 nvoMainValve_XXX SNVT_switch
Alarm BI 8 DI 8 30003 7 CFS_AB_XXX[0].7 nvoAlarm_XXX SNVT_switch
Interlock BI 9 DI 9 30003 8 CFS_AB_XXX[0].8 nvoInterlock_XXX SNVT_switch
PreIgn_Interlock BI 10 DI 10 30003 9 CFS_AB_XXX[0].9 nvoPreIgnInt_XXX SNVT_switch
Load_Control_In BI 11 DI 11 30003 10 CFS_AB_XXX[0].10 nvoLdCtrlIn_XXX SNVT_switch
Low_Fire_Switch BI 12 DI 12 30003 11 CFS_AB_XXX[0].11 nvoLoFireSw_XXX SNVT_switch
High_Fire_Switch BI 13 DI 13 30003 12 CFS_AB_XXX[0].12 nvoHiFireSw_XXX SNVT_switch
Stat_Demand BI 14 DI 14 30003 13 CFS_AB_XXX[0].13 nvoStatDem_XXX SNVT_switch
TimeOfDay BI 15 DI 15 30003 14 CFS_AB_XXX[0].14 nvoTimeOfDay_XXX SNVT_switch
Safety_Relay BI 16 DI 16 30003 15 CFS_AB_XXX[0].15 nvoSafetyRel_XXX SNVT_switch
Int_Air_Switch BI 17 DI 17 30004 0 CFS_AB_XXX[1].0 nvoIntAirSw_XXX SNVT_switch
Low_Water BI 18 DI 18 30004 1 CFS_AB_XXX[1].1 nvoLoWater_XXX SNVT_switch
Aux_Low_Water BI 19 DI 19 30004 2 CFS_AB_XXX[1].2 nvoAuxLoWtr_XXX SNVT_switch
High_Limit BI 20 DI 20 30004 3 CFS_AB_XXX[1].3 nvoHiLimit_XXX SNVT_switch
High_Gas_Press BI 21 DI 21 30004 4 CFS_AB_XXX[1].4 nvoHiGasPrs_XXX SNVT_switch
Low_Gas_Press BI 22 DI 22 30004 5 CFS_AB_XXX[1].5 nvoLoGasPrs_XXX SNVT_switch
High_Water BI 23 DI 23 30004 6 CFS_AB_XXX[1].6 nvoHigh_Wtr_XXX SNVT_switch
Feed_Water BI 24 DI 24 30004 7 CFS_AB_XXX[1].7 nvoFeed_Wtr_XXX SNVT_switch
DEMAND SOURCE AI 1 AI 1 30007 CFS_AI_XXX[0] nvoDemSrc_XXX SNVT_count_f
FIRING_RATE AI 2 AI 2 30009 CFS_AI_XXX[1] nvoFiringRat_XXX SNVT_count_f
FAN_SPEED AI 3 AI 3 30010 CFS_AI_XXX[2] nvoFanSpeed_XXX SNVT_count_f
FLAME_SIGNAL AI 4 AI 4 30011 CFS_AI_XXX[3] nvoFlameSig_XXX SNVT_count_f
STEAM_PRESSURE AI 5 AI 5 30021 CFS_AI_XXX[4] nvoStmPress_XXX SNVT_count_f
ANALOG_INPUT AI 6 AI 6 30022 CFS_AI_XXX[5] nvoAna_Input_XXX SNVT_count_f
ACTIVE_STEAM_SP AI 7 AI 7 30023 CFS_AI_XXX[6] nvoActStmSP_XXX SNVT_count_f
BURN_CTL_STATUS AI 8 AI 8 30033 CFS_AI_XXX[7] nvoBrnCtStat_XXX SNVT_count_f
BURN_CTL_STATE AI 9 AI 9 30034 CFS_AI_XXX[8] nvoBrnCtlSte_XXX SNVT_count_f
LOCKOUT_CODE AI 10 AI 10 30035 CFS_AI_XXX[9] nvoLockoutCd_XXX SNVT_count_f
HOLD_CODE AI 11 AI 11 30041 CFS_AI_XXX[10] nvoHoldCode_XXX SNVT_count_f
CYCLE_COUNT AI 12 AI 12 30129-
30
CFS_AI_XXX[11] nvoCycCount_XXX SNVT_count_f
RUN_TIME AI 13 AI 13 30131-
32
CFS_AI_XXX[12] nvoRunTime_XXX SNVT_count_f
BURNER_ENABLE AI 16 AI 16 30204 CFS_AI_XXX[13] nvoBrnrEnbl_XXX SNVT_count_f
STEAM_PRESSURE_SETPOINT AI 14 AI 14 30221 CFS_AI_XXX[14] nvoStmPrsSP_XXX SNVT_count_f
LEAD/LAG_STEAM_PRESS_SET
POINT
AI 15 AI 15 30739 CFS_AI_XXX[15] nvoLLStmPrSP_XXX SNVT_count_f
LEAD/LAG_HEADER_STEAM_PRESS AI 17 AI 17 30807 CFS_AI_XXX[16] nvoLLHdStmPr_XXX SNVT_count_f
VESSEL WATER TEMP (Deg C) AI 18 AI 18 30008 CFS_AR_XXX[0] nvoVesWtrTmp_XXX SNVT_temp_p
VESSEL WATER TEMP (Deg F) AI 19 AI 19 30008 CFS_AR_XXX[1]
*
BURNER ENABLE AV 1 AO 1 40204 CFS_AWI_XXX[0] nviBrnrEnbl_XXX SNVT_count_f
*
STEAM_PRESSURE_SETPOINT AV 21 AO 21 40221 CFS_AWI_XXX[1] nviStmPrsSP_XXX SNVT_count_f
