B.16. SHARK 200
Shark 200 Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object
Id
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon Name Lon SNVT Type
Volts A-N AI 1 AI 1 41000 S200_AR_XXX[0] nvoVolts_AN_XXX SNVT_count_inc_f
Volts B-N AI 2 AI 2 41002 S200_AR_XXX[1] nvoVolts_BN_XXX SNVT_count_inc_f
Volts C-N AI 3 AI 3 41004 S200_AR_XXX[2] nvoVolts_CN_XXX SNVT_count_inc_f
Volts A-B AI 4 AI 4 41006 S200_AR_XXX[3] nvoVolts_AB_XXX SNVT_count_inc_f
Volts B-C AI 5 AI 5 41008 S200_AR_XXX[4] nvoVolts_BC_XXX SNVT_count_inc_f
Volts C-A AI 6 AI 6 41010 S200_AR_XXX[5] nvoVolts_CA_XXX SNVT_count_inc_f
Amps A AI 7 AI 7 41012 S200_AR_XXX[6] nvoAmps_A_XXX SNVT_count_inc_f
Amps B AI 8 AI 8 41014 S200_AR_XXX[7] nvoAmps_B_XXX SNVT_count_inc_f
Amps C AI 9 AI 9 41016 S200_AR_XXX[8] nvoAmps_C_XXX SNVT_count_inc_f
Watts 3-Ph total AI 10 AI 10 41018 S200_AR_XXX[9] nvoWatt3PhTo_XXX SNVT_count_inc_f
VARs 3-Ph total AI 11 AI 11 41020 S200_AR_XXX[10] nvoVAR3PhTot_XXX SNVT_count_inc_f
VAs 3-Ph total AI 12 AI 12 41022 S200_AR_XXX[11] nvoVA_3PhTot_XXX SNVT_count_inc_f
Power Factor 3-Ph total AI 13 AI 13 41024 S200_AR_XXX[12] nvoPF_3PhTot_XXX SNVT_count_inc_f
Frequency AI 14 AI 14 41026 S200_AR_XXX[13] nvoFreq_XXX SNVT_count_inc_f
Neutral Current AI 15 AI 15 41028 S200_AR_XXX[14] nvoNeut_Crnt_XXX SNVT_count_inc_f
Watts Phase A AI 16 AI 16 41030 S200_AR_XXX[15] nvoWatts_PhA_XXX SNVT_count_inc_f
Watts Phase B AI 17 AI 17 41032 S200_AR_XXX[16] nvoWatts_PhB_XXX SNVT_count_inc_f
Watts Phase C AI 18 AI 18 41034 S200_AR_XXX[17] nvoWatts_PhC_XXX SNVT_count_inc_f
VARs Phase A AI 19 AI 19 41036 S200_AR_XXX[18] nvoVARs_PhA_XXX SNVT_count_inc_f
VARs Phase B AI 20 AI 20 41038 S200_AR_XXX[19] nvoVARs_PhB_XXX SNVT_count_inc_f
VARs Phase C AI 21 AI 21 41040 S200_AR_XXX[20] nvoVARs_PhC_XXX SNVT_count_inc_f
VAs Phase A AI 22 AI 22 41042 S200_AR_XXX[21] nvoVAs_PhA_XXX SNVT_count_inc_f
VAs Phase B AI 23 AI 23 41044 S200_AR_XXX[22] nvoVAs_PhB_XXX SNVT_count_inc_f
VAs Phase C AI 24 AI 24 41046 S200_AR_XXX[23] nvoVAs_PhC_XXX SNVT_count_inc_f
Power Factor Phase A AI 25 AI 25 41048 S200_AR_XXX[24] nvoPF_PhA_XXX SNVT_count_inc_f
Power Factor Phase B AI 26 AI 26 41050 S200_AR_XXX[25] nvoPF_PhB_XXX SNVT_count_inc_f
Power Factor Phase C AI 27 AI 27 41052 S200_AR_XXX[26] nvoPF_PhC_XXX SNVT_count_inc_f
W-hours Received AI 28 AI 28 41500 S200_AD_XXX[0] nvoWh_Rec_XXX SNVT_count_inc_f
W-hours Delivered AI 29 AI 29 41502 S200_AD_XXX[1] nvoWh_Del_XXX SNVT_count_inc_f
W-hours Net AI 30 AI 30 41504 S200_AD_XXX[2] nvoWh_Net_XXX SNVT_count_inc_f
W-hours Total AI 31 AI 31 41506 S200_AD_XXX[3] nvoWh_Tot_XXX SNVT_count_inc_f
VAR-hours Positive AI 32 AI 32 41508 S200_AD_XXX[4] nvoVARh_Pos_XXX SNVT_count_inc_f
VAR-hours Negative AI 33 AI 33 41510 S200_AD_XXX[5] nvoVARh_Neg_XXX SNVT_count_inc_f
VAR-hours Net AI 34 AI 34 41512 S200_AD_XXX[6] nvoVARh_Net_XXX SNVT_count_inc_f
VAR-hours Total AI 35 AI 35 41514 S200_AD_XXX[7] nvoVARh_Tot_XXX SNVT_count_inc_f
Amps A Avg AI 36 AI 36 42000 S200_AR_XXX[27] nvoAmpA_Avg_XXX SNVT_count_inc_f
Amps B Avg AI 37 AI 37 42002 S200_AR_XXX[28] nvoAmpB_Avg_XXX SNVT_count_inc_f
Amps C Avg AI 38 AI 38 42004 S200_AR_XXX[29] nvoAmpC_Avg_XXX SNVT_count_inc_f
Positive Watts 3-Ph Avg AI 39 AI 39 42006 S200_AR_XXX[30] nvoPsWat3PAv_XXX SNVT_count_inc_f
Positive VARs 3-Ph Avg AI 40 AI 40 42008 S200_AR_XXX[31] nvoPsVAR3PAv_XXX SNVT_count_inc_f
Negative Watts 3-Ph Avg AI 41 AI 41 42010 S200_AR_XXX[32] nvoNgWat3PAv_XXX SNVT_count_inc_f
Negative VARs 3-Ph Avg AI 42 AI 42 42012 S200_AR_XXX[33] nvoNgVAR3PAv_XXX SNVT_count_inc_f
VAs 3-Ph Avg AI 43 AI 43 42014 S200_AR_XXX[34] nvoVA_3PhAvg_XXX SNVT_count_inc_f
Positive PF 3-Ph Avg AI 44 AI 44 42016 S200_AR_XXX[35] nvoPsPF3PhAv_XXX SNVT_count_inc_f
Negative PF 3-PF Avg AI 45 AI 45 42018 S200_AR_XXX[36] nvoNgPF3PhAv_XXX SNVT_count_inc_f
VA-hours Total AI 46 AI 46 43048 S200_AD_XXX[8] nvoVAh_Tot_XXX SNVT_count_inc_f
Positive Watts 3-Ph Max Avg Demand AI 51 AI 51 49018 S200_AR_XXX[37] nvoPWt3PMADm_XXX SNVT_count_inc_f
Positive VARs 3-Ph Max Avg Demand AI 52 AI 52 49020 S200_AR_XXX[38] nvoPVr3PMADm_XXX SNVT_count_inc_f
Negative Watts 3-Ph Max Avg Demand AI 53 AI 53 49022 S200_AR_XXX[39] nvoNWt3PMADm_XXX SNVT_count_inc_f
Negative VARs 3-Ph Max Avg Demand AI 54 AI 54 49024 S200_AR_XXX[40] nvoNVr3PMADm_XXX SNVT_count_inc_f
