CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 61
B.6. LCS
LCS Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon Name Lon SNVT Type
Tank 1 Level AI 101 AI 1 40050 LCS_AI_XXX[0] nvoTnk1Lvl_XXX SNVT_count_inc
Tank 2 Level AI 102 AI 2 40051 LCS_AI_XXX[1] nvoTnk2Lvl_XXX SNVT_count_inc
Primary Valve Postion AI 103 AI 3 40052 LCS_AI_XXX[2] nvoPriVlvPos_XXX SNVT_lev_percent
Secondary Valve Postion AI 104 AI 4 40053 LCS_AI_XXX[3] nvoSecVlvPos_XXX SNVT_lev_percent
Digital Inputs AI 105 AI 5 40054 LCS_AI_XXX[4] nvoDigInputs_XXX SNVT_count
Digital Outputs AI 106 AI 6 40055 LCS_AI_XXX[5] nvoDigOutpts_XXX SNVT_count
Alarm Word AI 107 AI 7 40056 LCS_AI_XXX[6] nvoAlmWord_XXX SNVT_count
Tank 1 Level Setpoint AI 108 AI 8 40057 LCS_AI_XXX[7] nvoTnk1LvlSP_XXX SNVT_count_inc
Tank 2 Level Setpoint AI 109 AI 9 40058 LCS_AI_XXX[8] nvoTnk2LvlSP_XXX SNVT_count_inc
Common Alarm BI 230 DI 30 10001 LCS_AB_XXX[0].0 nvoCommonAlm_XXX SNVT_switch
Tank 1 LWCO Alarm BI 231 DI 31 10002 LCS_AB_XXX[0].1 nvoT1LWCOAlm_XXX SNVT_switch
Tank 1 LLW Alarm BI 232 DI 32 10003 LCS_AB_XXX[0].2 nvoT1LLWAlm_XXX SNVT_switch
Tank 1 LW Alarm BI 233 DI 33 10004 LCS_AB_XXX[0].3 nvoT1LWAlm_XXX SNVT_switch
Tank 1 HW Alarm BI 234 DI 34 10005 LCS_AB_XXX[0].4 nvoT1HWAlm_XXX SNVT_switch
Tank 1 HHW Alarm BI 235 DI 35 10006 LCS_AB_XXX[0].5 nvoT1HHWAlm_XXX SNVT_switch
Tank 2 LWCO Alarm BI 236 DI 36 10007 LCS_AB_XXX[0].6 nvoT2LWCOAlm_XXX SNVT_switch
Tank 2 LLW Alarm BI 237 DI 37 10008 LCS_AB_XXX[0].7 nvoT2LLWAlm_XXX SNVT_switch
Tank 2 LW Alarm BI 238 DI 38 10009 LCS_AB_XXX[0].8 nvoT2LWAlm_XXX SNVT_switch
Tank 2 HW Alarm BI 239 DI 39 10010 LCS_AB_XXX[0].9 nvoT2HWAlm_XXX SNVT_switch
Tank 2 HHW Alarm BI 240 DI 40 10011 LCS_AB_XXX[0].10 nvoT2HHWAlm_XXX SNVT_switch
Analog In Failure BI 241 DI 41 10012 LCS_AB_XXX[0].11 nvoAI_Fail_XXX SNVT_switch
Spare Alarm Bit 40056_12 BI 242 DI 42 10013 LCS_AB_XXX[0].12 nvoAlBt56_12_XXX SNVT_switch
Spare Alarm Bit 40056_13 BI 243 DI 43 10014 LCS_AB_XXX[0].13 nvoAlBt56_13_XXX SNVT_switch
Spare Alarm Bit 40056_14 BI 244 DI 44 10015 LCS_AB_XXX[0].14 nvoAlBt56_14_XXX SNVT_switch
Spare Alarm Bit 40056_15 BI 245 DI 45 10016 LCS_AB_XXX[0].15 nvoAlBt56_15_XXX SNVT_switch
Tank 1 LWCO Contacts BI 246 DI 46 10017 LCS_AB_XXX[1].0 nvoT1LWCOCnt_XXX SNVT_switch
Tank 1 LLW Contacts BI 247 DI 47 10018 LCS_AB_XXX[1].1 nvoT1LLWCnt_XXX SNVT_switch
Tank 1 LW Contacts BI 248 DI 48 10019 LCS_AB_XXX[1].2 nvoT1LWCnt_XXX SNVT_switch
Tank 1 HW Contacts BI 249 DI 49 10020 LCS_AB_XXX[1].3 nvoT1HWCnt_XXX SNVT_switch
Tank 1 HHW Contacts BI 250 DI 50 10021 LCS_AB_XXX[1].4 nvoT1HHWCnt_XXX SNVT_switch
Tank 2 LWCO Contacts BI 251 DI 51 10022 LCS_AB_XXX[1].5 nvoT2LWCOCnt_XXX SNVT_switch
Tank 2 LLW Contacts BI 252 DI 52 10023 LCS_AB_XXX[1].6 nvoT2LLWCnt_XXX SNVT_switch
Tank 2 LW Contacts BI 253 DI 53 10024 LCS_AB_XXX[1].7 nvoT2LWCnt_XXX SNVT_switch
Tank 2 HW Contacts BI 254 DI 54 10025 LCS_AB_XXX[1].8 nvoT2HWCnt_XXX SNVT_switch
Tank 2 HHW Contacts BI 255 DI 55 10026 LCS_AB_XXX[1].9 nvoT2HHWCnt_XXX SNVT_switch
Digital Input 1 Status BI 256 DI 56 10027 LCS_AB_XXX[2].0 nvoDI1Status_XXX SNVT_switch
Digital Input 2 Status BI 257 DI 57 10028 LCS_AB_XXX[2].1 nvoDI2Status_XXX SNVT_switch
Digital Input 3 Status BI 258 DI 58 10029 LCS_AB_XXX[2].2 nvoDI3Status_XXX SNVT_switch
Digital Input 4 Status BI 259 DI 59 10030 LCS_AB_XXX[2].3 nvoDI4Status_XXX SNVT_switch
Digital Input 5 Status BI 260 DI 60 10031 LCS_AB_XXX[2].4 nvoDI5Status_XXX SNVT_switch
Digital Input 6 Status BI 261 DI 61 10032 LCS_AB_XXX[2].5 nvoDI6Status_XXX SNVT_switch
Digital Input 7 Status BI 262 DI 62 10033 LCS_AB_XXX[2].6 nvoDI7Status_XXX SNVT_switch
Digital Input 8 Status BI 263 DI 63 10034 LCS_AB_XXX[2].7 nvoDI8Status_XXX SNVT_switch
Digital Input 9 Status BI 264 DI 64 10035 LCS_AB_XXX[2].8 nvoDI9Status_XXX SNVT_switch
Digital Input 10 Status BI 265 DI 65 10036 LCS_AB_XXX[2].9 nvoDI10Stat_XXX SNVT_switch
Digital Input 11 Status BI 266 DI 66 10037 LCS_AB_XXX[2].10 nvoDI11Stat_XXX SNVT_switch
Digital Input 12 Status BI 267 DI 67 10038 LCS_AB_XXX[2].11 nvoDI12Stat_XXX SNVT_switch
Digital Output 1 Status BI 268 DI 68 10039 LCS_AB_XXX[2].12 nvoDO1Status_XXX SNVT_switch
Digital Output 2 Status BI 269 DI 69 10040 LCS_AB_XXX[2].13 nvoDO2Status_XXX SNVT_switch
Digital Output 3 Status BI 270 DI 70 10041 LCS_AB_XXX[3].0 nvoDO3Status_XXX SNVT_switch
Digital Output 4 Status BI 271 DI 71 10042 LCS_AB_XXX[3].1 nvoDO4Status_XXX SNVT_switch
Digital Output 5 Status BI 272 DI 72 10043 LCS_AB_XXX[3].2 nvoDO5Status_XXX SNVT_switch
Digital Output 6 Status BI 273 DI 73 10044 LCS_AB_XXX[3].3 nvoDO6Status_XXX SNVT_switch
Digital Output 7 Status BI 274 DI 74 10045 LCS_AB_XXX[3].4 nvoDO7Status_XXX SNVT_switch
Digital Output 8 Status BI 275 DI 75 10046 LCS_AB_XXX[3].5 nvoDO8Status_XXX SNVT_switch
Digital Output 9 Status BI 276 DI 76 10047 LCS_AB_XXX[3].6 nvoDO9Status_XXX SNVT_switch
Digital Output 10 Status BI 277 DI 77 10048 LCS_AB_XXX[3].7 nvoDO10Stat_XXX SNVT_switch
Digital Output 11 Status BI 278 DI 78 10049 LCS_AB_XXX[3].8 nvoDO11Stat_XXX SNVT_switch
Digital Output 12 Status BI 279 DI 79 10050 LCS_AB_XXX[3].9 nvoDO12Stat_XXX SNVT_switch
