ProtoNode Gateway
52 750-426
B.4. CB120
CB120 Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
(Bit) EIP Tag Name Lon Name Lon SNVT Type
Safety_Relay BI 1 DI 1 40007 0 CB120_AB[0].0 nvoSafetyRel_XXX SNVT_switch
Main_Valve_In BI 2 DI 2 40007 1 CB120_AB[0].1 nvoMainVlvIn_XXX SNVT_switch
Delayed_Valve_In BI 3 DI 3 40007 2 CB120_AB[0].2 nvoDelVlvIn_XXX SNVT_switch
Pilot_Valve_In BI 4 DI 4 40007 3 CB120_AB[0].3 nvoPltVlvIn_XXX SNVT_switch
Ignition_In BI 5 DI 5 40007 4 CB120_AB[0].4 nvoIgnitnIn_XXX SNVT_switch
Blower_In BI 6 DI 6 40007 5 CB120_AB[0].5 nvoBlowerIn_XXX SNVT_switch
Op_Cntrl BI 7 DI 7 40007 6 CB120_AB[0].6 nvoOpCntrl_XXX SNVT_switch
Run_Intlck BI 8 DI 8 40007 7 CB120_AB[0].7 nvoRunIntlck_XXX SNVT_switch
LAG1 BI 9 DI 9 40007 8 CB120_AB[0].8 nvoLAG1_XXX SNVT_switch
LAG2 BI 10 DI 10 40007 11 CB120_AB[0].11 nvoLAG2_XXX SNVT_switch
Fuel_Vlv_POC BI 11 DI 11 40007 12 CB120_AB[0].12 nvoFuelVlPOC_XXX SNVT_switch
High_Fire_Intlck BI 12 DI 12 40007 13 CB120_AB[0].13 nvoHiFirIntl_XXX SNVT_switch
Low_Fire_Start BI 13 DI 13 40007 14 CB120_AB[0].14 nvoLoFirStrt_XXX SNVT_switch
Ref_AC_Line BI 14 DI 14 40007 15 CB120_AB[0].15 nvoRefACLine_XXX SNVT_switch
Ignition_Out BI 15 DI 15 40008 1 CB120_AB[1].1 nvoIgnOut_XXX SNVT_switch
Pilot_Valve_Out BI 16 DI 16 40008 2 CB120_AB[1].2 nvoPltVlvOut_XXX SNVT_switch
Blower_Out BI 17 DI 17 40008 3 CB120_AB[1].3 nvoBLoerOut_XXX SNVT_switch
Main_Valve_Out BI 18 DI 18 40008 4 CB120_AB[1].4 nvoMnVlvOut_XXX SNVT_switch
Delayed_Valve_Out BI 19 DI 19 40008 5 CB120_AB[1].5 nvoDelVlvOut_XXX SNVT_switch
Internal_Safety_Out BI 20 DI 20 40008 6 CB120_AB[1].6 nvoIntSftOut_XXX SNVT_switch
LowFireOut BI 21 DI 21 40008 8 CB120_AB[1].8 nvoLoFireOut_XXX SNVT_switch
HighFireOut BI 22 DI 22 40008 9 CB120_AB[1].9 nvoHiFireOut_XXX SNVT_switch
Rel_to_ModOut BI 23 DI 23 40008 10 CB120_AB[1].10 nvoRelModOut_XXX SNVT_switch
Alarm_Out BI 24 DI 24 40008 11 CB120_AB[1].11 nvoAlmOut_XXX SNVT_switch
Status AI 1 AI 1 40001 CB120_AI[0] nvoStatus_XXX SNVT_count_f
Msgn AI 2 AI 2 40002 CB120_AI[1] nvoMsgn_XXX SNVT_count_f
Gstat AI 3 AI 3 40003 CB120_AI[2] nvoGstat_XXX SNVT_count_f
Timer AI 4 AI 4 40004 CB120_AI[3] nvoTimer_XXX SNVT_count_f
Flame AI 5 AI 5 40005 CB120_AI[4] nvoFlame_XXX SNVT_count_f
Logstat AI 6 AI 6 40006 CB120_AI[5] nvoLogstat_XXX SNVT_count_f
Lockout_Count AI 7 AI 7 40015 CB120_AI[6] nvoLockotCnt_XXX SNVT_count_f
Sysmins AI 8 AI 8 40009-10 CB120_AD[0] nvoSysmins_XXX SNVT_time_min
Bnrmins AI 9 AI 9 40011-12 CB120_AD[1] nvoBnrmins_XXX SNVT_time_min
Cycles AI 10 AI 10 40013-14 CB120_AD[2] nvoCycles_XXX SNVT_count_f
LOCKOUT1_MSG AI 11 AI 11 40016 CB120_AI[7] nvoLkot1Msg_XXX SNVT_count_f
LOCKOUT1_MODULE AI 12 AI 12 40017 CB120_AI[8] nvoLkot1Mod_XXX SNVT_count_f
LOCKOUT2_MSG AI 13 AI 13 40022 CB120_AI[9] nvoLkot2Msg_XXX SNVT_count_f
LOCKOUT2_MODULE AI 14 AI 14 40023 CB120_AI[10] nvoLkot2Mod_XXX SNVT_count_f
LOCKOUT3_MSG AI 15 AI 15 40028 CB120_AI[11] nvoLkot3Msg_XXX SNVT_count_f
LOCKOUT3_MODULE AI 16 AI 16 40029 CB120_AI[12] nvoLkot3Mod_XXX SNVT_count_f
LOCKOUT4_MSG AI 17 AI 17 40034 CB120_AI[13] nvoLkot4Msg_XXX SNVT_count_f
LOCKOUT4_MODULE AI 18 AI 18 40035 CB120_AI[14] nvoLkot4Mod_XXX SNVT_count_f
LOCKOUT5_MSG AI 19 AI 19 40040 CB120_AI[15] nvoLkot5Msg_XXX SNVT_count_f
LOCKOUT5_MODULE AI 20 AI 20 40041 CB120_AI[16] nvoLkot5Mod_XXX SNVT_count_f
LOCKOUT6_MSG AI 21 AI 21 40046 CB120_AI[17] nvoLkot6Msg_XXX SNVT_count_f
LOCKOUT6_MODULE AI 22 AI 22 40047 CB120_AI[18] nvoLkot6Mod_XXX SNVT_count_f
LOCKOUT7_MSG AI 23 AI 23 40052 CB120_AI[19] nvoLkot7Msg_XXX SNVT_count_f
LOCKOUT7_MODULE AI 24 AI 24 40053 CB120_AI[20] nvoLkot7Mod_XXX SNVT_count_f
LOCKOUT8_MSG AI 25 AI 25 40058 CB120_AI[21] nvoLkot8Msg_XXX SNVT_count_f
