ProtoNode Gateway
750-426 21
4. WEB CONFIGURATOR
Use Protonode's Web Configurator to set up the gateway.
4.1 Connect the PC to ProtoNode via the Ethernet Port
FIGURE 19 - Ethernet Port
• Connect a standard CAT5 Ethernet cable (Straight through or Cross-Over) between the PC and ProtoNode.
• The Default IP Address of ProtoNode is 192.168.1.24, Subnet Mask is 255.255.255.0. If the PC and
ProtoNode are on different IP Networks, assign a static IP Address to the PC on the 192.168.1.xxx net-
work.
• For Windows 10:
Right click on > > >
>
Right-click on Local Area Connection > Properties
Highlight >
Use the following IP Address:
Click twice.
Ethernet
port
