ProtoNode Gateway
50 750-426
B.3. CB780
CB780 Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
(Bit) EIP Tag Name Lon Name Lon SNVT Type
BC_Initiate BI 1 DI 1 40013 0 CB780_AB[0].0 nvoBCInitiat_XXX SNVT_switch
BC_Standby BI 2 DI 2 40013 1 CB780_AB[0].1 nvoBCStandby_XXX SNVT_switch
BC_Purge BI 3 DI 3 40013 2 CB780_AB[0].2 nvoBCPurge_XXX SNVT_switch
BC_Pilot_Ignition BI 4 DI 4 40013 3 CB780_AB[0].3 nvoBCPlt_Ign_XXX SNVT_switch
BC_Main_Ignition BI 5 DI 5 40013 4 CB780_AB[0].4 nvoBCMainIgn_XXX SNVT_switch
BC_Run_Mode BI 6 DI 6 40013 5 CB780_AB[0].5 nvoBCRunMode_XXX SNVT_switch
BC_Postpurge BI 7 DI 7 40013 6 CB780_AB[0].6 nvoBCPostprg_XXX SNVT_switch
BC_Preignition BI 8 DI 8 40013 7 CB780_AB[0].7 nvoBCPreIgn_XXX SNVT_switch
BC_Alarm_Out BI 9 DI 9 40013 13 CB780_AB[0].13 nvoBCAlmOut_XXX SNVT_switch
BC_Lockout BI 10 DI 10 40013 15 CB780_AB[0].15 nvoBCLockout_XXX SNVT_switch
BC_Fault_Code AI 1 AI 1 40001 CB780_AI[0] nvoBCFltCode_XXX SNVT_count_f
BC_Fault_String_Code AI 2 AI 2 40002 CB780_AI[1] nvoBCFltStCd_XXX SNVT_count_f
BC_Sequence_State AI 3 AI 3 40003 CB780_AI[2] nvoBCSeqSt_XXX SNVT_count_f
BC_State_String_Code_L1 AI 4 AI 4 40004 CB780_AI[3] nvoBCStCdL1_XXX SNVT_count_f
BC_State_String_Code_L2 AI 5 AI 5 40005 CB780_AI[4] nvoBCStCdL2_XXX SNVT_count_f
BC_Sequence_Time AI 6 AI 6 40006 CB780_AI[5] nvoBCSeqTime_XXX SNVT_count_f
BC_Flame_Signal_Strength AI 7 AI 7 40011 CB780_AI[6] nvoBCFlSgStr_XXX SNVT_count_f
BC_State_Bits AI 8 AI 8 40013 CB780_AI[7] nvoBCStatBts_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec1 AI 9 AI 9 40017 CB780_AI[8] nvoBCFlCdRc1_XXX SNVT_count_f
BC_Flt_Hist_String_Rec1 AI 10 AI 10 40018 CB780_AI[9] nvoBCFlSgRc1_XXX SNVT_count_f
BC_Flt_Hist_State_Rec1 AI 11 AI 11 40019 CB780_AI[10] nvoBCFlStRc1_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec1 AI 12 AI 12 40020 CB780_AI[11] nvoBCFlL1Rc1_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec1 AI 13 AI 13 40021 CB780_AI[12] nvoBCFlL2Rc1_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec1 AI 14 AI 14 40022 CB780_AI[13] nvoBCFlTmRc1_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec2 AI 15 AI 15 40027 CB780_AI[14] nvoBCFlCdRc2_XXX SNVT_count_f
BC_Flt_Hist_String_Rec2 AI 16 AI 16 40028 CB780_AI[15] nvoBCFlSgRc2_XXX SNVT_count_f
BC_Flt_Hist_State_Rec2 AI 17 AI 17 40029 CB780_AI[16] nvoBCFlStRc2_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec2 AI 18 AI 18 40030 CB780_AI[17] nvoBCFlL1Rc2_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec2 AI 19 AI 19 40031 CB780_AI[18] nvoBCFlL2Rc2_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec2 AI 20 AI 20 40032 CB780_AI[19] nvoBCFlTmRc2_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec3 AI 21 AI 21 40037 CB780_AI[20] nvoBCFlCdRc3_XXX SNVT_count_f
BC_Flt_Hist_String_Rec3 AI 22 AI 22 40038 CB780_AI[21] nvoBCFlSgRc3_XXX SNVT_count_f
BC_Flt_Hist_State_Rec3 AI 23 AI 23 40039 CB780_AI[22] nvoBCFlStRc3_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec3 AI 24 AI 24 40040 CB780_AI[23] nvoBCFlL1Rc3_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec3 AI 25 AI 25 40041 CB780_AI[24] nvoBCFlL2Rc3_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec3 AI 26 AI 26 40042 CB780_AI[25] nvoBCFlTmRc3_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec4 AI 27 AI 27 40047 CB780_AI[26] nvoBCFlCdRc4_XXX SNVT_count_f
BC_Flt_Hist_String_Rec4 AI 28 AI 28 40048 CB780_AI[27] nvoBCFlSgRc4_XXX SNVT_count_f
BC_Flt_Hist_State_Rec4 AI 29 AI 29 40049 CB780_AI[28] nvoBCFlStRc4_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec4 AI 30 AI 30 40050 CB780_AI[29] nvoBCFlL1Rc4_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec4 AI 31 AI 31 40051 CB780_AI[30] nvoBCFlL2Rc4_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec4 AI 32 AI 32 40052 CB780_AI[31] nvoBCFlTmRc4_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec5 AI 33 AI 33 40057 CB780_AI[32] nvoBCFlCdRc5_XXX SNVT_count_f
BC_Flt_Hist_String_Rec5 AI 34 AI 34 40058 CB780_AI[33] nvoBCFlSgRc5_XXX SNVT_count_f
BC_Flt_Hist_State_Rec5 AI 35 AI 35 40059 CB780_AI[34] nvoBCFlStRc5_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec5 AI 36 AI 36 40060 CB780_AI[35] nvoBCFlL1Rc5_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec5 AI 37 AI 37 40061 CB780_AI[36] nvoBCFlL2Rc5_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec5 AI 38 AI 38 40062 CB780_AI[37] nvoBCFlTmRc5_XXX SNVT_count_f
BC_Flt_Hist_Code_Rec6 AI 39 AI 39 40067 CB780_AI[38] nvoBCFlCdRc6_XXX SNVT_count_f
