ProtoNode Gateway
46 750-426
APPENDIX B — DATA POINT MAPPINGS for CLEAVER-BROOKS APPLICATIONS
B.1. FALCON HYDRONIC
FALCON HYDRONIC Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks
RER LER
Point Name
BACnet
Data
Type
BACnet
Object
Id
N2
Data
Type
N2 Point
Address
Modbus
Register
(Bit
)
EIP Tag Name Lon Name Lon SNVT Type
PumpC BI 3 DI 3 30003 2 CFC_AB_XXX[0].2 nvoPumpC_XXX SNVT_switch
Blower_Mtr BI 4 DI 4 30003 3 CFC_AB_XXX[0].3 nvoBlwr_Mtr_XXX SNVT_switch
Ext_Ignition BI 5 DI 5 30003 4 CFC_AB_XXX[0].4 nvoExt_Ign_XXX SNVT_switch
Pilot-MainDBI_Valve BI 6 DI 6 30003 5 CFC_AB_XXX[0].5 nvoPlMnDBIVl_XXX SNVT_switch
Main_Valve BI 7 DI 7 30003 6 CFC_AB_XXX[0].6 nvoMainValve_XXX SNVT_switch
Alarm BI 8 DI 8 30003 7 CFC_AB_XXX[0].7 nvoAlarm_XXX SNVT_switch
Interlock BI 9 DI 9 30003 8 CFC_AB_XXX[0].8 nvoInterlock_XXX SNVT_switch
PreIgn_Interlock BI 10 DI 10 30003 9 CFC_AB_XXX[0].9 nvoPreIgnInt_XXX SNVT_switch
Load_Control_In BI 11 DI 11 30003 10 CFC_AB_XXX[0].10 nvoLdCtrlIn_XXX SNVT_switch
Low_Fire_Switch BI 12 DI 12 30003 11 CFC_AB_XXX[0].11 nvoLoFireSw_XXX SNVT_switch
High_Fire_Switch BI 13 DI 13 30003 12 CFC_AB_XXX[0].12 nvoHiFireSw_XXX SNVT_switch
Stat_Demand BI 14 DI 14 30003 13 CFC_AB_XXX[0].13 nvoStatDem_XXX SNVT_switch
TimeOfDay BI 15 DI 15 30003 14 CFC_AB_XXX[0].14 nvoTimeOfDay_XXX SNVT_switch
Safety_Relay BI 16 DI 16 30003 15 CFC_AB_XXX[0].15 nvoSafetyRel_XXX SNVT_switch
Int_Air_Switch BI 17 DI 17 30004 0 CFC_AB_XXX[1].0 nvoIntAirSw_XXX SNVT_switch
Low_Water BI 18 DI 18 30004 1 CFC_AB_XXX[1].1 nvoLoWater_XXX SNVT_switch
Aux_Low_Water BI 19 DI 19 30004 2 CFC_AB_XXX[1].2 nvoAuxLoWtr_XXX SNVT_switch
High_Limit BI 20 DI 20 30004 3 CFC_AB_XXX[1].3 nvoHiLimit_XXX SNVT_switch
High_Gas_Press BI 21 DI 21 30004 4 CFC_AB_XXX[1].4 nvoHiGasPrx_XXX SNVT_switch
Low_Gas_Press BI 22 DI 22 30004 5 CFC_AB_XXX[1].5 nvoLoGasPrx_XXX SNVT_switch
Natural_Gas BI 23 DI 23 30004 6 CFC_AB_XXX[1].6 nvoNatGas_XXX SNVT_switch
Propane_Gas BI 24 DI 24 30004 7 CFC_AB_XXX[1].7 nvoPropanGas_XXX SNVT_switch
DEMAND SOURCE AI 1 AI 1 30007 CFC_AI_XXX[0] nvoDemSrc_XXX SNVT_count_f
OUTLET WATER TEMP DEG F AI 2 AI 2 30008 CFC_AR_XXX[0] nvoOutWtrTmp_XXX SNVT_temp_p
FIRING_RATE AI 3 AI 3 30009 CFC_AI_XXX[1] nvoFirRate_XXX SNVT_count_f
FAN_SPEED AI 4 AI 4 30010 CFC_AI_XXX[2] nvoFanSpeed_XXX SNVT_count_f
FLAME_SIGNAL AI 5 AI 5 30011 CFC_AI_XXX[3] nvoFlameSig_XXX SNVT_count_f
INLET WATER TEMP DEG F AI 6 AI 6 30012 CFC_AR_XXX[1] nvoInlWtrTmp_XXX SNVT_temp_p
DHW WATER TEMP DEG F AI 7 AI 7 30013 CFC_AR_XXX[2] nvoDHWWtrTmp_XXX SNVT_temp_p
HEADER or ODT DEG F AI 8 AI 8 30014 CFC_AR_XXX[3] nvoHdrOrOdt_XXX SNVT_temp_p
STACK TEMP DEG F AI 9 AI 9 30015 CFC_AR_XXX[4] nvoStkTemp_XXX SNVT_temp_p
CH SETPOINT DEG F AI 11 AI 11 30017 CFC_AR_XXX[5] nvoCH_SP_XXX SNVT_temp_p
DHW SETPOINT DEG F AI 12 AI 12 30018 CFC_AR_XXX[6] nvoDHW_SP_XXX SNVT_temp_p
ANALOG_INPUT AI 14 AI 14 30022 CFC_AI_XXX[4] nvoAnaInput_XXX SNVT_count_f
BURN_CTL_STATUS AI 15 AI 15 30033 CFC_AI_XXX[5] nvoBrnCtStat_XXX SNVT_count_f
BURN_CTL_STATE AI 16 AI 16 30034 CFC_AI_XXX[6] nvoBrnCtlSte_XXX SNVT_count_f
LOCKOUT_CODE AI 17 AI 17 30035 CFC_AI_XXX[7] nvoLockoutCd_XXX SNVT_count_f
HOLD_CODE AI 18 AI 18 30041 CFC_AI_XXX[8] nvoHoldCode_XXX SNVT_count_f
CH STATUS AI 20 AI 20 30063 CFC_AI_XXX[9] nvoCH_Status_XXX SNVT_count_f
CH SETPOINT SOURCE AI 21 AI 21 30066 CFC_AI_XXX[10] nvoCH_SPSrc_XXX SNVT_count_f
CH HEAT DEMAND AI 22 AI 22 30067 CFC_AI_XXX[11] nvoCH_HtDem_XXX SNVT_count_f
CH BURNER DEMAND AI 23 AI 23 30068 CFC_AI_XXX[12] nvoCH_BrnDem_XXX SNVT_count_f
CH REQUESTED RATE AI 24 AI 24 30069 CFC_AI_XXX[13] nvoCH_ReqRat_XXX SNVT_count_f
CH FROST HEAT DEMAND AI 25 AI 25 30070 CFC_AI_XXX[14] nvoCH_FrHtDm_XXX SNVT_count_f
CH FROST BURNER DEMAND AI 26 AI 26 30071 CFC_AI_XXX[15] nvoCHFrBrnDm_XXX SNVT_count_f
DHW STATUS AI 29 AI 29 30081 CFC_AI_XXX[16] nvoDHW_Stat_XXX SNVT_count_f
DHW SETPOINT SOURCE AI 30 AI 30 30082 CFC_AI_XXX[17] nvoDHW_SPSrc_XXX SNVT_count_f
