CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 47
*Write point
DHW HEAT DEMAND AI 32 AI 32 30084 CFC_AI_XXX[18] nvoDHW_HtDem_XXX SNVT_count_f
DHW BURNER DEMAND AI 33 AI 33 30085 CFC_AI_XXX[19] nvoDHW_BrnDm_XXX SNVT_count_f
DHW REQUESTED RATE AI 34 AI 34 30086 CFC_AI_XXX[20] nvoDHW_ReqRt_XXX SNVT_count_f
CH PUMP STATUS AI 39 AI 39 30097 CFC_AI_XXX[21] nvoCH_PmpSt_XXX SNVT_count_f
DHW PUMP STATUS AI 43 AI 43 30101 CFC_AI_XXX[22] nvoDHWPmpSt_XXX SNVT_count_f
SYSTEM PUMP STATUS AI 48 AI 48 30106 CFC_AI_XXX[23] nvoSysPmpSt_XXX SNVT_count_f
BOILER PUMP STATUS AI 51 AI 51 30109 CFC_AI_XXX[24] nvoBlrPmpSt_XXX SNVT_count_f
AUXILIARY1 PUMP STATUS AI 54 AI 54 30112 CFC_AI_XXX[25] nvoAux1PmpSt_XXX SNVT_count_f
AUXILIARY2 PUMP STATUS AI 55 AI 55 30114 CFC_AI_XXX[26] nvoAux2PmpSt_XXX SNVT_count_f
BURNER_ENABLE AI 57 AI 57 30204 CFC_AI_XXX[27] nvoBrnrEnbl_XXX SNVT_count_f
LEAD/LAG SETPOINT DEG F AI 60 AI 60 30547 CFC_AR_XXX[7] nvoLL_SP_XXX SNVT_temp_p
LEAD/LAG_ENABLE AI 61 AI 61 30556 CFC_AI_XXX[28] nvoLL_Enbl_XXX SNVT_count_f
CYCLE_COUNT AI 58 AI 58 30129-30 CFC_AD_XXX[0] nvoCycCount_XXX SNVT_count_f
BURNER RUN_TIME AI 59 AI 59 30131-32 CFC_AD_XXX[1] nvoBrnRunTim_XXX SNVT_time_hour
*
BOILER BURNER ENABLE AV 1 AO 1 40204 CFC_AWI_XXX[0] nviBrnrEnbl_XXX SNVT_count_f
*
BOILER LEAD/LAG ENABLE AV 11 AO 11 40556 CFC_AWI_XXX[1] nviLL_Enbl_XXX SNVT_count_f
*
BOILER CH SETPOINT DEG F AV 21 AO 21 40212 CFC_AWR_XXX[0] nviCH_SP_XXX SNVT_temp_p
*
BOILER LEAD/LAG SETPOINT DEG F AV 31 AO 31 40547 CFC_AWR_XXX[1] nviLL_SP_XXX SNVT_temp_p
OUTLET WATER TEMP DEG C AI 62 AI 62 30008 CFC_AR_XXX[8]
INLET WATER TEMP DEG C AI 66 AI 66 30012 CFC_AR_XXX[9]
DHW WATER TEMP DEG C AI 67 AI 67 30013 CFC_AR_XXX[10]
HEADER or ODT DEG C AI 68 AI 68 30014 CFC_AR_XXX[11]
STACK TEMP DEG C AI 69 AI 69 30015 CFC_AR_XXX[12]
CH SETPOINT DEG C AI 71 AI 71 30017 CFC_AR_XXX[13]
DHW SETPOINT DEG C AI 72 AI 72 30018 CFC_AR_XXX[14]
LEAD/LAG SETPOINT DEG C AI 73 AI 73 30547 CFC_AR_XXX[15]
*
BOILER CH SETPOINT DEG C AV 41 AO 41 40212 CFC_AWR_XXX[2]
*
BOILER LEAD/LAG SETPOINT DEG C AV 51 AO 51 40547 CFC_AWR_XXX[3]
FIRING_RATE_PERCENT AI 74 AI 74 30074 CFC_AI_XXX[29]
4-20Ma Remote Ctl Input AI 75 AI 75 40016 CFC_AI_XXX[30] nvo420mARmCt_XXX SNVT_count_f
Active LL Setpoint AI 76 AI 76 40019 CFC_AI_XXX[31] nvoActLLSP_XXX SNVT_temp_p
Alarm Reason AI 77 AI 77 40036 CFC_AI_XXX[32] nvoAlmRson_XXX SNVT_count_f
Annunciator First Out AI 78 AI 78 40037 CFC_AI_XXX[33] nvoAnn1stOut_XXX SNVT_count_f
Annunciator Hold AI 79 AI 79 40038 CFC_AI_XXX[34] nvoAnnHold_XXX SNVT_count_f
Outdoor Temperature AI 80 AI 80 40171 CFC_AI_XXX[35] nvoOutdrTmp_XXX SNVT_temp_p
*
CH Pump Cycle Count AV 61 AO 61 40133-34 CFC_AD_XXX[2] nvi/nvoCHPmpCyCt_X XX SNVT_count_f
Lead Boiler Address AI 81 AI 81 40802 CFC_AI_XXX[36] nvoLdBlrAddr_XXX SNVT_count_f
Firing Rate Type AI 82 AI 82 30193 CFC_AI_XXX[37] nvoFirRteTyp_XXX SNVT_count_f
Master ID AI 83 AI 83 30546 CFC_AI_XXX[38] nvoMasterID_XXX SNVT_count_f
Slave Setpoint AI 84 AI 84 30030 CFC_AI_XXX[39] nvoSlaveSP_XXX SNVT_temp_p
Master OAT AI 85 AI 85 30171 CFC_AI_XXX[40] nvoMstrOAT_XXX SNVT_temp_p
Max Firing Rate AI 86 AI 86 30194 CFC_AI_XXX[41] nvoMxFirRate_XXX SNVT_count_f
Min Firing Rate AI 87 AI 87 30196 CFC_AI_XXX[42] nvoMnFirRate_XXX SNVT_count_f
FALCON HYDRONIC Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object
Id
N2
Data
Type
N2 Point
Address
Modbus
Register
(Bit
)
EIP Tag Name Lon Name Lon SNVT Type
