ProtoNode Gateway
10 750-426
2. PROTONODE SETUP
2.1 Record Identification Data
Each ProtoNode has a unique part number located on the underside of the unit. This number should
be recorded, as it may be required for technical support. The numbers are as follows:
FIGURE 2 - ProtoNode Part Numbers
• RER units have the following 3 ports: RS-485 + Ethernet + RS-485
• LER units have the following 3 ports: LonWorks + Ethernet + RS-485
2.2 Point Count Capacity and Registers per Device
The total number of Modbus registers presented by all of the devices attached to the ProtoNode
cannot exceed:
FIGURE 3 - Supported Point Count Capacity
FIGURE 4 - Modbus Registers per Device
Model Part Number Description
ProtoNode RER 833-06022-000 BACnet, N2, Modbus, Ethernet/IP
ProtoNode LER 833-06029-000 LonWorks
Model Total Registers
ProtoNode RER 10,000
ProtoNode LER 5,000
DEVICE REGISTERS PER DEVICE
Falcon_Hydronic 92
Falcon_Steam 62
CB780 93
CB120 94
HSC 318
LCS 59
PCS 57
HAWK_1000 278
HAWK_2000 75
HAWK_4000 293
HAWK_5000 278
HAWK_Master 200
HAWK_ADAC 275
HAWK_ICS 146
Shark100 41
Shark200 50
UDC2500 42
HSC_Pump_Interface 47
HSC_Boiler_Interface 40
CB780_CB783_FARC 178
Hawk_4000_V2 378
ADAC_1000 338
