1.2 Methods of Configuration - Cleaver-Brooks' Devices
The ProtoNode offers two methods of configuration:
• Auto-Discovery for RS-485 devices listed below in Figure 1.
• Web Configurator for Ethernet devices and RS-485 devices that cannot be identified by Auto-Discovery
A list of C-B products for use with the ProtoNode, together with their respective means of configura-
tion, is shown in the table below.
FIGURE 1 - Method of configuration for the devices
Devices Type of Communication Type of Configuration
Falcon Hydronic RS-485 Auto-Discovery/Web Configurator
Falcon Steam RS-485 Auto-Discovery/Web Configurator
CB780 RS-485 Web Configurator
CB120 RS-485 Web Configurator
HSC Admin RS-485 Auto-Discovery/Web Configurator
HSC BIM RS-485 Web Configurator
HSC PIM RS-485 Web Configurator
LCS RS-485 Web Configurator
PCS RS-485 Web Configurator
HAWK 1000 Ethernet Web Configurator
HAWK 2000 Ethernet Web Configurator
HAWK 4000 Ethernet Web Configurator
HAWK 4500 Ethernet Web Configurator
HAWK 5000 Ethernet Web Configurator
HAWK Master Ethernet Web Configurator
HAWK ADAC Ethernet Web Configurator
HAWK ICS Ethernet Web Configurator
Shark 100 Ethernet Web Configurator
Shark 200 Ethernet Web Configurator
UDC2500 Ethernet Web Configurator
HSC Pump Interface (PIM) Ethernet Web Configurator
HSC Boiler Interface (BIM) Ethernet Web Configurator
CB780 CB783 FARC Ethernet Web Configurator
HAWK 4000 V2 Ethernet Web Configurator
ADAC 1000 Ethernet Web Configurator
