ProtoNode Gateway
750-426 51
*Write point
BC_Flt_Hist_String_Rec6 AI 40 AI 40 40068 CB780_AI[39] nvoBCFlSgRc6_XXX SNVT_count_f
BC_Flt_Hist_State_Rec6 AI 41 AI 41 40069 CB780_AI[40] nvoBCFlStRc6_XXX SNVT_count_f
BC_Flt_Hist_Line1_Rec6 AI 42 AI 42 40070 CB780_AI[41] nvoBCFlL1Rc6_XXX SNVT_count_f
BC_Flt_Hist_Line2_Rec6 AI 43 AI 43 40071 CB780_AI[42] nvoBCFlL2Rc6_XXX SNVT_count_f
BC_Flt_Hist_Time_Rec6 AI 44 AI 44 40072 CB780_AI[43] nvoBCFlTmRc6_XXX SNVT_count_f
BC_Rem_Comd_Stat AI 45 AI 45 40085 CB780_AI[44] nvoBCRmCmdSt_XXX SNVT_count_f
BC_Vlv_Prov_Mode AI 46 AI 46 40104 CB780_AI[45] nvoBCVlPrvMd_XXX SNVT_count_f
BC_Vlv_Prov_Time AI 47 AI 47 40106 CB780_AI[46] nvoBCVlPrvTm_XXX SNVT_count_f
BC_Rem_Command AI 48 AI 48 40128 CB780_AI[47] nvoBCRemCmd_XXX SNVT_count_f
BC_Total_Cycles AI 50 AI 50 40007 CB780_AI[48] nvoBCTotCyc_XXX SNVT_count_f
BC_Total_Hours AI 51 AI 51 40009 CB780_AI[49] nvoBCTotalHr_XXX SNVT_time_hou r
BC_Flt_Hist_Cyc_Rec1 AI 52 AI 52 40023 CB780_AI[50] nvoBCFlCyRc1_XXX SNVT_count_f
BC_Flt_Hist_Hrs_Rec1 AI 53 AI 53 40025 CB780_AI[51] nvoBCFlHrRc1_XXX SNVT_count_f
BC_Flt_Hist_Cyc_Rec2 AI 54 AI 54 40033 CB780_AI[52] nvoBCFlCyRc2_XXX SNVT_count_f
BC_Flt_Hist_Hrs_Rec2 AI 55 AI 55 40035 CB780_AI[53] nvoBCFlHrRc2_XXX SNVT_count_f
BC_Flt_Hist_Cyc_Rec3 AI 56 AI 56 40043 CB780_AI[54] nvoBCFlCyRc3_XXX SNVT_count_f
BC_Flt_Hist_Hrs_Rec3 AI 57 AI 57 40045 CB780_AI[55] nvoBCFlHrRc3_XXX SNVT_count_f
BC_Flt_Hist_Cyc_Rec4 AI 58 AI 58 40053 CB780_AI[56] nvoBCFlCyRc4_XXX SNVT_count_f
BC_Flt_Hist_Hrs_Rec4 AI 59 AI 59 40055 CB780_AI[57] nvoBCFlHrRc4_XXX SNVT_count_f
BC_Flt_Hist_Cyc_Rec5 AI 60 AI 60 40063 CB780_AI[58] nvoBCFlCyRc5_XXX SNVT_count_f
BC_Flt_Hist_Hrs_Rec5 AI 61 AI 61 40065 CB780_AI[59] nvoBCFlHrRc5_XXX SNVT_count_f
BC_Flt_Hist_Cyc_Rec6 AI 62 AI 62 40073 CB780_AI[60] nvoBCFlCyRc6_XXX SNVT_count_f
BC_Flt_Hist_Hrs_Rec6 AI 63 AI 63 40075 CB780_AI[61] nvoBCFlHrRc6_XXX SNVT_count_f
* BC_Rem_Command AV 1 AO 1 40128 CB780_AWI[0] nviBCRemCmd_XXX SNVT_count_f
ExpAnn_First_Out_Code AI 49 AI 49 40014 CB780_AI[62] nvoExAn1OtCd_XXX SNVT_count_f
EA_Valve_POC BI 11 DI 11 40015 4 CB780_AB[1].4 nvoEAVlvPOC_XXX SNVT_switch
EA_Burner_Switch BI 12 DI 12 40015 5 CB780_AB[1].5 nvoEABrnrSw_XXX SNVT_switch
EA_Oper_Control BI 13 DI 13 40015 6 CB780_AB[1].6 nvoEAOpCtrl_XXX SNVT_switch
EA_Aux_Limit_1 BI 14 DI 14 40015 7 CB780_AB[1].7 nvoEAAuxLim1_XXX SNVT_switch
EA_Aux_Limit_2 BI 15 DI 15 40015 8 CB780_AB[1].8 nvoEAAuxLim2_XXX SNVT_switch
EA_LWCO BI 16 DI 16 40015 9 CB780_AB[1].9 nvoEALWCO_XXX SNVT_switch
EA_High_Limit BI 17 DI 17 40015 10 CB780_AB[1].10 nvoEAHiLim_XXX SNVT_switch
EA_Aux_Limit_3 BI 18 DI 18 40015 11 CB780_AB[1].11 nvoEAAuxLim3_XXX SNVT_switch
EA_Oil_Select BI 19 DI 19 40015 12 CB780_AB[1].12 nvoEAOilSel_XXX SNVT_switch
EA_High_Oil_Press BI 20 DI 20 40015 13 CB780_AB[1].13 nvoEAHiOilPr_XXX SNVT_switch
EA_Low_Oil_Press BI 21 DI 21 40015 14 CB780_AB[1].14 nvoEALoOilPr_XXX SNVT_switch
EA_High_Oil_Temp BI 22 DI 22 40015 15 CB780_AB[1].15 nvoEAHiOilTp_XXX SNVT_switch
EA_Low_Oil_Temp BI 23 DI 23 40015 16 CB780_AB[2].0 nvoEALoOilTp_XXX SNVT_switch
EA_Gas_Select BI 24 DI 24 40015 17 CB780_AB[2].1 nvoEAGasSel_XXX SNVT_switch
EA_High_Gas_Press BI 25 DI 25 40015 18 CB780_AB[2].2 nvoEAHiGasPr_XXX SNVT_switch
EA_Low_Gas_Press BI 26 DI 26 40015 19 CB780_AB[2].3 nvoEALoGasPr_XXX SNVT_switch
EA_Air_Flow_Switch BI 27 DI 27 40015 20 CB780_AB[2].4 nvoEAArFloSw_XXX SNVT_switch
EA_Aux_Limit_4 BI 28 DI 28 40015 21 CB780_AB[2].5 nvoEAAuxLim4_XXX SNVT_switch
EA_Aux_Limit_5 BI 29 DI 29 40015 22 CB780_AB[2].6 nvoEAAuxLim5_XXX SNVT_switch
CB780 Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
(Bit) EIP Tag Name Lon Name Lon SNVT Type
