ProtoNode Gateway
750-426 93
Boiler Efficiency AI 4 AI 4 30007 nvoBlrEff_XXX SNVT_lev_percent
Firing Rate AI 5 AI 5 30009 nvoFirRat_XXX SNVT_lev_percent
O2 Level AI 6 AI 6 30011 nvoO2Lvl_XXX SNVT_lev_percent
Set Point Steam Pressure/Water Temp AI 7 AI 7 30013 nvoSPStPWtTp_XXX SNVT_count_f
Water Level AI 8 AI 8 30015 nvoWtrLvl_XXX SNVT_press_f
Steam Pressure or HW Temp AI 9 AI 9 30017 nvoSTProHWTp_XXX SNVT_count_f
Combustion Air Pressure AI 10 AI 10 30019 nvoComAirPrs_XXX SNVT_count_f
Stack Temp Before Econ AI 11 AI 11 30021 nvoStkTpBfEc_XXX SNVT_temp_p
Combustion Air Temp AI 12 AI 12 30023 nvoComAirTmp_XXX SNVT_temp_p
Water Temp Shell/Outdoor Temp AI 13 AI 13 30025 nvoWtTpShl_XXX SNVT_temp_p
Feedwater Temp/Econ Water Out Temp AI 14 AI 14 30027 nvoFdWtTp_XXX SNVT_temp_p
Stack Temp After Econ/Return HW AI 15 AI 15 30029 nvoStkTmpEco_XXX SNVT_temp_p
Economizer Water In Temp AI 16 AI 16 30031 nvoEcWtInTmp_XXX SNVT_temp_p
Analog Input User Defined #1 Input AI 17 AI 17 30033 nvoAIUsDf1In_XXX SNVT_count_f
Analog Input User Defined #2 Input AI 18 AI 18 30035 nvoAIUsDf2In_XXX SNVT_count_f
Analog Input User Defined #3 Input AI 19 AI 19 30037 nvoAIUsDf3In_XXX SNVT_count_f
Analog Input User Defined #4 Input AI 20 AI 20 30039 nvoAIUsDf4In_XXX SNVT_count_f
Safety Valve Setting or Max Water Temp AI 21 AI 21 30041 nvoSftVlvSet_XXX SNVT_count_f
Header Pressure or temp 2 Boiler LL AI 22 AI 22 30043 nvoHdPrTpBLL_XXX SNVT_count_f
Set Point 2 Boiler LL AI 23 AI 23 30045 nvoSP2BlrLL_XXX SNVT_count_f
Boiler Off Point AI 24 AI 24 30047 nvoBlrOffPt_XXX SNVT_count_f
Boiler On Point AI 25 AI 25 30049 nvoBlrOnPt_XXX SNVT_count_f
AR[25] Future AI 26 AI 26 30051 nvoAR_25_XXX SNVT_count_f
AR[26] Future AI 27 AI 27 30053 nvoAR_26_XXX SNVT_count_f
Brnr Control Status Line 1 Honeywell AI 28 AI 28 30055 nvoBCtSL1Hy_XXX SNVT_count_f
Brnr Control Status Line 2 Honeywell AI 29 AI 29 30056 nvoBCtSL2Hy_XXX SNVT_count_f
Brnr Control Status Line 1 Fireye AI 30 AI 30 30057 nvoBCtSL1Fr_XXX SNVT_count_f
Brnr Control Status Line 2 Fireye AI 31 AI 31 30058 nvoBCtSL2Fr_XXX SNVT_count_f
Flame Signal Fireye AI 32 AI 32 30059 nvoFlSgFrey_XXX SNVT_count_f
Fuel 1 Type AI 33 AI 33 30060 nvoFl1Type_XXX SNVT_count_f
Fuel 2 Type AI 34 AI 34 30061 nvoFl2Type_XXX SNVT_count_f
Fuel 3 Type AI 35 AI 35 30062 nvoFl3Type_XXX SNVT_count_f
Boiler ID AI 36 AI 36 30063 nvoBlrID_XXX SNVT_count_f
Elapsed Time (First 16 Bits) AI 37 AI 37 30064 nvoElpTm1_XXX SNVT_time_hour
Elapsed Time (Second 16 Bits) AI 38 AI 38 30065 nvoElpTm2_XXX SNVT_time_hour
Number Of Cycles (First 16 Bits) AI 39 AI 39 30066 nvoNumCyc1_XXX SNVT_count_f
Number Of Cycles (Second 16 Bits) AI 40 AI 40 30067 nvoNumCyc2_XXX SNVT_count_f
AI[13] Future AI 41 AI 41 30068 nvoAI_13_XXX SNVT_count_f
AI[14] Future AI 42 AI 42 30069 nvoAI_14_XXX SNVT_count_f
Elapsed Time AI 43 AI 43 30070 nvoElapTim_XXX SNVT_time_hour
Number Of Cycles AI 44 AI 44 30072 nvoNumCyc_XXX SNVT_count_f
Hawk ICS Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
