ProtoNode Gateway

750-426 55

C Boiler 5 Outlet Temp AI 50 AI 50 30070 HSC_AI_XXX[49] nvoCBl5OtTp_XXX SNVT_temp_p

C Boiler 6 State AI 51 AI 51 30071 HSC_AI_XXX[50] nvoCBl6St_XXX SNVT_count_inc_f

C Boiler 6 Alarm Word AI 52 AI 52 30072 HSC_AI_XXX[51] nvoCBl6AlWd_XXX SNVT_count_inc_f

C Boiler 6 Hours Word 1 AI 53 AI 53 30073 HSC_AI_XXX[52] nvoCBl6Hrs1_XXX SNVT_time_hour

C Boiler 6 Hours Word 2 AI 54 AI 54 30074 HSC_AI_XXX[53] nvoCBl6Hrs2_XXX SNVT_time_hour

C Boiler 6 Cycles Word 1 AI 55 AI 55 30075 HSC_AI_XXX[54] nvoCBl6Cyc1_XXX SNVT_count_inc_f

C Boiler 6 Cycles Word 2 AI 56 AI 56 30076 HSC_AI_XXX[55] nvoCBl6Cyc2_XXX SNVT_count_inc_f

C Boiler 6 Status Bits AI 57 AI 57 30077 HSC_AI_XXX[56] nvoCBl6StBt_XXX SNVT_count_inc_f

C Boiler 6 Inlet Temp AI 58 AI 58 30078 HSC_AI_XXX[57] nvoCBl6InTp_XXX SNVT_temp_p

C Boiler 6 Fire Delay AI 59 AI 59 30079 HSC_AI_XXX[58] nvoCBl6FrDl_XXX SNVT_count_inc_f

C Boiler 6 Outlet Temp AI 60 AI 60 30080 HSC_AI_XXX[59] nvoCBl6OtTp_XXX SNVT_temp_p

C Boiler 7 State AI 61 AI 61 30081 HSC_AI_XXX[60] nvoCBl7St_XXX SNVT_count_inc_f

C Boiler 7 Alarm Word AI 62 AI 62 30082 HSC_AI_XXX[61] nvoCBl7AlWd_XXX SNVT_count_inc_f

C Boiler 7 Hours Word 1 AI 63 AI 63 30083 HSC_AI_XXX[62] nvoCBl7Hrs1_XXX SNVT_time_hour

C Boiler 7 Hours Word 2 AI 64 AI 64 30084 HSC_AI_XXX[63] nvoCBl7Hrs2_XXX SNVT_time_hour

C Boiler 7 Cycles Word 1 AI 65 AI 65 30085 HSC_AI_XXX[64] nvoCBl7Cyc1_XXX SNVT_count_inc_f

C Boiler 7 Cycles Word 2 AI 66 AI 66 30086 HSC_AI_XXX[65] nvoCBl7Cyc2_XXX SNVT_count_inc_f

C Boiler 7 Status Bits AI 67 AI 67 30087 HSC_AI_XXX[66] nvoCBl7StBt_XXX SNVT_count_inc_f

C Boiler 7 Inlet Temp AI 68 AI 68 30088 HSC_AI_XXX[67] nvoCBl7InTp_XXX SNVT_temp_p

C Boiler 7 Fire Delay AI 69 AI 69 30089 HSC_AI_XXX[68] nvoCBl7FrDl_XXX SNVT_count_inc_f

C Boiler 7 Outlet Temp AI 70 AI 70 30090 HSC_AI_XXX[69] nvoCBl7OtTp_XXX SNVT_temp_p

C Boiler 8 State AI 71 AI 71 30091 HSC_AI_XXX[70] nvoCBl8St_XXX SNVT_count_inc_f

C Boiler 8 Alarm Word AI 72 AI 72 30092 HSC_AI_XXX[71] nvoCBl8AlWd_XXX SNVT_count_inc_f

C Boiler 8 Hours Word 1 AI 73 AI 73 30093 HSC_AI_XXX[72] nvoCBl8Hrs1_XXX SNVT_time_hour

C Boiler 8 Hours Word 2 AI 74 AI 74 30094 HSC_AI_XXX[73] nvoCBl8Hrs2_XXX SNVT_time_hour

C Boiler 8 Cycles Word 1 AI 75 AI 75 30095 HSC_AI_XXX[74] nvoCBl8Cyc1_XXX SNVT_count_inc_f

C Boiler 8 Cycles Word 2 AI 76 AI 76 30096 HSC_AI_XXX[75] nvoCBl8Cyc2_XXX SNVT_count_inc_f

C Boiler 8 Status Bits AI 77 AI 77 30097 HSC_AI_XXX[76] nvoCBl8StBt_XXX SNVT_count_inc_f

C Boiler 8 Inlet Temp AI 78 AI 78 30098 HSC_AI_XXX[77] nvoCBl8InTp_XXX SNVT_temp_p

C Boiler 8 Fire Delay AI 79 AI 79 30099 HSC_AI_XXX[78] nvoCBl8FrDl_XXX SNVT_count_inc_f

C Boiler 8 Outlet Temp AI 80 AI 80 30100 HSC_AI_XXX[79] nvoCBl8OtTp_XXX SNVT_temp_p

C Boiler 9 State AI 81 AI 81 30101 HSC_AI_XXX[80] nvoCBl9St_XXX SNVT_count_inc_f

C Boiler 9 Alarm Word AI 82 AI 82 30102 HSC_AI_XXX[81] nvoCBl9AlWd_XXX SNVT_count_inc_f

C Boiler 9 Hours Word 1 AI 83 AI 83 30103 HSC_AI_XXX[82] nvoCBl9Hrs1_XXX SNVT_time_hour

C Boiler 9 Hours Word 2 AI 84 AI 84 30104 HSC_AI_XXX[83] nvoCBl9Hrs2_XXX SNVT_time_hour

C Boiler 9 Cycles Word 1 AI 85 AI 85 30105 HSC_AI_XXX[84] nvoCBl9Cyc1_XXX SNVT_count_inc_f

C Boiler 9 Cycles Word 2 AI 86 AI 86 30106 HSC_AI_XXX[85] nvoCBl9Cyc2_XXX SNVT_count_inc_f

C Boiler 9 Status Bits AI 87 AI 87 30107 HSC_AI_XXX[86] nvoCBl9StBt_XXX SNVT_count_inc_f

C Boiler 9 Inlet Temp AI 88 AI 88 30108 HSC_AI_XXX[87] nvoCBl9InTp_XXX SNVT_temp_p

C Boiler 9 Fire Delay AI 89 AI 89 30109 HSC_AI_XXX[88] nvoCBl9FrDl_XXX SNVT_count_inc_f

C Boiler 9 Outlet Temp AI 90 AI 90 30110 HSC_AI_XXX[89] nvoCBl9OtTp_XXX SNVT_temp_p

C Boiler 10 State AI 91 AI 91 30111 HSC_AI_XXX[90] nvoCBl10St_XXX SNVT_count_inc_f

C Boiler 10 Alarm Word AI 92 AI 92 30112 HSC_AI_XXX[91] nvoCBl10AlWd_XXX SNVT_count_inc_f

C Boiler 10 Hours Word 1 AI 93 AI 93 30113 HSC_AI_XXX[92] nvoCBl10Hrs1_XXX SNVT_time_hour

C Boiler 10 Hours Word 2 AI 94 AI 94 30114 HSC_AI_XXX[93] nvoCBl10Hrs2_XXX SNVT_time_hour

C Boiler 10 Cycles Word 1 AI 95 AI 95 30115 HSC_AI_XXX[94] nvoCBl10Cyc1_XXX SNVT_count_inc_f

C Boiler 10 Cycles Word 2 AI 96 AI 96 30116 HSC_AI_XXX[95] nvoCBl10Cyc2_XXX SNVT_count_inc_f

C Boiler 10 Status Bits AI 97 AI 97 30117 HSC_AI_XXX[96] nvoCBl10StBt_XXX SNVT_count_inc_f

C Boiler 10 Inlet Temp AI 98 AI 98 30118 HSC_AI_XXX[97] nvoCBl10InTp_XXX SNVT_temp_p

C Boiler 10 Fire Delay AI 99 AI 99 30119 HSC_AI_XXX[98] nvoCBl10FrDl_XXX SNVT_count_inc_f

HSC Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)

RER LER

Point Name

BACnet

Data

Type

BACnet

Object Id

Data

Type

N2 Point

Address

Modbus

EIP Tag Name Lon Name Lon SNVT Type
