ProtoNode Gateway
56 750-426
C Boiler 10 Outlet Temp AI 100 AI 100 30120 HSC_AI_XXX[99] nvoCBl10OtTp_XXX SNVT_temp_p
NC Boiler A State AI 101 AI 101 30121 HSC_AI_XXX[100] nvoNCBlASt_XXX SNVT_count_inc_f
NC Boiler A Alarm Word AI 102 AI 102 30122 HSC_AI_XXX[101] nvoNCBlAAlWd_XXX SNVT_count_inc_f
NC Boiler A Hours Word 1 AI 103 AI 103 30123 HSC_AI_XXX[102] nvoNCBlAHrs1_XXX SNVT_time_hour
NC Boiler A Hours Word 2 AI 104 AI 104 30124 HSC_AI_XXX[103] nvoNCBlAHrs2_XXX SNVT_time_hour
NC Boiler A Cycles Word 1 AI 105 AI 105 30125 HSC_AI_XXX[104] nvoNCBlACyc1_XXX SNVT_count_inc_f
NC Boiler A Cycles Word 2 AI 106 AI 106 30126 HSC_AI_XXX[105] nvoNCBlACyc2_XXX SNVT_count_inc_f
NC Boiler A Status Bits AI 107 AI 107 30127 HSC_AI_XXX[106] nvoNCBlAStBt_XXX SNVT_count_inc_f
NC Boiler A Inlet Temp AI 108 AI 108 30128 HSC_AI_XXX[107] nvoNCBlAInTp_XXX SNVT_temp_p
NC Boiler A Fire Delay AI 109 AI 109 30129 HSC_AI_XXX[108] nvoNCBlAFrDl_XXX SNVT_count_inc_f
NC Boiler A Outlet Temp AI 110 AI 110 30130 HSC_AI_XXX[109] nvoNCBlAOtTp_XXX SNVT_temp_p
NC Boiler B State AI 111 AI 111 30131 HSC_AI_XXX[110] nvoNCBlBSt_XXX SNVT_count_inc_f
NC Boiler B Alarm Word AI 112 AI 112 30132 HSC_AI_XXX[111] nvoNCBlBAlWd_XXX SNVT_count_inc_f
NC Boiler B Hours Word 1 AI 113 AI 113 30133 HSC_AI_XXX[112] nvoNCBlBHrs1_XXX SNVT_time_hour
NC Boiler B Hours Word 2 AI 114 AI 114 30134 HSC_AI_XXX[113] nvoNCBlBHrs2_XXX SNVT_time_hour
NC Boiler B Cycles Word 1 AI 115 AI 115 30135 HSC_AI_XXX[114] nvoNCBlBCyc1_XXX SNVT_count_inc_f
NC Boiler B Cycles Word 2 AI 116 AI 116 30136 HSC_AI_XXX[115] nvoNCBlBCyc2_XXX SNVT_count_inc_f
NC Boiler B Status Bits AI 117 AI 117 30137 HSC_AI_XXX[116] nvoNCBlBStBt_XXX SNVT_count_inc_f
NC Boiler B Inlet Temp AI 118 AI 118 30138 HSC_AI_XXX[117] nvoNCBlBInTp_XXX SNVT_temp_p
NC Boiler B Fire Delay AI 119 AI 119 30139 HSC_AI_XXX[118] nvoNCBlBFrDl_XXX SNVT_count_inc_f
NC Boiler B Outlet Temp AI 120 AI 120 30140 HSC_AI_XXX[119] nvoNCBlBOtTp_XXX SNVT_temp_p
NC Boiler C State AI 121 AI 121 30141 HSC_AI_XXX[120] nvoNCBlCSt_XXX SNVT_count_inc_f
NC Boiler C Alarm Word AI 122 AI 122 30142 HSC_AI_XXX[121] nvoNCBlCAlWd_XXX SNVT_count_inc_f
NC Boiler C Hours Word 1 AI 123 AI 123 30143 HSC_AI_XXX[122] nvoNCBlCHrs1_XXX SNVT_time_hour
NC Boiler C Hours Word 2 AI 124 AI 124 30144 HSC_AI_XXX[123] nvoNCBlCHrs2_XXX SNVT_time_hour
NC Boiler C Cycles Word 1 AI 125 AI 125 30145 HSC_AI_XXX[124] nvoNCBlCCyc1_XXX SNVT_count_inc_f
NC Boiler C Cycles Word 2 AI 126 AI 126 30146 HSC_AI_XXX[125] nvoNCBlCCyc2_XXX SNVT_count_inc_f
NC Boiler C Status Bits AI 127 AI 127 30147 HSC_AI_XXX[126] nvoNCBlCStBt_XXX SNVT_count_inc_f
NC Boiler C Inlet Temp AI 128 AI 128 30148 HSC_AI_XXX[127] nvoNCBlCInTp_XXX SNVT_temp_p
NC Boiler C Fire Delay AI 129 AI 129 30149 HSC_AI_XXX[128] nvoNCBlCFrDl_XXX SNVT_count_inc_f
NC Boiler C Outlet Temp AI 130 AI 130 30150 HSC_AI_XXX[129] nvoNCBlCOtTp_XXX SNVT_temp_p
NC Boiler D State AI 131 AI 131 30151 HSC_AI_XXX[130] nvoNCBlDSt_XXX SNVT_count_inc_f
NC Boiler D Alarm Word AI 132 AI 132 30152 HSC_AI_XXX[131] nvoNCBlDAlWd_XXX SNVT_count_inc_f
NC Boiler D Hours Word 1 AI 133 AI 133 30153 HSC_AI_XXX[132] nvoNCBlDHrs1_XXX SNVT_time_hour
NC Boiler D Hours Word 2 AI 134 AI 134 30154 HSC_AI_XXX[133] nvoNCBlDHrs2_XXX SNVT_time_hour
NC Boiler D Cycles Word 1 AI 135 AI 135 30155 HSC_AI_XXX[134] nvoNCBlDCyc1_XXX SNVT_count_inc_f
NC Boiler D Cycles Word 2 AI 136 AI 136 30156 HSC_AI_XXX[135] nvoNCBlDCyc2_XXX SNVT_count_inc_f
NC Boiler D Status Bits AI 137 AI 137 30157 HSC_AI_XXX[136] nvoNCBlDStBt_XXX SNVT_count_inc_f
NC Boiler D Inlet Temp AI 138 AI 138 30158 HSC_AI_XXX[137] nvoNCBlDInTp_XXX SNVT_temp_p
NC Boiler D Fire Delay AI 139 AI 139 30159 HSC_AI_XXX[138] nvoNCBlDFrDl_XXX SNVT_count_inc_f
NC Boiler D Outlet Temp AI 140 AI 140 30160 HSC_AI_XXX[139] nvoNCBlDOtTp_XXX SNVT_temp_p
NC Boiler E State AI 141 AI 141 30161 HSC_AI_XXX[140] nvoNCBlESt_XXX SNVT_count_inc_f
NC Boiler E Alarm Word AI 142 AI 142 30162 HSC_AI_XXX[141] nvoNCBlEAlWd_XXX SNVT_count_inc_f
NC Boiler E Hours Word 1 AI 143 AI 143 30163 HSC_AI_XXX[142] nvoNCBlEHrs1_XXX SNVT_time_hour
NC Boiler E Hours Word 2 AI 144 AI 144 30164 HSC_AI_XXX[143] nvoNCBlEHrs2_XXX SNVT_time_hour
NC Boiler E Cycles Word 1 AI 145 AI 145 30165 HSC_AI_XXX[144] nvoNCBlECyc1_XXX SNVT_count_inc_f
NC Boiler E Cycles Word 2 AI 146 AI 146 30166 HSC_AI_XXX[145] nvoNCBlECyc2_XXX SNVT_count_inc_f
NC Boiler E Status Bits AI 147 AI 147 30167 HSC_AI_XXX[146] nvoNCBlEStBt_XXX SNVT_count_inc_f
NC Boiler E Inlet Temp AI 148 AI 148 30168 HSC_AI_XXX[147] nvoNCBlEInTp_XXX SNVT_temp_p
NC Boiler E Fire Delay AI 149 AI 149 30169 HSC_AI_XXX[148] nvoNCBlEFrDl_XXX SNVT_count_inc_f
HSC Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon Name Lon SNVT Type
