R7999 Fault Info Word 33 AI 121 AI 121 40398 FARC_AI_XXX[105] nvoR7999Wd33_XXX SNVT_count_f
R7999 Fault Info Word 34 AI 122 AI 122 40399 FARC_AI_XXX[106] nvoR7999Wd34_XXX SNVT_count_f
R7999 Fault Info Word 35 AI 123 AI 123 40400 FARC_AI_XXX[107] nvoR7999Wd35_XXX SNVT_count_f
Air Total Resistance AI 124 AI 124 40401 FARC_AI_XXX[108] nvoAirTotRes_XXX SNVT_count_f
Fuel 1 Total Resistance AI 125 AI 125 40402 FARC_AI_XXX[109] nvoFl1TotRes_XXX SNVT_count_f
Fuel 2 Total Resistance AI 126 AI 126 40403 FARC_AI_XXX[110] nvoFl2TotRes_XXX SNVT_count_f
FGR Total Resistance AI 127 AI 127 40404 FARC_AI_XXX[111] nvoFGRTotRes_XXX SNVT_count_f
Air Resistance Change AI 128 AI 128 40405 FARC_AI_XXX[112] nvoAirResChg_XXX SNVT_count_f
Registers 40401-40405 Current AI 129 AI 129 40406 FARC_AI_XXX[113] nvoR40401_05_XXX SNVT_count_f
Fuel 1 Resistance Change AI 130 AI 130 40407 FARC_AI_XXX[114] nvoFl1ResChg_XXX SNVT_count_f
Fuel 2 Resistance Change AI 131 AI 131 40408 FARC_AI_XXX[115] nvoFl2ResChg_XXX SNVT_count_f
FGR Resistance Change AI 132 AI 132 40409 FARC_AI_XXX[116] nvoFGRResChg_XXX SNVT_count_f
Registers 40407-40411 Current AI 133 AI 133 40412 FARC_AI_XXX[117] nvoR40407_11_XXX SNVT_count_f
Air Purge Preset Position AI 134 AI 134 40413 FARC_AI_XXX[118] nvoArPrPrePs_XXX SNVT_count_f
Fuel Purge Preset Position AI 135 AI 135 40414 FARC_AI_XXX[119] nvoFlPrPrePs_XXX SNVT_count_f
FGR Purge Preset Position AI 136 AI 136 40415 FARC_AI_XXX[120] nvoFGRPrPrPs_XXX SNVT_count_f
Air Lightoff Preset Position AI 137 AI 137 40416 FARC_AI_XXX[121] nvoArLtPrePs_XXX SNVT_count_f
Fuel Lightoff Preset Position AI 138 AI 138 40417 FARC_AI_XXX[122] nvoFlLtPrePs_XXX SNVT_count_f
Registers 40413-40417 Current AI 139 AI 139 40418 FARC_AI_XXX[123] nvoR40413_17_XXX SNVT_count_f
Lightoff Preset FGR AI 140 AI 140 40419 FARC_AI_XXX[124] nvoLtOPreFGR_XXX SNVT_count_f
Air Standby Position AI 141 AI 141 40420 FARC_AI_XXX[125] nvoArStndPos_XXX SNVT_count_f
Fuel Standby Position AI 142 AI 142 40421 FARC_AI_XXX[126] nvoFlStndPos_XXX SNVT_count_f
FGR Standby Position AI 143 AI 143 40422 FARC_AI_XXX[127] nvoFGRStdPos_XXX SNVT_count_f
Non-Sel. Fuel Standby Pos. AI 144 AI 144 40423 FARC_AI_XXX[128] nvoNSlFlStPs_XXX SNVT_count_f
Registers 40419-40423 Current AI 145 AI 145 40424 FARC_AI_XXX[129] nvoR40419_23_XXX SNVT_count_f
Cycles AI 146 AI 146 40137 FARC_AD_XXX[15] nvoCycles_XXX SNVT_count_f
LCO Cycle Count AI 147 AI 147 40410 FARC_AD_XXX[16] nvoLCOCycCnt_XXX SNVT_count_f
Running Time Hours AI 148 AI 148 40437 FARC_AD_XXX[17] nvoRunTmHrs_XXX SNVT_time_hour
Running Time Minutes AI 149 AI 149 40438 FARC_AD_XXX[18] nvoRunTmMin_XXX SNVT_time_min
FARC CB 780/783 Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object
ID
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon SNVT Name Lon SNVT Name
