ProtoNode Gateway
750-426 105
Stack Pressure Input Fail BI 103 DI 103 10103 nvoStkPrInFl_XXX SNVT_switch
Hi Stack Pressure Alm BI 104 DI 104 10104 nvoHiStkPrAl_XXX SNVT_switch
Stack Damper Not Open Alm BI 105 DI 105 10105 nvoStDpNtOAl_XXX SNVT_switch
O2 Calibration Failed BI 106 DI 106 10106 nvoO2ClRtFld_XXX SNVT_switch
Lo Steam Pressure/Water Temp Alm BI 107 DI 107 10107 nvoLoStPWTAl_XXX SNVT_switch
Processor Test Fail Alm BI 108 DI 108 10108 nvoPrTstFlAl_XXX SNVT_switch
O2 Trim Internal Alm BI 109 DI 109 10109 nvoO2TrmInAl_XXX SNVT_switch
Firetube or Flextube 1 = Flextube BI 110 DI 110 10110 nvoFir_FlxTb_XXX SNVT_switch
Reserved for Cleaver Brooks BI 111 DI 111 10111 nvoAB_6_14_XXX SNVT_switch
VSD Limits Internal Alm BI 112 DI 112 10112 nvoVSDLmInAl_XXX SNVT_switch
Gas Actuator 2 Out Of Pos Alm BI 113 DI 113 10113 nvoGsAc2PsAl_XXX SNVT_switch
Gas Actuator 2 Feedback Fail Lo Alm BI 114 DI 114 10114 nvoGsAc2LoAl_XXX SNVT_switch
Gas Actuator 2 Feedback Fail Hi Alm BI 115 DI 115 10115 nvoGsAc2HiAl_XXX SNVT_switch
Actuator Modbus Communication Error BI 116 DI 116 10116 nvoAcModCmEr_XXX SNVT_switch
Air Actuator Modbus Comm Error Node 1 BI 117 DI 117 10117 nvoAAcMdCEr1_XXX SNVT_switch
Gas Actuator Modbus Comm Error Node 2 BI 118 DI 118 10118 nvoGsAMdCEr2_XXX SNVT_switch
Gas Act 2 Modbus Comm Error Node 3 BI 119 DI 119 10119 nvoGsA2MdCE3_XXX SNVT_switch
Oil Actuator Modbus Comm Error Node 5 BI 120 DI 120 10120 nvoOAcMdCEr5_XXX SNVT_switch
FGR Actuator Modbus Comm Error Node 7 BI 121 DI 121 10121 nvoFGRAMdCE7_XXX SNVT_switch
Reserved BI 122 DI 122 10122 nvoAB_7_9_XXX SNVT_switch
Reserved BI 123 DI 123 10123 nvoAB_7_10_XXX SNVT_switch
2nd Stage Outlet Wtr Temp Sensor Fail BI 124 DI 124 10124 nvo2SOtWTSnF_XXX SNVT_switch
Water Temp Second Stage Out Hi BI 125 DI 125 10125 nvoWtTp2SOtH_XXX SNVT_switch
Air Actuator Man Override Btn Press BI 126 DI 126 10126 nvoAAcMnOBPr_XXX SNVT_switch
Gas Actuator 1 Man Override Btn Press BI 127 DI 127 10127 nvoGAc1MOBPr_XXX SNVT_switch
Gas Actuator 2 Man Override Btn Press BI 128 DI 128 10128 nvoGAc2MOBPr_XXX SNVT_switch
Oil Actuator Man Override Btn Press BI 129 DI 129 10129 nvoOAcMnOBPr_XXX SNVT_switch
FGR Actuator Man Override Btn Press BI 130 DI 130 10130 nvoFGRAMnOBP_XXX SNVT_switch
Fuel 3 Act 1 Man Override Btn Press BI 131 DI 131 10131 nvoFl3A1MOBP_XXX SNVT_switch
Fuel 3 Act 2 Man Override Btn Press BI 132 DI 132 10132 nvoFl3A2MOBP_XXX SNVT_switch
Communication from BMS Failed BI 133 DI 133 10133 nvoComBMSFld_XXX SNVT_switch
CAP High BI 134 DI 134 10134 nvoCAPHi_XXX SNVT_switch
Water Flow Low BI 135 DI 135 10135 nvoWtrFlLo_XXX SNVT_switch
Water Level Signal Failed BI 136 DI 136 10136 nvoWtrLvSgFl_XXX SNVT_switch
Remote Setpoint Signal Failed BI 137 DI 137 10137 nvoRmSPSigFl_XXX SNVT_switch
Low O2 Shutdown BI 138 DI 138 10138 nvoLoO2Shdn_XXX SNVT_switch
Air Actuator Fault BI 139 DI 139 10139 nvoAirActFlt_XXX SNVT_switch
Fuel 1 Actuator 1 Fault BI 140 DI 140 10140 nvoF1Act1Flt_XXX SNVT_switch
Fuel 1 Actuator 2 Fault BI 141 DI 141 10141 nvoF1Act2Flt_XXX SNVT_switch
Fuel 2 Actuator 1 Fault BI 142 DI 142 10142 nvoF2Act1Flt_XXX SNVT_switch
Fuel 2 Actuator 2 Fault BI 143 DI 143 10143 nvoF2Act2Flt_XXX SNVT_switch
FGR Actuator Fault BI 144 DI 144 10144 nvoFGRActFlt_XXX SNVT_switch
Fuel 2 Actuator 2 Position Deviation BI 145 DI 145 10145 nvoF2Ac2PsDv_XXX SNVT_switch
Fuel 2 Actuator 2 Feedback Low BI 146 DI 146 10146 nvoF2Ac2FBLo_XXX SNVT_switch
Fuel 2 Actuator 2 Feedback High BI 147 DI 147 10147 nvoF2Ac2FBHi_XXX SNVT_switch
Fuel 2 Actuator 2 Manual PB Pressed BI 148 DI 148 10148 nvoF2A2MnPBP_XXX SNVT_switch
VFD Feedback Low BI 149 DI 149 10149 nvoVFDFBLo_XXX SNVT_switch
VFD Feedback High BI 150 DI 150 10150 nvoVFDFBHi_XXX SNVT_switch
Master PIDE Instruction Fault BI 151 DI 151 10151 nvoMstPIDFlt_XXX SNVT_switch
FGEN Fault BI 152 DI 152 10152 nvoFGENFlt_XXX SNVT_switch
Outdoor Temp Sensor Failed BI 153 DI 153 10153 nvoOutTpSnFl_XXX SNVT_switch
Combustion Air Temp Sensor Failed BI 154 DI 154 10154 nvoCmArTpSFl_XXX SNVT_switch
HAWK_4000_V2 Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks (Continued)
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
