CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 111
Feed Pump 2 In AUTO BI 56 DI 56 10056 nvoFdP2InAut_XXX SNVT_switch
Feed Pump 3 In AUTO BI 57 DI 57 10057 nvoFdP3InAut_XXX SNVT_switch
Feed Pump 4 In AUTO BI 58 DI 58 10058 nvoFdP4InAut_XXX SNVT_switch
Feed Pump 5 In AUTO BI 59 DI 59 10059 nvoFdP5InAut_XXX SNVT_switch
Feed Pump 6 In AUTO BI 60 DI 60 10060 nvoFdP6InAut_XXX SNVT_switch
Deaerator No Alarms Relay OK BI 61 DI 61 10061 nvoDeaNoAlms_XXX SNVT_switch
Yellow Stack Light ON BI 62 DI 62 10062 nvoYelStkLt_XXX SNVT_switch
Green Stack Light ON BI 63 DI 63 10063 nvoGrnStkLt_XXX SNVT_switch
Red Stack Light ON BI 64 DI 64 10064 nvoRedStkLt_XXX SNVT_switch
Chemical Feed ON BI 65 DI 65 10065 nvoChmFdON_XXX SNVT_switch
Deaerator Feed Wtr Valve Open BI 66 DI 66 10066 nvoDeFdWVlOp_XXX SNVT_switch
Feed Pumps ALT MODE ON BI 67 DI 67 10067 nvoFdPAltMd_XXX SNVT_switch
DA Lo-Lo Wtr Cutoff Relay Energized BI 68 DI 68 10068 nvoDACtoRlEn_XXX SNVT_switch
Deaerator 2nd Feed Wtr Valve Open BI 69 DI 69 10069 nvoD2FdWVlOp_XXX SNVT_switch
Boiler Feed Pump 1 Flow Fault BI 70 DI 70 10070 nvoFdP1FloFl_XXX SNVT_switch
Boiler Feed Pump 2 Flow Fault BI 71 DI 71 10071 nvoFdP2FloFl_XXX SNVT_switch
Boiler Feed Pump 3 Flow Fault BI 72 DI 72 10072 nvoFdP3FloFl_XXX SNVT_switch
Boiler Feed Pump 4 Flow Fault BI 73 DI 73 10073 nvoFdP4FloFl_XXX SNVT_switch
Boiler Feed Pump 5 Flow Fault BI 74 DI 74 10074 nvoFdP5FloFl_XXX SNVT_switch
Boiler Feed Pump 6 Flow Fault BI 75 DI 75 10075 nvoFdP6FloFl_XXX SNVT_switch
PLC Battery Low. Replace Battery BI 76 DI 76 10076 nvoPLCBatLo_XXX SNVT_switch
Feed Pump 1 VSD Speed Feedback Bad Q BI 77 DI 77 10077 nvoFdP1VSDBQ_XXX SNVT_switch
Feed Pump 2 VSD Speed Feedback Bad Q BI 78 DI 78 10078 nvoFdP2VSDBQ_XXX SNVT_switch
Feed Pump 3 VSD Speed Feedback Bad Q BI 79 DI 79 10079 nvoFdP3VSDBQ_XXX SNVT_switch
Feed Pump 4 VSD Speed Feedback Bad Q BI 80 DI 80 10080 nvoFdP4VSDBQ_XXX SNVT_switch
Feed Pump 5 VSD Speed Feedback Bad Q BI 81 DI 81 10081 nvoFdP5VSDBQ_XXX SNVT_switch
Feed Pump 6 VSD Speed Feedback Bad Q BI 82 DI 82 10082 nvoFdP6VSDBQ_XXX SNVT_switch
Recirculation Valve Close BI 83 DI 83 10083 nvoRecVlvCls_XXX SNVT_switch
Feed Pumps Lead Lag Enabled BI 84 DI 84 10084 nvoFPLLEnbl_XXX SNVT_switch
Feed Pumps Auto Restart Enabled BI 85 DI 85 10085 nvoFPAutReEn_XXX SNVT_switch
Remote Set Point Active BI 86 DI 86 10086 nvoRemSPAct_XXX SNVT_switch
User Def Ch2 Bad Quality BI 87 DI 87 10087 nvoCh2BadQ_XXX SNVT_switch
User Def Ch2 LOW BI 88 DI 88 10088 nvoCh2Low_XXX SNVT_switch
User Def Ch2 HIGH BI 89 DI 89 10089 nvoCh2High_XXX SNVT_switch
User Def Ch3 Bad Quality BI 90 DI 90 10090 nvoCh3BadQ_XXX SNVT_switch
User Def Ch3 LOW BI 91 DI 91 10091 nvoCh3Low_XXX SNVT_switch
User Def Ch3 HIGH BI 92 DI 92 10092 nvoCh3High_XXX SNVT_switch
Spare45 BI 93 DI 93 10093 nvoDAB1_5_12_XXX SNVT_switch
Spare46 BI 94 DI 94 10094 nvoDAB1_5_13_XXX SNVT_switch
Spare47 BI 95 DI 95 10095 nvoDAB1_5_14_XXX SNVT_switch
Reserved for CB - ADAC 1000 Dual BI 96 DI 96 10096 nvoADAC1000D_XXX SNVT_switch
Surge Tank Level BAD QUALITY BI 97 DI 97 10097 nvoSgTkLvlBQ_XXX SNVT_switch
Surge Tank Level HIGH BI 98 DI 98 10098 nvoSgTkLvlHi_XXX SNVT_switch
Surge Tank Level LOW BI 99 DI 99 10099 nvoSgTkLvlLo_XXX SNVT_switch
Surge Tank Temperature BAD QUALITY BI 100 DI 100 10100 nvoSgTkTmpBQ_XXX SNVT_switch
Surge Tank Temperature LOW BI 101 DI 101 10101 nvoSgTkTmpLo_XXX SNVT_switch
Surge Tank Temperature HIGH BI 102 DI 102 10102 nvoSgTkTmpHi_XXX SNVT_switch
Transfer Pump 1 FAULT BI 103 DI 103 10103 nvoXfrPm1Flt_XXX SNVT_switch
Transfer Pump 2 FAULT BI 104 DI 104 10104 nvoXfrPm2Flt_XXX SNVT_switch
Transfer Pump 3 FAULT BI 105 DI 105 10105 nvoXfrPm3Flt_XXX SNVT_switch
Transfer Pump 1 OVERLOAD BI 106 DI 106 10106 nvoXfrP1OvLd_XXX SNVT_switch
Transfer Pump 2OVERLOAD BI 107 DI 107 10107 nvoXfrP2OvLd_XXX SNVT_switch
Transfer Pump 3OVERLOAD BI 108 DI 108 10108 nvoXfrP3OvLd_XXX SNVT_switch
Surge Tank LOW-LOW (LWCO) BI 109 DI 109 10109 nvoSgTkLWCO_XXX SNVT_switch
Surge Tank Header Pressure HIGH BI 110 DI 110 10110 nvoSgTkHdPHi_XXX SNVT_switch
Surge Tank Header Pressure LOW BI 111 DI 111 10111 nvoSgTkHdPLo_XXX SNVT_switch
Surge Tank Header Pressure BAD QUALITY BI 112 DI 112 10112 nvoSgTkHPrBQ_XXX SNVT_switch
ADAC_1000 EtherNet/IP Mappings to BACnet, Metasys N2 and LonWorks (Continued)
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
