CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 113
DAR1[9] AI 10 AI 10 30019 nvoDAR1_9_XXX SNVT_count_f
Stop Lag Feed Pump Limit AI 11 AI 11 30021 nvoStLgFdPLm_XXX SNVT_count_f
Alternate Feed Pumps AI 12 AI 12 30023 nvoAltFdPmps_XXX SNVT_time_hour
Start Chemical Feed Time Delay AI 13 AI 13 30025 nvoStrChFTDl_XXX SNVT_time_sec
Stop Chemical Feed Time Delay AI 14 AI 14 30027 nvoStpChFTDl_XXX SNVT_time_sec
DAR1[14] AI 15 AI 15 30029 nvoDAR1_14_XXX SNVT_count_f
Deaerator Temp AI 16 AI 16 30031 nvoDeaTmp_XXX SNVT_temp_p
Deaerator Tank Pressure AI 17 AI 17 30033 nvoDeaTnkPrs_XXX SNVT_count_f
Deaerator Tank Wtr Lvl AI 18 AI 18 30035 nvoDeaTnWtLv_XXX SNVT_count_f
Deaerator Feed Wtr (MUV) Signal AI 19 AI 19 30037 nvoDeaMUVSig_XXX SNVT_lev_percent
Deaerator Steam PRValve Signal AI 20 AI 20 30039 nvoDeaStPRVS_XXX SNVT_lev_percent
Boiler Feed Wtr Header Pressure AI 21 AI 21 30041 nvoBFdWtHdPr_XXX SNVT_count_f
2nd Feed Water (MUV) Signal AI 22 AI 22 30043 nvoDea2MUVSg_XXX SNVT_lev_percent
Start Lag Feed Pump Limit AI 23 AI 23 30045 nvoStrLgFPLm_XXX SNVT_count_f
DA Level - Pump Auto-Restart Level AI 24 AI 24 30047 nvoDALvPmAut_XXX SNVT_count_f
Boiler Feed Water Header Pressure SetPt AI 25 AI 25 30049 nvoBFWHdPrSP_XXX SNVT_count_f
Over Flow Valve Signal AI 26 AI 26 30051 nvoOvFlVlvSg_XXX SNVT_count_f
User Cfg 0 EU/Tray Temperature AI 27 AI 27 30053 nvoUsr0TT_XXX SNVT_count_f
User Cfg 1 EU/Tray Pressure AI 28 AI 28 30055 nvoUsr1TP_XXX SNVT_count_f
User Cfg 2 EU AI 29 AI 29 30057 nvoUsr2EU_XXX SNVT_count_f
User Cfg 3 EU AI 30 AI 30 30059 nvoUsr3EU_XXX SNVT_count_f
Spare AI 31 AI 31 30061 nvoDAR1_30_XXX SNVT_count_f
User Cfg 0 Flow Total AI 32 AI 32 30063 nvoUsr0FlTot_XXX SNVT_count_f
User Cfg 1 Flow Total AI 33 AI 33 30065 nvoUsr1FlTot_XXX SNVT_count_f
User Cfg 2 Flow Total AI 34 AI 34 30067 nvoUsr2FlTot_XXX SNVT_count_f
User Cfg 3 Flow Total AI 35 AI 35 30069 nvoUsr3FlTot_XXX SNVT_count_f
Spare AI 36 AI 36 30071 nvoDAR1_35_XXX SNVT_count_f
Spare102 AI 37 AI 37 30073 nvoDAR1_36_XXX SNVT_count_f
Spare103 AI 38 AI 38 30075 nvoDAR1_37_XXX SNVT_count_f
Spare104 AI 39 AI 39 30077 nvoDAR1_38_XXX SNVT_count_f
Surge Header Pressure AI 40 AI 40 30079 nvoSrgHdrPrs_XXX SNVT_count_f
Surge Tank Temperature AI 41 AI 41 30081 nvoSrgTnkTmp_XXX SNVT_temp_p
Surge Tank Water Level AI 42 AI 42 30083 nvoSgTkWtrLv_XXX SNVT_count_f
Surge Tank Feed Water (MUV) Signal AI 43 AI 43 30085 nvoSgTkFdWSg_XXX SNVT_lev_percent
Transfer Pump 1 Run Time AI 44 AI 44 30087 nvoXfrP1RnTm_XXX SNVT_time_hour
Transfer Pump 2 Run Time AI 45 AI 45 30089 nvoXfrP2RnTm_XXX SNVT_time_hour
Transfer Pump 3 Run Time AI 46 AI 46 30091 nvoXfrP3RnTm_XXX SNVT_time_hour
Alternate Transfer Pumps AI 47 AI 47 30093 nvoAltXfrPs_XXX SNVT_time_hour
Stop Lag Transfer Pump Limit AI 48 AI 48 30095 nvoSpXfLFPLm_XXX SNVT_count_f
Surge Tank 2nd Feed Water (MUV) Signal AI 49 AI 49 30097 nvoSgT2FWSig_XXX SNVT_lev_percent
Start Lag Transfer Pump Limit AI 50 AI 50 30099 nvoSTStLgFPL_XXX SNVT_count_f
Surge Level - Tr Pump Auto-Restart Level AI 51 AI 51 30101 nvoSLvPARStL_XXX SNVT_count_f
Start Surge Chemical Feed Time Delay AI 52 AI 52 30103 nvoStrSrChFT_XXX SNVT_count_f
Stop Surge Chemical Feed Time Delay AI 53 AI 53 30105 nvoStpSrChFT_XXX SNVT_count_f
Transfer Header Pressure SetPt AI 54 AI 54 30107 nvoTrnHdPrSP_XXX SNVT_count_f
Surge Level - Transfer Valve Bias Setpoint 1 AI 55 AI 55 30109 nvoSLVlBSP1_XXX SNVT_count_f
Surge Level - Transfer Valve Bias Setpoint 2 AI 56 AI 56 30111 nvoSLVlBSP2_XXX SNVT_count_f
Spare114 AI 57 AI 57 30113 nvoDAR1_56_XXX SNVT_count_f
Spare115 AI 58 AI 58 30115 nvoDAR1_57_XXX SNVT_count_f
Spare116 AI 59 AI 59 30117 nvoDAR1_58_XXX SNVT_count_f
Spare117 AI 60 AI 60 30119 nvoDAR1_59_XXX SNVT_count_f
Spare118 AI 61 AI 61 30121 nvoDAR1_60_XXX SNVT_count_f
Spare119 AI 62 AI 62 30123 nvoDAR1_61_XXX SNVT_count_f
Spare120 AI 63 AI 63 30125 nvoDAR1_62_XXX SNVT_count_f
Spare121 AI 64 AI 64 30127 nvoDAR1_63_XXX SNVT_count_f
Spare122 AI 65 AI 65 30129 nvoDAR1_64_XXX SNVT_count_f
Spare123 AI 66 AI 66 30131 nvoDAR1_65_XXX SNVT_count_f
ADAC_1000 EtherNet/IP Mappings to BACnet, Metasys N2 and LonWorks (Continued)
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
