CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 115
* Write point
* DAWB[0]7 BV 8 DO 8 8 nviDAWB0_7_XXX SNVT_switch
* DAWB[0]8 BV 9 DO 9 9 nviDAWB0_8_XXX SNVT_switch
* DAWB[0]9 BV 10 DO 10 10 nviDAWB0_9_XXX SNVT_switch
* DAWB[0]10 BV 11 DO 11 11 nviDAWB0_10_XXX SNVT_switch
* DAWB[0]11 BV 12 DO 12 12 nviDAWB0_11_XXX SNVT_switch
* DAWB[0]12 BV 13 DO 13 13 nviDAWB0_12_XXX SNVT_switch
* DAWB[0]13 BV 14 DO 14 14 nviDAWB0_13_XXX SNVT_switch
* DAWB[0]14 BV 15 DO 15 15 nviDAWB0_14_XXX SNVT_switch
* DAWB[0]15 BV 16 DO 16 16 nviDAWB0_15_XXX SNVT_switch
* DAWB[1]0 BV 17 DO 17 17 nviDAWB1_0_XXX SNVT_switch
* DAWB[1]1 BV 18 DO 18 18 nviDAWB1_1_XXX SNVT_switch
* DAWB[1]2 BV 19 DO 19 19 nviDAWB1_2_XXX SNVT_switch
* DAWB[1]3 BV 20 DO 20 20 nviDAWB1_3_XXX SNVT_switch
* DAWB[1]4 BV 21 DO 21 21 nviDAWB1_4_XXX SNVT_switch
* DAWB[1]5 BV 22 DO 22 22 nviDAWB1_5_XXX SNVT_switch
* DAWB[1]6 BV 23 DO 23 23 nviDAWB1_6_XXX SNVT_switch
* DAWB[1]7 BV 24 DO 24 24 nviDAWB1_7_XXX SNVT_switch
* DAWB[1]8 BV 25 DO 25 25 nviDAWB1_8_XXX SNVT_switch
* DAWB[1]9 BV 26 DO 26 26 nviDAWB1_9_XXX SNVT_switch
* DAWB[1]10 BV 27 DO 27 27 nviDAWB1_10_XXX SNVT_switch
* DAWB[1]11 BV 28 DO 28 28 nviDAWB1_11_XXX SNVT_switch
* DAWB[1]12 BV 29 DO 29 29 nviDAWB1_12_XXX SNVT_switch
* DAWB[1]13 BV 30 DO 30 30 nviDAWB1_13_XXX SNVT_switch
* DAWB[1]14 BV 31 DO 31 31 nviDAWB1_14_XXX SNVT_switch
* DAWB[1]15 BV 32 DO 32 32 nviDAWB1_15_XXX SNVT_switch
* BFP 1 LEAD/LAG Order AV 1 AO 1 40001 nviBFP1LLOrd_XXX SNVT_count_f
* BFP 2 LEAD/LAG Order AV 2 AO 2 40002 nviBFP2LLOrd_XXX SNVT_lev_percent
* BFP 3 LEAD/LAG Order AV 3 AO 3 40003 nviBFP3LLOrd_XXX SNVT_count_f
* BFP 4 LEAD/LAG Order AV 4 AO 4 40004 nviBFP4LLOrd_XXX SNVT_count_f
* BFP 5 LEAD/LAG Order AV 5 AO 5 40005 nviBFP5LLOrd_XXX SNVT_count_f
* DAWI[5] AV 6 AO 6 40006 nviDAWI_5_XXX SNVT_count_f
* TP 1 LEAD/LAG Order AV 7 AO 7 40007 nviTP1LLOrd_XXX SNVT_count_f
* TP 2 LEAD/LAG Order AV 8 AO 8 40008 nviTP2LLOrd_XXX SNVT_count_f
* TP 2 LEAD/LAG Order AV 9 AO 9 40009 nviTP3LLOrd_XXX SNVT_count_f
* DAWI[9] AV 10 AO 10 40010 nviDAWI_9_XXX SNVT_count_f
* DAWI[10] AV 11 AO 11 40011 nviDAWI_10_XXX SNVT_count_f
* DAWI[11] AV 12 AO 12 40012 nviDAWI_11_XXX SNVT_count_f
* DAWI[12] AV 13 AO 13 40013 nviDAWI_12_XXX SNVT_count_f
* DAWI[13] AV 14 AO 14 40014 nviDAWI_13_XXX SNVT_count_f
* DAWI[14] AV 15 AO 15 40015 nviDAWI_14_XXX SNVT_count_f
* DAWI[15] AV 16 AO 16 40016 nviDAWI_15_XXX SNVT_count_f
* DAWI[16] AV 17 AO 17 40017 nviDAWI_16_XXX SNVT_count_f
* DAWI[17] AV 18 AO 18 40018 nviDAWI_17_XXX SNVT_count_f
* DAWI[18] AV 19 AO 19 40019 nviDAWI_18_XXX SNVT_count_f
* DAWI[19] AV 20 AO 20 40020 nviDAWI_19_XXX SNVT_count_f
* FW Header Pressure Setpoint AV 21 AO 21 40030 nviFWHdPrsSP_XXX SNVT_count_f
* DAWR[1] AV 22 AO 22 40032 nviDAWR_1_XXX SNVT_count_f
* DAWR[2] AV 23 AO 23 40034 nviDAWR_2_XXX SNVT_count_f
* DAWR[3] AV 24 AO 24 40036 nviDAWR_3_XXX SNVT_count_f
* DAWR[4] AV 25 AO 25 40038 nviDAWR_4_XXX SNVT_count_f
* DAWR[5] AV 26 AO 26 40040 nviDAWR_5_XXX SNVT_count_f
* DAWR[6] AV 27 AO 27 40042 nviDAWR_6_XXX SNVT_count_f
* DAWR[7] AV 28 AO 28 40044 nviDAWR_7_XXX SNVT_count_f
* DAWR[8] AV 29 AO 29 40046 nviDAWR_8_XXX SNVT_count_f
* DAWR[9] AV 30 AO 30 40048 nviDAWR_9_XXX SNVT_count_f
ADAC_1000 EtherNet/IP Mappings to BACnet, Metasys N2 and LonWorks (Continued)
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
