ProtoNode Gateway
750-426 118
Stack Pressure Input Fail BI 103 DI 103 10103 nvoStkPrInFl_XXX SNVT_switch
Hi Stack Pressure Alm BI 104 DI 104 10104 nvoHiStkPrAl_XXX SNVT_switch
Stack Damper Not Open Alm BI 105 DI 105 10105 nvoStDpNtOAl_XXX SNVT_switch
O2 Calibration Failed BI 106 DI 106 10106 nvoO2ClRtFld_XXX SNVT_switch
Lo Steam Pressure/Water Temp Alm BI 107 DI 107 10107 nvoLoStPWTAl_XXX SNVT_switch
Processor Test Fail Alm BI 108 DI 108 10108 nvoPrTstFlAl_XXX SNVT_switch
O2 Trim Internal Alm BI 109 DI 109 10109 nvoO2TrmInAl_XXX SNVT_switch
Firetube or Flextube 1 = Flextube BI 110 DI 110 10110 nvoFir_FlxTb_XXX SNVT_switch
Reserved for Cleaver Brooks BI 111 DI 111 10111 nvoAB_6_14_XXX SNVT_switch
VSD Limits Internal Alm BI 112 DI 112 10112 nvoVSDLmInAl_XXX SNVT_switch
Gas Actuator 2 Out Of Pos Alm BI 113 DI 113 10113 nvoGsAc2PsAl_XXX SNVT_switch
Gas Actuator 2 Feedback Fail Lo Alm BI 114 DI 114 10114 nvoGsAc2LoAl_XXX SNVT_switch
Gas Actuator 2 Feedback Fail Hi Alm BI 115 DI 115 10115 nvoGsAc2HiAl_XXX SNVT_switch
Actuator Modbus Communication Error BI 116 DI 116 10116 nvoAcModCmEr_XXX SNVT_switch
Air Actuator Modbus Comm Error Node 1 BI 117 DI 117 10117 nvoAAcMdCEr1_XXX SNVT_switch
Gas Actuator Modbus Comm Error Node 2 BI 118 DI 118 10118 nvoGsAMdCEr2_XXX SNVT_switch
Gas Act 2 Modbus Comm Error Node 3 BI 119 DI 119 10119 nvoGsA2MdCE3_XXX SNVT_switch
Oil Actuator Modbus Comm Error Node 5 BI 120 DI 120 10120 nvoOAcMdCEr5_XXX SNVT_switch
FGR Actuator Modbus Comm Error Node 7 BI 121 DI 121 10121 nvoFGRAMdCE7_XXX SNVT_switch
Reserved BI 122 DI 122 10122 nvoAB_7_9_XXX SNVT_switch
Reserved BI 123 DI 123 10123 nvoAB_7_10_XXX SNVT_switch
2nd Stage Outlet Wtr Temp Sensor Fail BI 124 DI 124 10124 nvo2SOtWTSnF_XXX SNVT_switch
Water Temp Second Stage Out Hi BI 125 DI 125 10125 nvoWtTp2SOtH_XXX SNVT_switch
Air Actuator Man Override Btn Press BI 126 DI 126 10126 nvoAAcMnOBPr_XXX SNVT_switch
Gas Actuator 1 Man Override Btn Press BI 127 DI 127 10127 nvoGAc1MOBPr_XXX SNVT_switch
Gas Actuator 2 Man Override Btn Press BI 128 DI 128 10128 nvoGAc2MOBPr_XXX SNVT_switch
Oil Actuator Man Override Btn Press BI 129 DI 129 10129 nvoOAcMnOBPr_XXX SNVT_switch
FGR Actuator Man Override Btn Press BI 130 DI 130 10130 nvoFGRAMnOBP_XXX SNVT_switch
Fuel 3 Act 1 Man Override Btn Press BI 131 DI 131 10131 nvoFl3A1MOBP_XXX SNVT_switch
Fuel 3 Act 2 Man Override Btn Press BI 132 DI 132 10132 nvoFl3A2MOBP_XXX SNVT_switch
Communication from BMS Failed BI 133 DI 133 10133 nvoComBMSFld_XXX SNVT_switch
CAP High BI 134 DI 134 10134 nvoCAPHi_XXX SNVT_switch
Water Flow Low BI 135 DI 135 10135 nvoWtrFlLo_XXX SNVT_switch
Water Level Signal Failed BI 136 DI 136 10136 nvoWtrLvSgFl_XXX SNVT_switch
Remote Setpoint Signal Failed BI 137 DI 137 10137 nvoRmSPSigFl_XXX SNVT_switch
Low O2 Shutdown BI 138 DI 138 10138 nvoLoO2Shdn_XXX SNVT_switch
Air Actuator Fault BI 139 DI 139 10139 nvoAirActFlt_XXX SNVT_switch
Fuel 1 Actuator 1 Fault BI 140 DI 140 10140 nvoF1Act1Flt_XXX SNVT_switch
Fuel 1 Actuator 2 Fault BI 141 DI 141 10141 nvoF1Act2Flt_XXX SNVT_switch
Fuel 2 Actuator 1 Fault BI 142 DI 142 10142 nvoF2Act1Flt_XXX SNVT_switch
Fuel 2 Actuator 2 Fault BI 143 DI 143 10143 nvoF2Act2Flt_XXX SNVT_switch
FGR Actuator Fault BI 144 DI 144 10144 nvoFGRActFlt_XXX SNVT_switch
Fuel 2 Actuator 2 Position Deviation BI 145 DI 145 10145 nvoF2Ac2PsDv_XXX SNVT_switch
Fuel 2 Actuator 2 Feedback Low BI 146 DI 146 10146 nvoF2Ac2FBLo_XXX SNVT_switch
Fuel 2 Actuator 2 Feedback High BI 147 DI 147 10147 nvoF2Ac2FBHi_XXX SNVT_switch
Fuel 2 Actuator 2 Manual PB Pressed BI 148 DI 148 10148 nvoF2A2MnPBP_XXX SNVT_switch
VFD Feedback Low BI 149 DI 149 10149 nvoVFDFBLo_XXX SNVT_switch
VFD Feedback High BI 150 DI 150 10150 nvoVFDFBHi_XXX SNVT_switch
Master PIDE Instruction Fault BI 151 DI 151 10151 nvoMstPIDFlt_XXX SNVT_switch
FGEN Fault BI 152 DI 152 10152 nvoFGENFlt_XXX SNVT_switch
Outdoor Temp Sensor Failed BI 153 DI 153 10153 nvoOutTpSnFl_XXX SNVT_switch
Combustion Air Temp Sensor Failed BI 154 DI 154 10154 nvoCmArTpSFl_XXX SNVT_switch
Hawk 4500 EtherNet/IP Mappings to BACnet, Metasys N2 and LonWorks
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
