CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 65
Gas Actuator Modbus Comm Error Node 2 BI 118 DI 118 10118 nvoGsAMdCEr2_XXX SNVT_switch
Gas Act 2 Modbus Comm Error Node 3 BI 119 DI 119 10119 nvoGsA2MdCE3_XXX SNVT_switch
Oil Actuator Modbus Comm Error Node 5 BI 120 DI 120 10120 nvoOAcMdCEr5_XXX SNVT_switch
FGR Actuator Modbus Comm Error Node 7 BI 121 DI 121 10121 nvoFGRAMdCE7_XXX SNVT_switch
Reserved BI 122 DI 122 10122 nvoAB_7_9_XXX SNVT_switch
Reserved BI 123 DI 123 10123 nvoAB_7_10_XXX SNVT_switch
2nd Stg Outlet Wtr Temp Sensor Failed BI 124 DI 124 10124 nvo2StOtWTSF_XXX SNVT_switch
Wtr Temp Second Stg Out Hi BI 125 DI 125 10125 nvoWT2StOtHi_XXX SNVT_switch
Air Actuator Man Override Btn Press BI 126 DI 126 10126 nvoAAcMnOBPr_XXX SNVT_switch
Gas Actuator 1 Man Override Btn Press BI 127 DI 127 10127 nvoGAc1MOBPr_XXX SNVT_switch
Gas Actuator 2 Man Override Btn Press BI 128 DI 128 10128 nvoGAc2MOBPr_XXX SNVT_switch
Oil Actuator Man Override Btn Press BI 129 DI 129 10129 nvoOAcMnOBPr_XXX SNVT_switch
FGR Actuator Man Override Btn Press BI 130 DI 130 10130 nvoFGRAMnOBP_XXX SNVT_switch
Fuel 3 Act 1 Man Override Btn Press BI 131 DI 131 10131 nvoFl3A1MOBP_XXX SNVT_switch
Fuel 3 Act 2 Man Override Btn Press BI 132 DI 132 10132 nvoFl3A2MOBP_XXX SNVT_switch
Communication from BMS Failed BI 133 DI 133 10133 nvoComBMSFld_XXX SNVT_switch
Combustion Air Pressure Hi BI 134 DI 134 10134 nvoComArPrHi_XXX SNVT_switch
Wtr FLo Lo BI 135 DI 135 10135 nvoWtrFloLo_XXX SNVT_switch
Wtr Level Signal Failed BI 136 DI 136 10136 nvoWtLvSgFld_XXX SNVT_switch
Remote Setpoint Signal Failed BI 137 DI 137 10137 nvoRmSPSgFld_XXX SNVT_switch
Lo O2 Shutdown BI 138 DI 138 10138 nvoLoO2Shdn_XXX SNVT_switch
Air Actuator Fault BI 139 DI 139 10139 nvoAirAcFlt_XXX SNVT_switch
Fuel 1 Actuator 1 Fault BI 140 DI 140 10140 nvoFl1Ac1Flt_XXX SNVT_switch
Fuel 1 Actuator 2 Fault BI 141 DI 141 10141 nvoFl1Ac2Flt_XXX SNVT_switch
Fuel 2 Actuator 1 Fault BI 142 DI 142 10142 nvoFl2Ac1Flt_XXX SNVT_switch
Fuel 2 Actuator 2 Fault BI 143 DI 143 10143 nvoFl2Ac2Flt_XXX SNVT_switch
FGR Actuator Fault BI 144 DI 144 10144 nvoFGRAcFlt_XXX SNVT_switch
Fuel 2 Actuator 2 Pos Deviation BI 145 DI 145 10145 nvoFl2Ac2PsD_XXX SNVT_switch
Fuel 2 Actuator 2 Feedback Lo BI 146 DI 146 10146 nvoFl2Ac2FLo_XXX SNVT_switch
Fuel 2 Actuator 2 Feedback Hi BI 147 DI 147 10147 nvoFl2Ac2FHi_XXX SNVT_switch
Fuel 2 Actuator 2 Man PB Press BI 148 DI 148 10148 nvoF2A2MnPBP_XXX SNVT_switch
VFD Feedback Lo BI 149 DI 149 10149 nvoVFDFdbkLo_XXX SNVT_switch
VFD Feedback Hi BI 150 DI 150 10150 nvoVFDFdbkHi_XXX SNVT_switch
Master PIDE Instruction Fault BI 151 DI 151 10151 nvoMPIDEInFl_XXX SNVT_switch
FGEN Fault BI 152 DI 152 10152 nvoFGENFlt_XXX SNVT_switch
Outdoor Temp/Retrun Temp Sensor Failed BI 153 DI 153 10153 nvoOTmpRTpFl_XXX SNVT_switch
Combustion Air Temp Sensor Failed BI 154 DI 154 10154 nvoCmATpSnFl_XXX SNVT_switch
O2 Sensor Fault BI 155 DI 155 10155 nvoO2SenFlt_XXX SNVT_switch
AB[9]11 BI 156 DI 156 10156 nvoAB_9_11_XXX SNVT_switch
AB[9]12 BI 157 DI 157 10157 nvoAB_9_12_XXX SNVT_switch
AB[9]13 BI 158 DI 158 10158 nvoAB_9_13_XXX SNVT_switch
AB[9]14 BI 159 DI 159 10159 nvoAB_9_14_XXX SNVT_switch
Hawk 1000 system BI 160 DI 160 10160 nvoH1000Sys_XXX SNVT_switch
Flame Strength Honeywell AI 1 AI 1 30001 nvoFlmStrHny_XXX SNVT_count_f
Combustion Air Fan Speed AI 2 AI 2 30003 nvoCmArFnSpd_XXX SNVT_count_f
AR[2] AI 3 AI 3 30005 nvoAR_2 XXX SNVT_count_f
Boiler Efficiency AI 4 AI 4 30007 nvoBlrEff_XXX SNVT_lev_percent
Firing Rate AI 5 AI 5 30009 nvoFirRat_XXX SNVT_lev_percent
O2 Level AI 6 AI 6 30011 nvoO2Lvl_XXX SNVT_lev_percent
SP Steam Pressure/Wtr Temp AI 7 AI 7 30013 nvoSPStPWtTp_XXX SNVT_count_f
Wtr Level AI 8 AI 8 30015 nvoWtrLvl_XXX SNVT_press_f
Steam Pressure or Hot Wtr Temp AI 9 AI 9 30017 nvoStPrHWTmp_XXX SNVT_count_f
AR[9] AI 10 AI 10 30019 nvoAR_9_XXX SNVT_count_f
Stack Temp Before Economizer AI 11 AI 11 30021 nvoStkTpBfEc_XXX SNVT_temp_p
Combustion Air Temp AI 12 AI 12 30023 nvoComAirTmp_XXX SNVT_temp_p
Wtr Temp Shell/Outdoor Temp AI 13 AI 13 30025 nvoWtTpShl_XXX SNVT_temp_p
FeedWtr Temp/Econ Wtr Out Temp AI 14 AI 14 30027 nvoFdWtTp_XXX SNVT_temp_p
Stack Temp After Econ/Return HW AI 15 AI 15 30029 nvoStkTmpEco_XXX SNVT_temp_p
Economizer Wtr In Temp AI 16 AI 16 30031 nvoEcWtInTmp_XXX SNVT_temp_p
Hawk 1000 Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
Lon Name Lon SNVT Type
