CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 67
*Write point
* AWB[0]9 BV 10 DO 10 00010 nviAWB_0_9_XXX SNVT_switch
* AWB[0]10 BV 11 DO 11 00011 nviAWB_0_10_XXX SNVT_switch
* AWB[0]11 BV 12 DO 12 00012 nviAWB_0_11_XXX SNVT_switch
* AWB[0]12 BV 13 DO 13 00013 nviAWB_0_12_XXX SNVT_switch
* AWB[0]13 BV 14 DO 14 00014 nviAWB_0_13_XXX SNVT_switch
* AWB[0]14 BV 15 DO 15 00015 nviAWB_0_14_XXX SNVT_switch
* AWB[0]15 BV 16 DO 16 00016 nviAWB_0_15_XXX SNVT_switch
* AWB[1]0 BV 17 DO 17 00017 nviAWB_1_0_XXX SNVT_switch
* AWB[1]1 BV 18 DO 18 00018 nviAWB_1_1_XXX SNVT_switch
* AWB[1]2 BV 19 DO 19 00019 nviAWB_1_2_XXX SNVT_switch
* AWB[1]3 BV 20 DO 20 00020 nviAWB_1_3_XXX SNVT_switch
* AWB[1]4 BV 21 DO 21 00021 nviAWB_1_4_XXX SNVT_switch
* AWB[1]5 BV 22 DO 22 00022 nviAWB_1_5_XXX SNVT_switch
* AWB[1]6 BV 23 DO 23 00023 nviAWB_1_6_XXX SNVT_switch
* AWB[1]7 BV 24 DO 24 00024 nviAWB_1_7_XXX SNVT_switch
* AWB[1]8 BV 25 DO 25 00025 nviAWB_1_8_XXX SNVT_switch
* AWB[1]9 BV 26 DO 26 00026 nviAWB_1_9_XXX SNVT_switch
* AWB[1]10 BV 27 DO 27 00027 nviAWB_1_10_XXX SNVT_switch
* AWB[1]11 BV 28 DO 28 00028 nviAWB_1_11_XXX SNVT_switch
* AWB[1]12 BV 29 DO 29 00029 nviAWB_1_12_XXX SNVT_switch
* AWB[1]13 BV 30 DO 30 00030 nviAWB_1_13_XXX SNVT_switch
* AWB[1]14 BV 31 DO 31 00031 nviAWB_1_14_XXX SNVT_switch
* AWB[1]15 BV 32 DO 32 00032 nviAWB_1_15_XXX SNVT_switch
* Rem Op SP Boiler AV 1 AO 1 40001 nviRemOpSPBl_XXX SNVT_count_f
* Rem Firing Rate AV 2 AO 2 40003 nviRemFirRat_XXX SNVT_lev_percent
* Rem Op SP 2 boiler Lead/Lag AV 3 AO 3 40005 nviRmOSP2BLL_XXX SNVT_count_f
* AWR[3] AV 4 AO 4 40007 nviAWR_3_XXX SNVT_count_f
* AWR[4] AV 5 AO 5 40009 nviAWR_4_XXX SNVT_count_f
* AWR[5] AV 6 AO 6 40011 nviAWR_5_XXX SNVT_count_f
* AWR[6] AV 7 AO 7 40013 nviAWR_6_XXX SNVT_count_f
* AWR[7] AV 8 AO 8 40015 nviAWR_7_XXX SNVT_count_f
* AWR[8] AV 9 AO 9 40017 nviAWR_8_XXX SNVT_count_f
* AWR[9] AV 10 AO 10 40019 nviAWR_9_XXX SNVT_count_f
Hawk 1000 Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
Lon Name Lon SNVT Type
