CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
78 750-426
CPU Battery Alm BI 150 DI 150 10150 nvoCPUBatAlm_XXX SNVT_switch
Actuator8 (2nd Air) Out Of Pos Alm BI 151 DI 151 10151 nvoAc8PosAlm_XXX SNVT_switch
Actuator9 (2nd F1) Out Of Pos Alm BI 152 DI 152 10152 nvoAc9PosAlm_XXX SNVT_switch
Actuator8 (2nd Air) FB Outside Cal Rng BI 153 DI 153 10153 nvoAc8FBOCRg_XXX SNVT_switch
Actuator9 (2nd F1) FB Outside Cal Rng BI 154 DI 154 10154 nvoAc9FBOCRg_XXX SNVT_switch
Reserved BI 155 DI 155 10155 nvoAB9_10_XXX SNVT_switch
Reserved BI 156 DI 156 10156 nvoAB9_11_XXX SNVT_switch
Reserved BI 157 DI 157 10157 nvoAB9_12_XXX SNVT_switch
No Fuel Selected BI 158 DI 158 10158 nvoNoFlSel_XXX SNVT_switch
EIP Comm Link FAULT - Master Panel BI 159 DI 159 10159 nvoEIPCmLkFl_XXX SNVT_switch
Reserved BI 160 DI 160 10160 nvoAB9_15_XXX SNVT_switch
HAlm - Usr Def (07:00) BI 161 DI 161 10161 nvoHAl_07_00_XXX SNVT_switch
HAlm - Usr Def (07:01) BI 162 DI 162 10162 nvoHAl_07_01_XXX SNVT_switch
HAlm - Usr Def (07:02) BI 163 DI 163 10163 nvoHAl_07_02_XXX SNVT_switch
HAlm - Usr Def (07:03) BI 164 DI 164 10164 nvoHAl_07_03_XXX SNVT_switch
HAlm - Usr Def (07:04) BI 165 DI 165 10165 nvoHAl_07_04_XXX SNVT_switch
HAlm - Usr Def (07:05) BI 166 DI 166 10166 nvoHAl_07_05_XXX SNVT_switch
HAlm - Usr Def (07:06) BI 167 DI 167 10167 nvoHAl_07_06_XXX SNVT_switch
HAlm - Usr Def (07:07) BI 168 DI 168 10168 nvoHAl_07_07_XXX SNVT_switch
Input Bad Quality - Usr Def (07:00) BI 169 DI 169 10169 nvoBdQl07_00_XXX SNVT_switch
Input Bad Quality - Usr Def (07:01) BI 170 DI 170 10170 nvoBdQl07_01_XXX SNVT_switch
Input Bad Quality - Usr Def (07:02) BI 171 DI 171 10171 nvoBdQl07_02_XXX SNVT_switch
Input Bad Quality - Usr Def (07:03) BI 172 DI 172 10172 nvoBdQl07_03_XXX SNVT_switch
Input Bad Quality - Usr Def (07:04) BI 173 DI 173 10173 nvoBdQl07_04_XXX SNVT_switch
Input Bad Quality - Usr Def (07:05) BI 174 DI 174 10174 nvoBdQl07_05_XXX SNVT_switch
Input Bad Quality - Usr Def (07:06) BI 175 DI 175 10175 nvoBdQl07_06_XXX SNVT_switch
Input Bad Quality - Usr Def (07:07) BI 176 DI 176 10176 nvoBdQl07_07_XXX SNVT_switch
LAlm - Usr Def (07:00) BI 177 DI 177 10177 nvoLAl_07_00_XXX SNVT_switch
LAlm - Usr Def (07:01) BI 178 DI 178 10178 nvoLAl_07_01_XXX SNVT_switch
LAlm - Usr Def (07:02) BI 179 DI 179 10179 nvoLAl_07_02_XXX SNVT_switch
LAlm - Usr Def (07:03) BI 180 DI 180 10180 nvoLAl_07_03_XXX SNVT_switch
LAlm - Usr Def (07:04) BI 181 DI 181 10181 nvoLAl_07_04_XXX SNVT_switch
LAlm - Usr Def (07:05) BI 182 DI 182 10182 nvoLAl_07_05_XXX SNVT_switch
LAlm - Usr Def (07:06) BI 183 DI 183 10183 nvoLAl_07_06_XXX SNVT_switch
LAlm - Usr Def (07:07) BI 184 DI 184 10184 nvoLAl_07_07_XXX SNVT_switch
Reserved BI 185 DI 185 10185 nvoAB11_8_XXX SNVT_switch
Reserved BI 186 DI 186 10186 nvoAB11_9_XXX SNVT_switch
Reserved BI 187 DI 187 10187 nvoAB11_10_XXX SNVT_switch
Reserved BI 188 DI 188 10188 nvoAB11_11_XXX SNVT_switch
Reserved BI 189 DI 189 10189 nvoAB11_12_XXX SNVT_switch
Reserved BI 190 DI 190 10190 nvoAB11_13_XXX SNVT_switch
Reserved BI 191 DI 191 10191 nvoAB11_14_XXX SNVT_switch
Reserved BI 192 DI 192 10192 nvoAB11_15_XXX SNVT_switch
Steam Press AI 1 AI 1 30001 nvoStmPrs_XXX SNVT_count_f
Drum Level AI 2 AI 2 30003 nvoDrumLvl_XXX SNVT_count_f
Stack Temp AI 3 AI 3 30005 nvoStkTmp_XXX SNVT_count_f
Remote Modulation AI 4 AI 4 30007 nvoRemMod_XXX SNVT_count_f
Steam Flo AI 5 AI 5 30009 nvoStmFlo_XXX SNVT_count_f
Mud Drum Shell Temp AI 6 AI 6 30011 nvoMdDrShTp_XXX SNVT_count_f
VSD Speed Feedback AI 7 AI 7 30013 nvoVSDSpFdbk_XXX SNVT_count_f
Hawk 5000 Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
Lon Name Lon SNVT Type
