Blr G Lead Lag Entered Seq AI 657 AI 45 31149 nvoGLLEntSq_XXX SNVT_count_f
Blr H Lead Lag Entered Seq AI 658 AI 46 31150 nvoHLLEntSq_XXX SNVT_count_f
Blr A Lead Lag Working Seq AI 659 AI 47 31151 nvoALLWrkSq_XXX SNVT_count_f
Blr B Lead Lag Working Seq AI 660 AI 48 31152 nvoBLLWrkSq_XXX SNVT_count_f
Blr C Lead Lag Working Seq AI 661 AI 49 31153 nvoCLLWrkSq_XXX SNVT_count_f
Blr D Lead Lag Working Seq AI 662 AI 50 31154 nvoDLLWrkSq_XXX SNVT_count_f
Blr E Lead Lag Working Seq AI 663 AI 51 31155 nvoeLLWrkSq_XXX SNVT_count_f
Blr F Lead Lag Working Seq AI 664 AI 52 31156 nvoFLLWrkSq_XXX SNVT_count_f
Blr G Lead Lag Working Seq AI 665 AI 53 31157 nvoGLLWrkSq_XXX SNVT_count_f
Blr H Lead Lag Working Seq AI 666 AI 54 31158 nvoHLLWrkSq_XXX SNVT_count_f
Max Pressure/Temp AI 401 AI 55 30801 nvoMaxPrsTmp_XXX SNVT_count_f
Lead Boiler On Point AI 402 AI 56 30803 nvoLdBlrOnPt_XXX SNVT_count_f
Lead Boiler Off Point AI 403 AI 57 30805 nvoLdBlrOfPt_XXX SNVT_count_f
Operating Pressure/Temp AI 404 AI 58 30807 nvoOpPrsTmp_XXX SNVT_count_f
Low SP Limit AI 405 AI 59 30809 nvoLoSPLim_XXX SNVT_count_f
High SP Limit AI 406 AI 60 30811 nvoHiSPLim_XXX SNVT_count_f
Days Till Auto Seq Rotation AI 407 AI 61 30813 nvoDyAtSqRot_XXX SNVT_count_f
Hours Till Auto Seq Rotation AI 408 AI 62 30815 nvoHrAtSqRot_XXX SNVT_count_f
Minutes Till Auto Seq Rotation AI 409 AI 63 30817 nvoMnAtSqRot_XXX SNVT_count_f
Seconds Till Auto Seq Rotation AI 410 AI 64 30819 nvoScAtSqRot_XXX SNVT_count_f
Control Output Boiler A AI 411 AI 65 30821 nvoCtrOutBlA_XXX SNVT_lev_percent
Control Output Boiler B AI 412 AI 66 30823 nvoCtrOutBlB_XXX SNVT_lev_percent
Control Output Boiler C AI 413 AI 67 30825 nvoCtrOutBlC_XXX SNVT_lev_percent
Control Output Boiler D AI 414 AI 68 30827 nvoCtrOutBlD_XXX SNVT_lev_percent
Control Output Boiler E AI 415 AI 69 30829 nvoCtrOutBlE_XXX SNVT_lev_percent
Control Output Boiler F AI 416 AI 70 30831 nvoCtrOutBlF_XXX SNVT_lev_percent
Control Output Boiler G AI 417 AI 71 30833 nvoCtrOutBlG_XXX SNVT_lev_percent
Control Output Boiler H AI 418 AI 72 30835 nvoCtrOutBlH_XXX SNVT_lev_percent
Steam Pressure (Water Temp) SP AI 419 AI 73 30837 nvoStmPrsSP_XXX SNVT_count_f
AMR[19] AI 420 AI 74 30839 nvoAMR_19_XXX SNVT_count_f
AMR[20] AI 421 AI 75 30841 nvoAMR_20_XXX SNVT_count_f
AMR[21] AI 422 AI 76 30843 nvoAMR_21_XXX SNVT_count_f
AMR[22] AI 423 AI 77 30845 nvoAMR_22_XXX SNVT_count_f
AMR[23] AI 424 AI 78 30847 nvoAMR_23_XXX SNVT_count_f
AMR[24] AI 425 AI 79 30849 nvoAMR_24_XXX SNVT_count_f
AMR[25] AI 426 AI 80 30851 nvoAMR_25_XXX SNVT_count_f
* Master Write Bit BV 1 DO 1 00001 nvoMstWrtBit_XXX SNVT_switch
* Setpoint Value Write AV 51 AO 51 40051 nvoSPValWrt_XXX SNVT_count_f
* N510[0] AV 1 AO 1 40001 nvoN510_0_XXX SNVT_count_f
* Lag 1 Start Timer Set AV 2 AO 2 40002 nvoL1StrTmSt_XXX SNVT_time_sec
* Lag 1 Start Point AV 3 AO 3 40003 nvoLg1StrPt_XXX SNVT_count_f
* Lag 1 Stop Point AV 4 AO 4 40004 nvoLg1StpPt_XXX SNVT_count_f
* Lag 1 Stop Timer Set AV 5 AO 5 40005 nvoL1StpTmSt_XXX SNVT_time_sec
* N510[5] AV 6 AO 6 40006 nvoN510_5_XXX SNVT_count_f
* Lag 2 Start Timer Set AV 7 AO 7 40007 nvoL2StrTmSt_XXX SNVT_time_sec
* Lag 2 Start Point AV 8 AO 8 40008 nvoLg2StrPt_XXX SNVT_count_f
* Lag 2 Stop Point AV 9 AO 9 40009 nvoLg2StpPt_XXX SNVT_count_f
* Lag 2 Stop Timer Set AV 10 AO 10 40010 nvoL2StpTmSt_XXX SNVT_time_sec
* N510[10] AV 11 AO 11 40011 nvoN510_10_XXX SNVT_count_f
* Lag 3 Start Timer Set AV 12 AO 12 40012 nvoL3StrTmSt_XXX SNVT_time_sec
* Lag 3 Start Point AV 13 AO 13 40013 nvoLg3StrPt_XXX SNVT_count_f
* Lag 3 Stop Point AV 14 AO 14 40014 nvoLg3StpPt_XXX SNVT_count_f
* Lag 3 Stop Timer Set AV 15 AO 15 40015 nvoL3StpTmSt_XXX SNVT_time_sec
* Lead Boiler Selection AV 16 AO 16 40016 nvoLdBlrSel_XXX SNVT_count_f
* Lag 1 Boiler Selection AV 17 AO 17 40017 nvoLg1BlrSel_XXX SNVT_count_f
Hawk Master Panel Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
Lon Name Lon SNVT Type
To Next Page
