List of ACU events
98-148248-C Appendix D: System messages D-9
DDDD
System messages
0807F-0 ADM WARNING Local administration
enabled
Local administration mode is currently enabled. This
allows login without providing the admin password.
Will be disabled after 1 hour or next reboot.
08080-0 ADM WARNING Satellite info
mismatch
Currently selected manual satellite information does
not match information from the modem. Please select
another satellite for manual pointing.
08081-0 ADM WARNING BUC communication Missing communication between VMU and BUC.
Info: 0x00000001: From VMU to BUC
Info: 0x00000002: From BUC to VMU
08083-0 ADM WARNING Friction test timeout Friction test timeout. Info code format: 0xaaaatttt,
where aaaa = axis under test (0=Azi, 1=XEL, 2=EL) and
tttt = timeout type.
Info: 0xaaaa0001: Axis aaaa did not get ready for test
in time
Info: 0xaaaa0002: Axis aaaa test did not finish in
time
08100-0 ADM ERROR PSM low voltage (22
V)
The ADM measures a different antenna voltage than
expected. If the problem is not solved by a restart,
and the PSM is not reporting any errors, the ADM is
probably defective.
08101-0 ADM ERROR PSM high voltage (48
V)
The ADM measures a different antenna voltage than
expected. Check for short circuit of the antenna coax
connector. If the problem is not solved by a restart,
and the PSM is not reporting any errors, the ADM is
probably defective.
08102-0 ADM ERROR PSM 5 V power Internal voltage supply error of the ADM.
08103-0 ADM ERROR ADM hotswap The ACU is not able to supply the correct voltage to
the antenna. Check for short circuits in coax cable and
the antenna
08104-0 ADM ERROR Antenna
communication
The ACU cannot communicate with the antenna.
Check cable and antenna.
08107-0 ADM ERROR ADM FPGA load The ADM FPGA cannot be initialised and loaded.
08108-0 ADM ERROR TX Power Detector
calibration
The power detector calibration is not valid.
08109-0 ADM ERROR Antenna XIM data There is a mismatch in the antenna configuration
data. Either the PCM or the VIM in the antenna are
malfunctioning or one of them has been replaced. In
the latter case, select which is the original device in
the web interface and restart the system.
0810A-0 ADM ERROR ADM production data Production data has been corrupted.
