Configuration with the web interface
6-18 Chapter 6: Configuration 98-148248-C
To navigate the web interface
• To expand a menu, click the menu in the navigation pane.
• To access status and settings, click the relevant subject in the navigation pane or
click the relevant icon in the icon bar. The status or settings are displayed in the contents
section.
• To get an overview over the submenus available, click SITE MAP in the
navigation pane. Click on items in the site map to go directly to the relevant location.
To access the web interface
To access the antenna web interface do as follows:
1. Connect a PC to LAN interface 3 (Service port, standard Ethernet) of the ACU or to the
front LAN connector of the ACU. If you want to use another LAN port to access the
web interface you must configure it according to your network requirements. See To
configure the LAN network on page 6-26 for more information.
2. Open your Internet browser and enter the IP address of the ACU (Default IP address:
http://192.168.0.1).
Status field in the icon bar
The top bar shows the current status of the antenna.
• Antenna initializing
• Antenna SW upload
• Antenna POST error
• XIM data error
• Unrecoverable XIM data error
•System upgrade
• Antenna POST pending
• Antenna POST
• Safe Mode (error, followed by an error description)
• Ready (waiting for data from the modem or no satellite profile selected)
• Pointing antenna (locating the satellite)
• Acquiring signal (acquiring the satellite signal)
• Tracking (tracks the current satellite)
• Lineup (line up is activated)
•Azimuth calibration
• TX cable calibration
•BUC calibration
•Test
