CONCORD HANDILIFT - Appendix A; Electrical Schematics

47
APPENDIX ‘A’
Electrical Schematics
NOTE
These electrical schematics are for a typical installation of a HANDILIFT at the time
of printing this manual. The exact schematics for the HANDILIFT are shipped with
the unit and may be different from what is shown in Appendix A. For accuracy, only
the schematics shipped with the unit should be used.
