82
REAR ASSEMBLY PORTABLE BASE
Concord Handilift Vertical Wheelchair Platform Lift
REF. DESCRIPTION QTY. PART NUMBER
1 Rear Frame Assembly 1 241305
11 Rear Wheel Bar 1 241301
16 Central Screw Assembly 1 241310
22 Screw 3/8 - 16 x 1" ZNC 10 102197
23 Flat Washer .375" ZNC 3/8 2 102188
28 Brace Cab to Base 3/16 x 1 1/4 2 241377
33 Hex Nut 3/8 - 16 UNC JAM 10 100085
34 Wheel Pneumatic Assembly 8" Rigid 2 103499
35 Lock Washer 0.375 Spring ZNC 3/8 2 102191
36 Clevis Pin 1/4 x 1" 2 103558
37 Hitch Pin Clip 0.042 Diameter 2 103557
