CONCORD HANDILIFT - Cab Assembly (Type 2)

72
AB ASSEMBLY (TYPE 2)
oncord Handilift Vertical Wheelchair Platform Lift
C
C
REF. DESCRIPTION QTY. PART NUMBER
1 Car Control Station Assembly 1 See Chart “A”
2 Screw Cap Hex Head 1/4-20 x 1 ½" Full Thread 2 100154
3 Lock Washer 1/4" Spring (Zinc) 2 101213
4 Flat Washer 1/4" (Zinc) 2 101196
5 Wall Control Subassembly 54" x 42" 1 240614
6 Wall Side Subassembly 54" x 42" 1 240617
7 Machine Screw Flathead 1/4-20 x 3/4" Phillips 4 100086
8 Vertical Wall Stiffener Subassembly 4 240078
9 35" x 54" Platform Weldment Subassembly 1 240570
10 13" x 28" Anti-Skid Safety Tread 3 100561
11 Plastic Edge Protector 2 100519
12 Flat Washer 5/16" Spring (Zinc) 8 102324
13 Lock Washer 5/16" Spring (Zinc) 8 102190
14 Screw Cap Hex Head 5/16" #18 x 1 1/4" (Zinc) 8 100168
CHART “A”
PACKAGE REQUIRED PART NUMBER
Key, 1, 2 248060
Key, Stop, 1, 2 248059
Key, Stop/Alarm, 1, 2 248058
