CONCORD HANDILIFT - Main Drive Screw Subassembly

MAIN DRIVE SCREW SUBASSEMBLY
Concord Handilift Vertical Wheelchair Platform Lift
REF. DESCRIPTION QTY. PART NUMBER
1 1" Diameter -5 Pitch Class 2G Acme Screw 1 248016
2 Thrust Bearing Flange Block 1 248003
3 25 mm ID Angular Contact Ball Bearing 2 102387
4 Thrust Adaptor Subassembly 1 248007
5 5/32" Diameter x 1" Spring Pin 1 100542
Main Drive Screw Subassembly
77
