CONCORD HANDILIFT - Car Station Assembly

74
AR STATION ASSEMBLY
oncord Handilift Vertical Wheelchair Platform Lift
C
C
REF. DESCRIPTION QTY. PART NUMBER
1 Car Station Box (Interior/Exterior) 1 240095
2 Car Station Plate (14 ga. ST/STL) 1 248044
3 Speed Nut - Spring - #18-32 2 101074
4 “Button Board” PCB Assembly 1 776009
5 #6-32 UNF Hex Nut (Zinc) 6 101113
6 #6 Lock Washer - Spring (Zinc) 6 101220
7 #8 Flat Washer - Standard (Zinc) 4 101206
8 #8 Fork Terminal (for #18AWG) Ground 1 100656
9 #6-32 UNC x 3/4" F.H.M.S. (Zinc) 4 100069
10 Rubber Grommet (for Alarm option) 1 101488
11 #6-32 x 1" P.H.M.S. (Zinc) 1 102180
12 #10 Lock Washer - Spring (Zinc) 2 101223
13 #10-32 UNF x 1" P.H.M.S. (Zinc) 2 101121
14 “Concord” Logo Label 1 102259
15 Hex Lock Nut (Key Switch) supplied with item 21 1 n/a
16 #8-32 x 1" Allen Head M.S. (ST/STL) 2 101042
17 Car Station Traveling Cable Clamp 1 635056
18 Push Button Legend “Alarm” 1 100640
19 Push Button Legend “Arrow” 2 100735
20 Push Button Switch (Yellow Lens) 1 100598
21 Switch Keyed (Chicago) 1 102268
22 Push Button Switch (Clear Lens) 2 100592
23 Switch Rocker Red (Optional) 1 100599
24 Plank Switch Wiring Harness 1 771024
25 Traveling Cable Harness (15'-6") 1 776008
26 Under-platform Obstruction Sensor Harness
(Optional)
1 240100
27 #6-32 UNC x 1" Weld Stud 2 101038
28 #8-32 x 3/8" P.H.M.S. - Phillips (Zinc) 1 101138
29 #8 Lock Washer - Standard (Zinc) 1 101222
30 Alarm Piezo - Horn (Optional) 1 674004
31 9 Volt D.C. Battery (Snap-Top) 2 n/a
