CONCORD HANDILIFT - Main Drive Nut Subassembly

70
AIN DRIVE NUT SUBASSEMBLY
oncord Handilift Vertical Wheelchair Platform Lift
M
C
REF. DESCRIPTION QTY. PART NUMBER
1 Drive Nut Swivel Seat (Upper) 1 248047
2 Drive Nut Swivel Universal Joint 1 248048
3 Drive Nut Swivel Seat (Lower) 1 248046
4 Main Drive Nut (Bronze) 1 248001
5 Drive Nut Retainer Plate 1 248025
6 1/2" x 1/2" Shoulder Bolt (3.8-16 UNC) 4 102564
7 (0.0005 lbs) Fabric Oil Wick - 3/4" long 1 102704
8 #6-32 x 1/4: P.H.M.S. (Zinc) 1 751043
9 3/8" Lock Washer - Spring (Zinc) 2 102191
10 3/8"-16 x 2 3/4" H.H.C.S. (Zinc) 2 102518
11 Barrel Switch - Positive Acting (Plank) 1 102182
12 15/32" Thin Hex Nut (Included with item 11) 2 n/a
