FRONT ASSEMBLY PORTABLE BASE
Concord Handilift Vertical Wheelchair Platform Lift
REF. DESCRIPTION QTY. PART NUMBER
1 Front Frame Assembly 1 241348
11 Wheel Support Bar Assembly 1 241319
17 Wheel 8" OD Pneumatic Swivel 2 102340
18 Screw 3/8 - 16 x 1" ZNC 8 102197
19 Flat Washer .375" ZNC 3/8 8 102188
21 Hex Nut 3/8 UNC Jam 8 100085
22 Central Screw Assembly 1 241310
28 Handle Bar Assembly 1 241366
30 Clevis Pin 2 103558
32 Hitch Pin Clip 2 103557
37 Handle Grip 3 100852
38 Clevis Pin 1/2 Diameter 6 Lg 1 103525
39 Cotter Pin 0.065 1 102833
