GENERAL SPECIFICATIONS
CONCORD HANDILIFT PLATFORM LIFT
Load Capacity 550 lbs. (250 kg)
Optional Load Capacity 750 lbs. (341 kg) load capacity is available. This option requires a 20
uit breaker and a minimum 10 gauge wire feed. The unit is built
pere overload.
ampere circ
with a 20 am
Rated Speed 8 feet per minute (0.04 m/s) Nominal
Power Supply 110 VAC, 15 amperes min., 60 Hz (Slow Blow/Motor Start Circuit),
Single Phase
220 VAC, 10 amperes min., 50 Hz, Single Phase
Motor 1 HP (0.75 kW), 1800 rpm
Drive Type Acme Screw with matched V-Belt Drive
Platform Size 35” x 48” (890 mm x 1219 mm)
35” x 54” (890 mm x 1372 mm) clear in
side
Control Voltage
24 Volts DC
Control System Constant Pressure
Emergency Device Manual Lowering (Hand crank is optional)
Maximum Travel 12 feet (3660 mm)
Finish Polyester Baked Powder Coat Finish
Standard Features
• Anti-Skid Flooring
• Stand Alone Base (Free Standing)
• 42 1/4” (1073 mm) High Barrier Walls
• Automatic 16” (406 mm) “Flip-Up” Ramp on Platform or Permanent
Ramp for Increased Safety
• Integral “Back-Up” Nut Safety Device
• Detachable Platform Base and Sling
• Self-Lubricating Acme Screw Drive System for Maintenance Free
Operation
• Removable Modular Cab Walls
• Rigid Extruded Aluminum Cab with Steel Inserts for Strength and
Durability
• Cab Handrail for Added Safety and Convenience
• Under-Platform Obstruction Sensor
Options
• 36” - 72” (914 mm x 1829 mm) Height Option
• Exterior Package includes water resistant switches and buttons, weather
stripping and aluminum underpan
• Roofs - Domed or sloped roofs on EN model
• Colors - Optional colors in enamel finish for long lasting durability and
appearance
