UTOMATIC RAMP (OPTIONAL)
Figure # 9 Under Platform Safety Prop
A
TO PREVENT DAMAGE TO THE AUTOMATIC RAMP
AND/OR PERSONAL INJURY, TIE OR RESTRICT THE
AUTOMATIC RAMP’S MOVEMENT, BEFORE MOVING
THE PLATFORM.
The automatic ramp is attached to the platform on the same side as the lower landing in non-pitted
stallations. When shipped, the ramp is attached to the platform and the linkage arm. Refer to Figure #
0 and the following instructions
) Raise the platform approximately 4" (102 mm) to 6" (152 mm) above the lower limit.
While holding the ramp UP, install the l
tform, the linkage-arm
assembly plate and bolts.
3) Move the platform to the bottom limit, so that the ramp just touches the floor.
in
1 :
1
inkage bar between the ramp actuator arm and the
ramp. Refer to the ELECTRICAL CONNECTIONS section of this manual to hook-up
temporary controls to raise the lift.
2) Check that the ramp folds freely and clears the sides of the pla
