66
OTOR MOUNT SUBASSEMBLY
oncord Handilift Vertical Wheelchair Platform Lift
M
C
REF. DESCRIPTION QTY. PART NUMBER
1 Motor Mount/Drive Bracket Subassembly 1 248018
2 115/1/60 1 HP 1725 rpm Motor (56 Frame) 1 100968
3 2" Pitch Diameter Drive Sheave (5/8" Keyed) 1 248002
4 Capacitor Cover (included with motor) 1 n/a
5 3/8" Flex Duplex Connector 1 100597
6 Motor Wiring Cover (included with motor) 1 n/a
7 3/8" Flex Connector Straight 1 100600
8 1/4"-20 Hex Nut - Standard (Zinc) 4 102205
9 1/4" Lock Washer - Spring (Zinc) 4 101213
10 1/4" Flat Washer (Zinc) 4 101196
11 3/16" x 7/8" long Keystock (included with motor) 1 n/a
12 #10-32 x 1/2" P.H.M.S. (Zinc) Phillips 2 751078
13 #10 Flat Washer - Standard (Zinc) 2 101210
14 1/4"-20 x 1/4" Set Screw (Knurl point) 2 400838
15 Locknut (3/4" Electrical) Galvanized 2 102261
16 3/8" Flexible Conduit x 18" long 1 100880
17 3/8" Flexible Conduit x 66" long 1 100880
