CONCORD HANDILIFT - Main Drive Tower Assembly

64
AIN DRIVE TOWER ASSEMBLY
Concord Handilift Vertical Wheelchair Platform Lift
M
REF. DESCRIPTION QTY. PART NUMBER
1 Tower Weldment Subassembly 1 240020
2 Pit Channel 1/4" Formed 1 248094
3 Sling Assembly Handilift 1 248045
4 1" - 5 Class 2G Acme Screw Subassembly 1 248054
5 7" P.D. Type “A” V-Belt Sheave 1 248017
6 Standard Base Subassembly Left Hand 1 240255
7 Standard Base Subassembly Right Hand 1 240256
8 Limit Switch Bracket Assembly (Top Floor) 1 242408
9 Main Drive Nut Subassembly 1 248052
10 Limit Switch Bracket Assembly (Bottom Floor) 1 242407
11 Motor Mount Subassembly 1 248156
12 Anti-Vibration Gasket 1 248049
13 Type A-26 V-Belt (Matched Set) 4 102415
14 3/16" Keystock x 1" long 1 759011
15 1/2" x 1 1/4" Shoulder Bolt (3/8"-16 UNC) 15 102206
16 1/4" Flat Washer Standard (Zinc) 2 101196
17 1/4" Lock Washer (Zinc) 10 101213
18 1/4"-20 UNC Hex Nut Standard (Zinc) 9 102205
19 Motor/Capacitor Wiring Harness 1 776005
20 3/8"-16 UNC Hex Nut Standard (Zinc) 10 102186
21 Backup Nut Subassembly 1 248014
22 1/4"-20 x 1 1/2" H.H.C.S. (Zinc) 1 100154
24 3/8" Lock Washer Spring (Zinc) 13 102191
25 3/8"-16 x 1 1/4" H.H.C.S. (Zinc) 8 102201
26 17 ID x 40 OD Ball Bearing c/w Snap Ring 1 736016
31 Crosshead Support Channel S/A 1 248079
32 3/8" Flat Washer Standard (Zinc) 5 102188
33 Thrust Bearing Support Shim 1 248056
34 Bearing Isolation Gasket 1 248055
35 Rubber Isolator Bushing 5 102570
36 3/8" x 16 x 1" H.H.C.S. 6 102197
37 Manual Lowering Safety Plate Assy. 1 248108
